Innr$manual$for$Re mote$Control$RC$110$
!
!
Introduction!
You!can!use!the!Innr!remote!control!in!two!ways:! ! !
A. Bridge$Mode!7!if!you!alre a d y!h a ve !a !b rid ge !a n d !w a n t!to !a d d !th e !remote!co n tro l !
B. Standalone$Mode!7!if!you!don’t!hav e!a!brid ge !an d!w an t!to!ad d!ligh ts!directly!to!the!remote!
!
Bridge$Mode!Installation$(A)$
1. In!the!A p p !ch o ose!“Set tin g s” a n d !p u t!the !bridg e!in!the !“Search”!mode;!the!green!LED!on!the!
bridge!button!will!start!flashing!slowly.!
2. Then!simultaneously!press!and!hold!the!'program'!and !the !'7'!button!o n ! the !rem o te!co ntro l!
for!at!least!3!secon ds ;!the!gre en !LED !on !the ! RC!110!will!start!to!blink!slowly.!
3. Once!the!bridge!and!remote!found!each!other,!the!LED!on!the!RC!110!will!blink!fast!5x.!
4. Now!the!remote!control!is!coupled!to!the!bridge!and!the!RC!110!will!also!appear!in!the!
'lights’!s e a rc h !s c r e e n !o f !the!App.!
5. Stop!searching!and!choose!“Done ”!in !th e !ap p ,!th is !w ill!re g ist er !th e!R C !1 1 0 !in !th e !sy st em.!
6. The!remote!controls!all!the!lights!in!the!entire!system,!unless!you!link!it!to!a!specific!room!
to!only!control!the !lights!in!tha t!room.!This!can!be!do ne !in!th e!follow in g!w ay:!
a.!Open!the!app!and!choose!the!room!where!you!want!to!attach!the!remote!control.!
b.!Press!"Edit!Room”!and!tick!the!box!for!the!RC!110.!
c.!Now!put!the!remote!in!'learning!mode’!by!pressing!the!"Program"!button!for!3!seconds;!
the!green!LED!will!flash!slowly!for!30!seconds.!
d.!Click,!within!those!30!seconds,!on!"Update"!in!the!app!to!add!the!RC!110!to !the!ro om .!
The!remote!can!only!be!connected!to!one!room!at!a!time.!
!
Standalone$Mode!Installation$(B)$
1. Connect!the!remote!control!to!a!light!bulb!by!holding!it!close!to!a!lamp!(distance!<5!cm)!
and!then!simultaneously!press!and!hold!the!"Program"!and!"+"!buttons;!the!green!LED!
will!blink!slowly.!!
2. The!lamp!will!now!respond!by!flashing!once!or!twice.!About!10!seconds!later,!the!lamp!
will!again!flash!once!or!twice!to!indicate !tha t!it !is!successfully!coupled!with!the!remote!
control.!You!can!now!control!the!lamp.!
3. Repeat!this!process!with!all!the!lights!you!want!to!couple!with!the!remote!control.!You!
can!couple!up!to!10!lam ps !to!a!single !rem ote !con trol.!!
