SPECIFICATIONS

Allfeaturesandspecificationsaresubjectto changewithout notice.

Trademarksof DolbyLaboratories.

DTSisaregisteredtrademarkof DigitalTheater Systems,Inc.

Leviton Tech Support #2 1-800-824-3005

w w

w. l e v i t o n . c o m

OWNER’S GUIDE

AEH50-BL

AEH50-WH

AEH50 Complete Five-Piece Surround-Sound Home Cinema Speaker System

wit

h 100 Watt Powered Subwoofer

JBL is a registered trademark of JBL, Incorporated.

Speaker complement

Features

Specifications

Enclosure type: Bass-reflex

Recommended Amplifier Power Range: 10- 100 Watts

Amplifier 10

Woofer: 8“ (200)

Weight: 28 lbs (12.7kg)

Watts RMS

Frequenc

y Response (+/- 3dB): 35 Hz-150 Hz

Crossover Frequenc

y (+/- 3dB): 5000Hz, 6dB/octave

Frequenc

y Response (+/- 3dB): 150 Hz- 20 kHz

Speake

r Sensitivity (2.83V/1m): 86 dB

Impedance

: Nominal 8 Ohms

000-AEH50-BL – Leviton IS Part number: DI-000-AEH50-02A Vendor part number: 406-000-05421-E

003-AEH50-WH

- Leviton IS Part number: DI-000-AEH50-02A Vendor part number: 406-000-05421-E

000-AESS5-B

L Leviton IS Part number: DI-000-AESS5-02A Vendor part number: 406-000-05430-E

003-AESS5-W

H Leviton IS Part number: DI-000-AESS5-02A Vendor part number: 406-000-05430-E

• Five 2-way magnetically-shielded satellite speakers with high-output

5 in (63.5 mm) woofer and precision .5 in (12.7 mm) tweeter

• One 8 in (200 mm) 100 Watt powered subwoofer with LFE input, adjustable

leve

l control, and built-in crossover network for use with speaker-level outputs.

• Five-channel system is expandable to 6.1 and 7.1 surround-sound operation

wit

h optional additional AESS5 satellite speaker(s)

• Includes architectural-grade adjustable mounting brackets

• Includes subwoofer input RCA cable

Satellites

LIMITED 5 YEAR WARRANTY AND EXCLUSIONS

Leviton warrants to the original consumer purchaser and not for the benefit of anyone else that this product at the time of its sale by

Leviton is free of defects in materials and workmanship under normal and proper use for five years from the purchase date. Levitonʼs

only obligation is to correct such defects by repair or replacement, at its option, if within such five year period the product is returned

prepaid, with proof of purchase date, and a description of the problem to Leviton Manufacturing Co., Inc., Att: Quality Assurance

Department, 59-25 Little Neck Parkway, Little Neck, New York 11362-2591. This warranty excludes and there is disclaimed liability for

labor for removal of this product or reinstallation. This warranty is void if this product is installed improperly or in an improper environment,

overloaded, misused, opened, abused, or altered in any manner, or is not used under normal operating conditions or not in accordance

with any labels or instructions. There are no other or implied warranties of any kind, including merchantability and fitness for a

particular purpose, but if any implied warranty is required by the applicable jurisdiction, the duration of any such implied warranty,

including merchantability and fitness for a particular purpose, is limited to five years. Leviton is not liable for incidental, indirect,

special, or consequential damages, including without limitation, damage to, or loss of use of, any equipment, lost sales or

profits or delay or failure to perform this warranty obligation. The remedies provided herein are the exclusive remedies under this

warranty, whether based on contract, tort or otherwise.

Midrange Driver(s): 2-1/2” magnetcally shielded

High-Frequency Transducer: 1/2” magnetcally shielded

Dimension (H x W x D):

Dimension (H x W x D, icluding feet):

5“ x 3-1/2“ x 3-1/2“ (127mm x 88mm x 88mm)

16-1/4“ x 11“ x 13-3/4“ (413mm x 279mm x 349mm)

Weight per Speaker: 1.25 lbs. (

Subwoofer

READ FIRST!

Important Safety Precautions!

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near

water.

6. Clean only with a dry cloth.

7. Do not block any ventilation

openings. Install in accordance with

the manufacturer’s instructions.

8. Do not install near any heat

sources such as radiators, heat

registers, stoves or other apparatus

(including amplifiers) that produce

heat.

9. Do not defeat the safety purpose of

the polarized or grounding-type plug.

A polarized plug has two blades with

one wider than the other. A ground-

ing-type plug has two blades and a

third grounding prong. The wide

blade or the third prong are

provided for your safety. If the

provided plug does not fit into your

outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being

walked on or pinched, particularly at

plugs, convenience receptacles and

the point where they exit from the

apparatus.

11. Only use attachments/accessories

specified by the manufacturer.

12. Use only with the cart, stand,

tripod, bracket or table specified by

the manufacturer or sold with the

apparatus. When a cart is

used, use caution when

moving the cart/appara-

tus combination to avoid

injury from tip-over.

13. Unplug this apparatus during light-

ning storms or when unused for long

periods of time.

14. Refer all servicing to qualified

service personnel. Servicing is

required when the apparatus has

been damaged in any way, such as

power-supply cord or plug is dam-

aged, liquid has been spilled or

objects have fallen into the appara-

tus, the apparatus has been exposed

to rain or moisture, does not operate

normally, or has been dropped.

15. Do not use attachments not

recommended by the product

manufacturer, as they may cause

hazards.

16. This product should be operated

only from the type of power source

indicated on the marking label. If you

are not sure of the type of power

supply to your home, consult your

product dealer or local power

company. For products intended

to operate from battery power, or

other sources, refer to the operating

instructions.

1 7 . If an outside antenna or cable

system is connected to the product,

be sure the antenna or cable system

is grounded so as to provide some

protection against voltage surges

and built-up static charges. Article

810 of the National Electrical Code,

ANSI/NFPA 70, provides information

with regard to proper grounding of

the mast and supporting structure,

grounding of the lead-in wire to

an antenna discharge unit, size of

grounding conductors, location of

antenna-discharge unit, connection

to grounding electrodes, and require-

ments for the grounding electrode.

See Figure A.

18. An outside antenna system should

not be located in the vicinity of over-

head power lines or other electric

light or power circuits, or where it

can fall into such power lines or cir-

cuits. When installing an outside

antenna system, extreme care should

be taken to keep from touching such

power lines or circuits, as contact

with them might be fatal.

19. Do not overload wall outlets,

extension cords, or integral conven-

ience receptacles, as this can result

in a risk of fire or electric shock.

20. Never push objects of any kind

into this product through openings, as

they may touch dangerous voltage

points or short-out parts that could

result in a fire or electric shock.

Never spill liquid of any kind on the

product.

21. Do not attempt to service this

product yourself, as opening or

removing covers may expose you to

dangerous voltage or other hazards.

Refer all servicing to qualified

service personnel.

22. When replacement parts are

required, be sure the service tech-

nician has used replacement parts

specified by the manufacturer or that

have the same characteristics as the

original part. Unauthorized substitu-

tions may result in fire, electric shock

or other hazards.

23. Upon completion of any service or

repairs to this product, ask the serv-

ice technician to perform safety

checks to determine that the product

is in proper operating condition.

24. The product should be mounted

to a wall or ceiling only as recom-

mended by the manufacturer.

Figure A.

Example of Antenna Grounding as per

National Electrical Code ANSI/NFPA 70

3 Important Safety Precautions

4 Introduction

4 Unpacking the System

4 Planning Your System

5 Home Theater

6 Placement

7 Wall-Mounting the Satellites

7 Satellite Speaker Connections

8 Dolby* Digital or DTS

8 Dolby Pro Logic* (Non-Digital) Line Level

9 Dolby Pro Logic (Non-Digital) Speaker Level

10 Operation

11 Troubleshooting

12 Specifications

TABLE OF CONTENTS

OWNER’S GUIDE

Robin Marshall

Harman Consumer International

Chateau-du-Loir, France 10/03

Declaration of Conformity

We, Harman Consumer International

2, route de Tours

72500 Chateau-du-Loir

France

declare in own responsibility that the product described

in this owner’s manual is in compliance with technical

standards:

EN 50081-1:1992

EN 50082-1:1997
