Jøtul F V45 2 Greenville

Wood Stove

Jøtul F V 45 2

Greenville

Installation and Operating Instructions

The Jøtul F V Greenville heater is listed to 45 2

burn solid wood only.

Do not burn any other fuels.

Read this entire manual before you install

and use this appliance.

Save these instructions for future reference

and make them available to anyone using or

servicing the fireplace insert.

This wood heater requires periodic inspection

and repair for proper operation. See this

manual for specific maintenance information.

It is against federal regulations to operate

this wood heater in a manner inconsistent

with the operating instructions in this

owner’s manual.

This heater meets the 2020 U.S.

Environmental Protection Agency’s

emission limits for wood heaters

manufactured after May 15, 2020.

Une version française de ce manuel est disponible

au téléchargement sur www.jotul.ca

139967-5 F V 9/22 45 2

Jøtul F Greenville 45 V2

Accessories

Stove Gloves, pair - #157363

Flame-retardant, full length, Black.

Stove-Top Thermometer - #5002

We recommend the use of a magnetic stove-top thermometer

to monitor the surface temperature of the stove.

The optimum surface temperature range for the most

efficient performance is between 4000 F - 7000 F (2050 C -

3160 C).

Outside Air Kit - #157637

This kit includes a plenum assembly which attaches to the

stove bottom. It permits connection of duct work from

an outside source directly to the air intake of the stove. A

direct outside air connection is required for mobile home

installations.

Mobile Home Floor Bracket Kit - #157321

This kit includes two brackets used to fulfill the mobile

home requirement that the stove be secured directly to the

floor.

Blower Kit - #156431

This kit includes components for mounting a

thermostatically controlled 120 cfm blower to the back of

the stove to enhance heat convection into the living area.

Short Leg Kit - #157636

This kit includes four, 4 1/4” steel legs which allow stove

installation into a fireplace opening height as low as 26 1/4”.

Approved only for code-approved, masonry fireplace hearth

mount installation.

Table of Contents

Accessories ...................................................................................2

Standards and Safety Notices

Standards / Codes 3 ...........................................................................

Combustion Specifications 3 ...........................................................

Safety Notices 4 ..................................................................................

1.0 Installation

1.1. Unpack the Stove 5 ...................................................................

1.2 Bottom Heat Shield Requirement 5 .....................................

1.3 Short Leg Installation 5 ...........................................................

1.4 Leg Leveller Installation 5 .......................................................

1.5 Flue Collar Orientation 6 .........................................................

1.6 Flue Collar Heat Shield 6 ..........................................................

1.7 Chimney Connector 6 ...............................................................

2.0 Chimney Requirements

2.1 Masonry Chimneys 7 ...............................................................

2.2 Prefabricated Chimneys 7 .......................................................

2.3 Chimney Height 8 .....................................................................

2.4 Wall Pass-Throughs 8 ...............................................................

3.0 Connecting to the Chimney

3.1 Masonry Chimneys 9 ...............................................................

3.2 Hearthmount into a Masonry Fireplace 9 ...........................

3.3 Prefabricated Chimneys 10 .......................................................

3.4 Mobile Home Requirements 10 ..............................................

4.0 Clearances to Combustibles

4.1 Floor Protection 11 ......................................................................

4.2 Clearances to Walls and Ceilings 11 ........................................

4.3 Using Shields to Reduce Clearances 12 ..................................

4.4 Alcove Installation 12 .................................................................

4.5 Fireplace Clearances, Mantel and Trim ................................ 12

4.6 Clearance Diagrams 13 ..............................................................

5.0 Operation

5.1 Combustion Efficiency 14 ..........................................................

5.2 CO Emissions 14 ..........................................................................

5.3 Wood Fuel and Performance 14 ...............................................

5.4 F 45 2V Functionality 15 ............................................................

5.5 Air Control / Blower Settings 15 ..............................................

5.6 Controling the Fire 15 .................................................................

5.7 Break-in Procedure 16 .................................................................

5.8 Starting and Maintaining a Fire 16 ........................................

5.9 Adding Fuel 17 .............................................................................

5-10 Creosote and the Need for Removal .................................17

5.11 Ash Removal 17 ............................................................................

6.0 Maintenance

6.1 Door Latch 18 ................................................................................

6.2 Glass Care 18 .................................................................................

6.3 General Care 18 ............................................................................

6.4 Gasket Replacement 19 .............................................................

6.5 Glass Replacement 19 ................................................................

6.6 Chimney System 20 ....................................................................

6.7 Firebricks .................................................................................20

7.0 Appendix

7.1 Blower Installation 21 ................................................................

7.2 Outside Air Kit Installation 23 .................................................

7.3 Short Leg Installation 23 ...........................................................

7.4 Mobile Home Floor Bracket 24 ................................................

7.5 Secondary Air Manifold / Turbulator Inspection 25 ...........

7.6 F Start-Up and Refueling 26 45 V2 ...........................................

8.0 Illustrated Part List ........................................................... 28

9.0 Warranty Statement 31 .....................................................
