Side 1/28

Jøtul F 50 TL Rangeley

Wood Stove

Installation and Operating Instructions

for the U.S. and Canada

The Jøtul is listed to burn solid wood F 50 TL

only. Do not burn any other fuels.

Read this entire manual before you install

and use this appliance.

Save these instructions for future reference

and make them available to anyone using or

servicing the fireplace insert.

This wood heater requires periodic inspection

and repair for proper operation. See this

manual for specific maintenance information.

It is against federal regulations to operate

this wood heater in a manner inconsistent

with the operating instructions in this

owner’s manual.

139262 Rev_S F 50 TL Rangeley 1/20

Table of Contents

Standards / Codes ................................................... 3

Accessories ...................................................................................3

Safety Notices ............................................................................ 4

1.0 Installation

1.1. Assembly Before Installation 5 ..............................................

1.2 Flue Collar Installation 6 ..........................................................

1.3 Flue Collar Heat Shield 6 ..........................................................

1.4 Bottom Heat Shield Installation......................................... 6

1.5 Leg Leveller Installation 6 ........................................................

1.6 Chimney Connector 6 ...............................................................

2.0 Chimney Requirements

2.1 Masonry Chimneys 7 ...............................................................

2.2 Prefabricated Chimneys 8 .......................................................

2.3 Chimney Height 8 .....................................................................

2.4 Wall Pass-Throughs 8 ...............................................................

3.0 Connecting to the Chimney

3.1 Masonry Chimneys 9 ...............................................................

3.2 Hearthmount into a Masonry Fireplace 9 ...........................

3.3 Prefabricated Chimneys 10 .......................................................

3.4 Mobile Home Requirements 10 ..............................................

4.0 Clearances to Combustibles

4.1 Floor Protection 11 ......................................................................

4.2 Clearances to Walls and Ceilings 11 ........................................

4.3 Using Shields to Reduce Clearances 11 ..................................

4.4 Alcove Installation 12 .................................................................

4.5 Fireplace Clearances, Mantel and Trim ................................ 12

4.6 Clearance Diagrams 13 ..............................................................

5.0 Operation

5.1 Combustion Efficiency 14 ..........................................................

5.2 CO Emissions 14 ...........................................................................

5.3 Wood Fuel and Performance 14 ...............................................

5.4 F 50 TL Rangeley Functionality............................................15

5.5 Air Control 15 ................................................................................

5.6 Top Loading 15 .............................................................................

5.7 Controlling the Fire 16 ................................................................

5.8 Break-in Procedure 16 ................................................................

5.9 Starting and Maintaining a Fire 16 ........................................

5-10 Adding Fuel 17 .............................................................................

5.11 Open Door Fire-viewing 17 ......................................................

5.12 Creosote Formation 17 ..............................................................

5.13 Ash Removal 17 ...........................................................................

6.0 Maintenance

6.1 Glass Care 18 .................................................................................

6.2 General Care 18 ............................................................................

6.3 Glass Removal or Replacement 18 ..........................................

6.4 Gaskets .....................................................................................19

6.5 Gasket Replacement 19 .............................................................

6.6 Chimney System 19 ....................................................................

7.0 Appendix

7.1 Blower Installation 20 ................................................................

7.2 Outside Air Kit Installation 22 .................................................

7.3 Mobile Home Floor Bracket 23 ................................................

8.0 Illustrated Part List ........................................................... 24

9.0 Warranty Statement 26 ....................................................

Installation and Operation

Instructions for USA/Canada

Safety Notice: If this solid fuel room heater is not

properly installed, a house fire may result. For your

safety, follow the installation directions. Contact

local building or fire officials about restrictions

and installation inspection requirements in your

area. Save these instructions for future reference.
