Jøtul F 500 V3

Oslo

Catalytic Wood Heater

Classic and Clean Face Models

Installation and Operating Instructions

for the United States and Canada

Jøtul F 500 V3

Oslo

The Jøtul F 500 V3 wood stove is listed

to burn solid wood only. Do not burn any

other fuels.

Read this entire manual before you install

and use this appliance.

Save these instructions for future

reference and make them available to

anyone using or servicing this wood

heater.

This wood heater contains a catalytic

combustor that requires periodic

inspection and maintenance for proper

operation. See this manual for speciﬁc

maintenance information. It is against

federal regulations to operate this wood

heater in a manner inconsistent with the

operating instructions in this owner’s

manual, or if the catalytic element is

deactivated or removed.

Classic

Clean Face

Une version française de ce manuel est disponible auprès de

votre revendeur et sur le site www. jotul.ca.

139946-18 F 500 V3 Oslo May 2022

Table of Contents

Combustion Speciﬁcations,

Building Codes,

Safety Notices 3 .....................................................................

1. Installation

1.1 Assembly before Installation 4 ........................................

2. Chimney and Connector Requirements

2.1 Chimney Connector 4 ......................................................

2.2 General Requirements.................................................. 4

2.3 Masonry Chimneys 5 .......................................................

2.4 Prefabricated Chimneys 5 ..............................................

2.5 Chimney Height 5 ..........................................................

2.6 Wall Pass-through 6 .........................................................

3. Connecting to the Chimney

3.1 Masonry Chimney Thimbles 6 .........................................

3.2 Hearthmount into a Masonry Fireplace 6 .....................

3.3 Prefabricated Chimneys............................................... 7

4. Clearances to Combustibles

4.1 Floor Protection............................................................. 7

4,2 Clearances to Walls and Ceilings 7 .................................

4.3 Using Shields to reduce Clearances 7- 8 ............................

4.4 Alcove Installation 8 ........................................................

4.5 Mobile Home Installation 8 ............................................

5. Operation

5.1 Combustion Eciency 9 .................................................

5.2 CO Emissions 9 ...............................................................

5.3 Wood Fuel and Performance .....................................9-10

5.4 Stove Control - Functions and Settings ....................10

5.5 Catalytic Combustor Monitor 10-11 ....................................

5.6 Break-in Procedure 11 .....................................................

5.7 Starting and Maintaining a Fire 11-12 ..................................

5.8 Creosote Formation and Removal 12 ..............................

5.9 Adding Fuel 12 ..................................................................

Standards

The Jøtul F 500 V3 Oslo solid fuel heater has been tested and listed

to ANSI/UL 1482-11 in the U.S. and

ANSI ULC-S in Canada.627-M20

Certiﬁed Safety Tests performed by

Intertek Testing Services, Middleton, WI U.S.A.

Manufactured by

Jøtul North America, Inc.

55 Hutcherson Drive

Gorham, Maine 04038, U.S.A.

6. Maintenance

6.1 Annual Stove Inspection 13 ..............................................

6.2 Ash Removal 13 .................................................................

6.3 Chimney System 13 .........................................................

6.4 Enamel Care 14 ................................................................

6.5 Glass Care/Glass Replacement 14 ...................................

6.6 Gaskets 14 .........................................................................

7. Accessories .......................................................... 15

8. Illustrations

Figures 16-21 ...................................................................................

Clearance Chart and Diagrams 22-23 ...........................................

9. Appendix

A. Catalytic Combustor Maintenance .............................. 24

Catalytic Combustor Replacement 25-26 ..............................

B. Alternate Floor Protection 27 ............................................

10. Warranty ...................................................................................... 28-30

WARNING !

THIS WOOD HEATER HAS A MANUFACTURER-

SET MINIMUM LOW BURN RATE THAT MUST

NOT BE ALTERED. IT IS AGAINST FEDERAL

REGULATIONS TO ALTER THIS SETTING

OR OTHERWISE OPERATE THIS WOOD

HEATER IN A MANNER INCONSISTENT WITH

OPERATING INSTRUCTIONS IN THIS MANUAL.

This heater meets the 2020 U.S.

Environmental Protection Agency’s

emission limits for wood heaters

manufactured after May 15, 2020.

NOTE: It is normal for a new, painted stove to

emit odor and smoke during initial ﬁres, depending

upon temperatures over time. This is caused by the

curing of high temperature paint and manufacturing

materials. This condition can be alleviated by

opening a window or door to provide additional

ventilation. See Break-in Procedure, Sect. 5.6 for

details.

This manual describes the installation and operation

of the Jøtul F 500 V3 catalytic equipped wood heater.

This heater meets the 2020 U.S. Environmental

Protection Agency’s crib wood emission limits for wood

heaters sold after May 15, 2020. Under speciﬁc test

conditions, this heater has been shown to deliver heat

at rates ranging from 13,000 to 37,000 Btu/hr.
