Jøtul F 55

Carrabassett

Installation and Operating

Instructions

for the U.S. and Canada

Jøtul F 55 Carrabassett

Wood Stove

The Jøtul F 55 Carrabassett non-catalytic stove

is listed to burn solid wood only. Do not burn

any other fuels.

Read this entire manual before you install

and use this appliance.

Save these instructions for future reference

and make them available to anyone using or

servicing the fireplace insert.

This wood heater requires periodic inspection

and repair for proper operation. See this

manual for specific maintenance information.

It is against federal regulations to operate

this wood heater in a manner inconsistent

with the operating instructions in this

owner’s manual.

139473_M F 55 1/20

Accessories

Stove Gloves, pair - #157363

Heavy-duty, flame-retardant with full gauntlet

Spark Screen - #157232

Enjoy the warmth of open door fire-viewing with use of

this custom fit spark screen.

Stove-Top Thermometer - #5002

We recommend the use of a magnetic stove-top

thermometer to monitor the surface temperature of the

stove. The optimum surface temperature range for the

most efficient performance is between 400

0 F - 7000 F

(2050 C - 3160 C).

Outside Air Kit - #157440

This kit includes a plenum assembly which attaches to

the stove bottom. It permits connection of duct work

from an outside source directly to the air intake of the

stove. A direct outside air connection is required for

mobile home installations.

Mobile Home Floor Bracket Kit - #157321

This kit includes two brackets used to fulfill the mobile

home requirement that the stove be secured directly to

the floor.

Blower Kit - #156431

This kit includes components for mounting a

thermostatically controlled 120 cfm blower to the back

of the stove to enhance heat convection into the living

area.

Gasket Kit - #157680

Includes enough gasket material to replace the glass

and door seals.

Installation and Operation

Instructions for USA/Canada

Safety Notice: If this solid fuel room heater is not properly

installed, a house fire may result. For your safety, follow the

installation directions. Contact local building or fire officials

about restrictions and installation inspection requirements

in your area. Save these instructions for future reference.

Table of Contents

Accessories ...................................................................................2

Standards and Safety Notices

Standards / Codes 3 ...........................................................................

Safety Notices 4 ..................................................................................

1.0 Installation

1.1. Pre-installation Assembly 5 ....................................................

1.2 Flue Collar Installation 6 ..........................................................

1.3 Flue Collar Heat Shield 6 ..........................................................

1.4 Chimney Connector 6 ...............................................................

2.0 Chimney Requirements

2.1 Masonry Chimneys 7 ...............................................................

2.2 Prefabricated Chimneys 7 .......................................................

2.3 Chimney Height 8 .....................................................................

2.4 Wall Pass-Throughs 8 ...............................................................

3.0 Connecting to the Chimney

3.1 Masonry Chimneys 9 ...............................................................

3.2 Hearthmount into a Masonry Fireplace 9 ...........................

3.3 Prefabricated Chimneys 10 .......................................................

3.4 Mobile Home Requirements 10 ..............................................

4.0 Clearances to Combustibles

4.1 Floor Protection 11 ......................................................................

4.2 Clearances to Walls and Ceilings 11 ........................................

4.3 Using Shields to Reduce Clearances 11 ..................................

4.4 Alcove Installation 12 .................................................................

4.5 Fireplace Clearances, Mantel and Trim ................................ 12

4.6 Clearance Diagrams 13 ..............................................................

5.0 Operation

5.1 Combstion Efficiency 14 .............................................................

5.2 CO Emissions 14 ...........................................................................

5.3 Wood Fuel and Performance 14 ...............................................

5.4 How Your F 55 Works 15 .............................................................

5.5 Controlling the Fire 15 ................................................................

5.6 Air Control / Blower Settings 15 ..............................................

5.7 Break-in Procedure 16 .................................................................

5.8 Starting and Maintaining the Fire 16 .....................................

5-9 Adding Fuel 17 ..............................................................................

5.10 Open Door Fire-viewing 17 .......................................................

5.11 Creosote and the Need for Removal .................................17

5.12 Ash Removal 17 ............................................................................

6.0 Maintenance

6.1 Door Latch 18 ................................................................................

6.2 Glass Care 18 .................................................................................

6.3 General Care 18 ............................................................................

6.4 Gasket Replacement 19 .............................................................

6.5 Glass Replacement 19 ................................................................

6.6 Chimney System 19 ....................................................................

7.0 Appendix

7.1 Blower Installation 20 ................................................................

7.2 Outside Air Kit Installation 22 .................................................

7.3 Mobile Home Floor Bracket 23 ................................................

8.0 Illustrated Part List ...........................................................25

9.0 Warranty Statement 26 ....................................................
