Jøtul F 55 V2 Carrabassett

Wood Stove

 The Jøtul F 55 V2 Carrabassett heater is listed

to burn solid wood only. Do not burn any

other fuels.

 Read this entire manual before you install

and use this appliance.

 Save these instructions for future reference

and make them available to anyone using or

servicing the fireplace insert.

 This wood heater requires periodic inspection

and repair for proper operation. See this

manual for specific maintenance information.

It is against federal regulations to operate

this wood heater in a manner inconsistent

with the operating instructions in this

owner’s manual.

This heater meets the 2020 U.S.

Environmental Protection Agency’s

emission limits for wood heaters

manufactured after May 15, 2020.

Une version française de ce manuel est disponible au

téléchargement sur www.jotul.ca

Jøtul F 55 V2

Carrabassett

Installation and Operating Instructions

for the United States and Canada

139009 F 55 V2 3/21

Accessories

Stove Gloves, pair - #157363

Heavy-duty, flame-retardant with full gauntlet

Stove-Top Thermometer - #5002

We recommend the use of a magnetic stove-top

thermometer to monitor the surface temperature of the

stove. The optimum surface temperature range for the

most efficient performance is between 400

F - 700

(205

C - 316

C).

Outside Air Manifold - #158208

This kit includes a plenum assembly which attaches to

the stove bottom. It permits connection of duct work

from an outside source directly to the air intake of the

stove. A direct outside air connection is required for

mobile home installations. This kit cannot be used with

the Short Leg Kit.

Mobile Home Floor Bracket Kit - #157321

This kit includes two brackets used to fulfill the mobile

home requirement that the stove be secured directly to

the floor.

Blower Kit - #156431

This kit includes components for mounting a

thermostatically controlled 120 cfm blower to the back

of the stove to enhance heat convection into the living

area.

Gasket Kit - #157680

Includes enough gasket material to replace the glass

and door seals.

Short Leg Kit - #158209

This kit includes four, 4 1/4’’ (108 mm) steel legs and a

Bottom Heat Shield which allow stove installation into

a fireplace opening height as low as 27 1/4’’. Approved

only for code-approved, masonry fireplace hearth mount

installation.

Installation and Operation

Instructions for USA/Canada

Safety Notice: If this solid fuel room heater is not properly

installed, a house fire may result. For your safety, follow the

installation directions. Contact local building or fire officials

about restrictions and installation inspection requirements

in your area. Save these instructions for future reference.

Table of Contents

Accessories ................................................................................... 2

Standards and Safety Notices

Standards / Combustion Specifications / Codes ..................... 3

Safety Notices ..................................................................................4

1.0 Installation

1.1. Pre-installation Assembly .................................................... 5

1.2 Flue Collar Installation ..........................................................5

1.3 Flue Collar Heat Shield .......................................................... 5

1.4 Short Leg Kit ............................................................................ 6

1.5 Leg Levellers .............................................................................6

1.6 Chimney Connector ...............................................................6

2.0 Chimney Requirements

2.1 Masonry Chimneys ............................................................... 7

2.2 Prefabricated Chimneys .......................................................7

2.3 Chimney Height ..................................................................... 8

2.4 Wall Pass-Throughs ...............................................................8

3.0 Connecting to the Chimney

3.1 Masonry Chimneys ............................................................... 9

3.2 Hearthmount into a Masonry Fireplace ........................... 9

3.3 Prefabricated Chimneys .......................................................10

3.4 Mobile Home Requirements ..............................................10

4.0 Clearances to Combustibles

4.1 Floor Protection ...................................................................... 11

4.2 Clearances to Walls and Ceilings ........................................ 11

4.3 Using Shields to Reduce Clearances ..................................11

4.4 Alcove Installation ................................................................. 12

4.5 Fireplace Clearances, Mantel and Trim ................................ 12

4.6 Clearance Diagrams .............................................................. 13

5.0 Operation

5.1 Combstion Efficiency ............................................................. 14

5.2 CO Emissions ........................................................................... 14

5.3 Wood Fuel and Performance ...............................................14

5.4 How Your F 55 Works ............................................................. 15

5.5 Controlling the Fire ................................................................ 15

5.6 Air Control / Blower Settings .............................................. 15

5.7 Break-in Procedure ................................................................. 16

5.8 Starting and Maintaining the Fire ..................................... 16

5-9 Adding Fuel .............................................................................. 17

5.10 Creosote and the Need for Removal .................................17

5.11 Ash Removal ............................................................................ 18

6.0 Maintenance

6.1 Door Latch ................................................................................18

6.2 Glass Care .................................................................................18

6.3 General Care ............................................................................ 19

6.4 Gasket Replacement ............................................................. 19

6.5 Glass Replacement ................................................................ 19

6.6 Chimney System .................................................................... 19

7.0 Appendix

7.1 Blower Installation ................................................................20

7.2 Outside Air Kit Installation ................................................. 22

7.3 Short Leg Kit Installation ..................................................... 22

7.4 Mobile Home Floor Bracket ................................................ 23

7.5 Aternate Floor Protection.. ................................................... 23

7.6 Secondary Air Manifold Maintenance .............................. 24

7.7 F55 V2 Start-Up and Refueling ........................................... 25

8.0 Illustrated Part List ............................................................ 26

9.0 Warranty Statement .................................................... 28
