JT- DMSO2D72

Portable 3 one oscilloscope, signal generator and multimeter-in-

1. GENERAL INFORMATION

Dear customer,

Thank you for choosing our product. Please read the following im-

portant information before putting the device into operation.

This oscilloscope is compact, portable and flexible. It has a TFT-LCD

color display with a resolution of 320 x 240 pixels and adjustable

backlight brightness.

The maximum real time sampling rate can be up to 250 MSa/s. USB

memory devices are also supported, the user can upgrade the firm-

ware via USB, the edge trigger function is automatically detected and

it has a user defined fast oset calibration with A/D converter that -

can sample each channel simultaneously.

2. SAFETY INSTRUCTIONS

Safety Terms and Symbols:

following terms may appear on product:

Danger It represents that harms may be caused to you at once if you per-

form the operation.

Warning It represents that latent harms may be caused to you if you per-

form the operation.

Notice It represents that damage may possibly caused to the product or

other properties if you perform the operation.

Symbols on the product: following symbols may appear on product:

General Safety Summary

Read the following safety precautions to avoid injury and prevent damage

to this product or any products connected to it. To evade potential haz-

ards, use this product only as specified.

Only qualified personnel should perform maintenance.

Use suitable power cord. Use only the power cord specified for this prod-

uct and certified for the country of use.

Connect and disconnect properly. Connect a probe with the oscilloscope

before it is connected to measured circuits; disconnect the probe from the

oscilloscope aer it is disconnected from measured circuits.

Ground the product. This product is grounded through the grounding

conductor of the power cord. To avoid electric shock, the grounding con-

ductor must be connected to earth ground. Before making connections to

the input or output terminals of the product, ensure that the product is

properly grounded.

Notice

Please read

the manual

Protective

ground

terminal

Measuring

ground

terminal

Chassis

ground

terminal
