LK-BASE-RB
Baseboard for Raspberry Pi
1. GENERAL INFORMATION
Dear customer,
thank you for choosing our product. In the following, we will show you how
to use your product.
Should you encounter any unexpected problems during use, please do not
hesitate to contact us.
application of LinkerKit products directly with the Raspberry Pi. It is
equipped with the common UART and I2C interfaces as well as up to 12
digital and 4 analog LinkerKit products.
2. PINOUT
In the following picture is a detailed connection diagramm which shows the
dierent slots of the LinkerKit baseboard module.
Digital GPIO
D2 - GPIO 2
D3 - GPIO 3
:
22 - GPIO 22
25 - GPIO 25
:
D27 - GPIO 27
UART
1 - RXD
2 - TXD
3 - V+
4 - GND
Analog inputs
A0 - analog channel 0
A1 - analog channel 1
A2 - analog channel 2
:
:
A7 - analog channel 7
I2C
1 - SCL
2 - SDA
3 - V+
4 - GND
voltage switch
for V+
position 1-2: 3.3 V
position 2-3: 5 V
