Side 1/8

www.joy-it.net

Pascalstr. 8 47506 Neukirchen-Vluyn

CASE CLAMP FOR VESA– AND DIN

RAIL MOUNT

RB-Mount3

2. GENERAL INFORMATION

Dear customer,

Thank you for purchasing our product. In the following, we will show you

which things should be noted during the use.

Should you encounter any unexpected problems, do not hesitate to

contact

us.

The housing clamp makes it possible to mount various small housings (e.g.

single board computers, microcontrollers, etc.) on DIN rails (TH35) and

VESA75 and VESA100 mounts.

1. TABLE OF CONTENTS

1. Table of Contents

2. General information

3. Scope of delivery

4. Assembly

5. DIN rail mount

6. VESA mount

7. Other information

8. Support

www.joy-it.net

Pascalstr. 8 47506 Neukirchen-Vluyn

3. SCOPE OF DELIVERY

2x case clamp

2x VESA adapter

1x mounting plate

1x adhesive rubber

4x M3 x 5mm stando

4x screw M3 x 16 mm

4x screw M3 x 5 mm

4x countersunk screw M3 x 5 mm

2x countersunk screw M2.5 x 10 mm

ATTENTION:

The screws for mounting on the VESA device are not included due to die-

rent designs.

Produkt Specifikationer

Mærke:	Joy-It
Kategori:	Ikke kategoriseret
Model:	RB-Mount3
Produktfarve:	Sort
Materiale:	Aluminium
Montering interface kompatibilitet (min.):	75 x 75 mm
Montering interface kompatibilitet (maks.):	100 x 100 mm
