Side 1/11

B 80 W

Walk-behind scrubber drier (80 l) with traction drive. Ideal for 1,500-3,000 m². Conguration

example with disc brushes with sweeping function and 75 cm working width.

CONFIGURABLE

Cer tiﬁed

R A C LEA N ENV I RO N M E NT

CLEANING EFFICIENCY

Acc . I EC / E N 62885-9 a n d T S EU C l 35000

Green

Cleaning

Choice of four batteries



Battery types: maintenance-free 170 Ah (C5) with eece technology,

maintenance-free 180 Ah (C5), low-maintenance 180 Ah (C5) or

maintenance-free 240 Ah (C5).



The charge curve of the built-in charger is perfectly adapted to the

different battery types.

Convenient Auto Fill function



Time-saving lling of the fresh water tank.



Filling via the fresh water hose stops automatically when the tank is

full.

Automatic lowering and raising of the brush head and

squeegee



Brush head and squeegee are lowered automatically depending on

the selected cleaning programme.



Practical: squeegee is raised automatically when reversing.

Brush head with disc engineering



With 65 or 75 cm working width.



Simple operation: unlocking the brush via foot pedal, locking by

lowering the machine or clipping in manually.

B 80 W, 1.259-010.2, 2022-02-08

TECHNICAL DATA AND EQUIPMENT

B 80 W

Technical data

Order no. 1.259-010.2

EAN code 4039784590106

Current type V / Hz 100 – 240 / 50 – 60

Working width, vacuuming mm 940

Max. area performance m²/h 4500

Fresh/dirty water tank l 80 / 80

Brush contact pressure g/cm² 28

Brush rotational speed rpm 210

Rated input power W max. 2200

Weight (with accessories) kg 133

Dimensions (L × W × H) mm 1617 × 810 × 1154

Battery voltage V 24

Battery capacity Ah 240

Battery runtime h max. 4

Equipment

Disc brush



Fact –

Tin –

Powerful traction drive



Battery charger



2-tank system



Motor Battery



Included in the scope of supply.

Produkt Specifikationer

Mærke:	Kärcher
Kategori:	Ikke kategoriseret
Model:	B 80 W
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 / 60 Hz
Bredde:	1617 mm
Dybde:	810 mm
Højde:	1154 mm
Vægt:	133000 g
Batterispænding:	24 V
Batterikapacitet:	240 At
Vægt (inkl. batteri):	316000 g
Støjniveau:	61 dB
Maksimal indgangseffekt:	2200 W
Maksimal ydeevne:	3000 m²/t
Spildevandsbeholder volumen:	80 L
Kapacitet for ferskvandstank:	80 L
Trækkraftmotor:	575 W
Børste rotationshastighed (min.):	210 rpm
Børste kontakttryk (min.):	28 g/cm²
