English
Quick start guide
Operating temperature, protection of the instruments and information about storage and the battery
1 Device description
•
Operating temperature: 0 to +50 °C (+32 to +122 °F)
• IP 54
• Storage temperature: -20 to +80 °C (-4 °F to +176 °F)
The MP 210 micromanometer measures pressure, air velocity, airow,
temperature, tachometry, gas leak and carbon monoxide (up to 6 simultaneous
measurements).
If the instrument is stored outside the operating temperature (for example in a van, a
warehouse,...) please wait for 10 minutes in its operating temperature before starting and using it.
Rechargeable Li-ion battery inside the instrument, 16 h battery-life with a pressure module or 14h
a hotwire probe. The instrument is supplied with a 5 V, 1 A power adapter to load the internal
battery. The current loading is indicated by a battery symbol on the top left of the screen. The
orange led on the bottom of the instrument is also on until the full loading of the battery (the led
turns green).
1. Battery level
2. Date and time
3. Home screen
4. Measurement menu
5. Dataset menu
6. Conguration menu
7. Information menu
8. Function keys
9. OK button
10. Navigation arrows
11. ESC button
12. On/Off button
Directive 2014/53/EU
Hereby, Sauermann Industrie SAS declares that the radio equipment type AMI 310 is in compliance
with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the
following internet address: www.sauermanngroup.com
1
1
2
3
4
1. Module
2. Location to remove the module
3. Battery
4. Probe handle
1
2
1. USB connection + power supply
2. Light indicator for battery charging
2 Connections
3 Set language
OK
Press Up and Down
arrows to select the
required language:
FRA, ENG
4 Use of the probes
Connect a probe
Connect the mini-DIN cable on the mini-DIN connection of the probe.
Connect the mini-DIN cable with the probe on the instrument.
A beep indicates that the operation has been correctly performed.
Special precautions for air velocity probes
Before any use of the device
with an air velocity probe,
please lower the protective
tube (1) of the sensitive
element (except vane probe).
Always use the standard air
velocity probe with the red
point in front of the ow.
Always use the telescopic
probe with the white point in
front of the ow.
1
2
3
4
5
6
7
8
9
10
11 12
1
2
OK
1. Mini-DIN C2 connection
2. Mini-DIN C1 connection
