Side 1/8
8559765A
Kitchen Faucets
®
HOME APPLIANCES
Installation Instructions and
Use and Care Guide
Model Series
KKFV01LP
Model Series
KKFV01SP
Model Series
KKFV01PP
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
IMPORTANT:
Installer: Leave installation instructions with the homeowner.
Homeowner: Keep installation instructions for future reference.
2
1. Before installing the faucet, flush water supply pipes
thoroughly. Shut off water supply valves.
2. Remove nut, metal washer and rubber washer from faucet.
Do not remove rubber o-ring in bottom of faucet base.
3. Feed tubing through hole in sink or countertop and then insert
faucet assembly into hole.
4. Reinstall the parts onto the threaded shank of the faucet in
the following order: rubber washer, plastic base, metal washer
and nut. Hand-tighten nut.
5. Align faucet and securely hand-tighten the nut to prevent
faucet base from turning when moving operating lever. For
Model series KKFV01SP and KKFV01PP, be sure the control
lever is pointed toward the right side of the sink.
A
B
C
A
C
B
D
INSTALLATION
REQUIREMENTS
INSTALLATION
INSTRUCTIONS
Tools and Parts
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Tools needed
■Adjustable wrench
■Slip joint pliers
■#2 Phillips screwdriver
■Basin wrench (optional)
Tools needed
Remove parts from carton. Check that all parts are included.
All models:
■Faucet assembly
■Plastic base
■⁵⁄₆₄" (2 mm) Allen wrench
Model series KKFV01SP & KKFV01PP:
■Weights
■Check valve assembly
– 2 fiber seals
Location Requirements
IMPORTANT: Observe all governing codes and ordinances.
■Check location where faucet will be installed. Proper
installation is your responsibility. Make sure you have
everything necessary for correct installation. It is the
responsibility of the installer to comply with installation
specifications and with state and local plumbing codes.
Protect faucet and water lines leading to faucet against
freezing. Damage from freezing is not covered by the warranty.
■Faucet requires a 1 " (3.5 cm) diameter opening in sink or³⁄₈
countertop. If hole is not available for mounting it is
recommended that a qualified installer be contacted to drill the
hole for your installation in a sink deck or countertop.
Thickness of sink or countertop hole must not exceed 1³⁄₄"
(4.4 cm).
■Hot and cold water supply lines must be available and if they
are not it is recommended that a qualified plumber install the
necessary piping.
■Faucet hoses are equipped with compression type seals and
do not require sealing compounds to prevent leaking.
■As with all metal objects, follow proper handling techniques.
■It is recommended that a qualified plumber/installer install the
faucet. The faucet installation must comply with national and
local plumbing codes and ordinances.
■The faucet should be examined for damage prior to
installation. Do not install a damaged faucet. Instead, return
the faucet to the dealer from whom you purchased it. Failure
to do so will void the warranty.
A. Rubber washer
B. Metal washer
C. Nut
A. Rubber washer
B. Plastic base
B. Metal washer
C. Nut
