Side 1/8
W11039684A
INSTALLATION INSTRUCTIONS ELECTRIC
BUILT‑IN MICROWAVE OVEN SPACER KIT
INSTRUCTIONS D’INSTALLATION TROUSSE
D’ENTRETOISE POUR FOUR À MICRO‑ONDES
ÉLECTRIQUE ENCASTRÉ
Built-In Spacer Kit
Trousse d’entretoise pour four
encastré
Dimensions et couleur
UL Listed for Model Numbers
Homologation UL pour les
modèles numéro
W10469901 27" (68.6 cm), stainless steel
27" (68,6 cm), acier inoxydable
KMBP107ESS
W10842584 27" (68.6 cm), limited edition black
27" (68,6 cm), edition limitee en noir
KMBP107EBS
W10469903 30" (76.2 cm), stainless steel
30" (76,2 cm), acier inoxydable
KMBP100ESS
W10842586 30" (76.2 cm), limited edition black
30" (76,2 cm), édition limitée en noir
KMBP100EBS
Table of Contents/Table des matières
BUILT-IN MICROWAVE OVEN SAFETY 1 ..................................
INSTALLATION REQUIREMENTS 2 ..........................................
Tools and Parts 2 ....................................................................
Location Requirements 2 .......................................................
INSTALLATION INSTRUCTIONS 3 ...........................................
Assemble Spacer Kit 3 ............................................................
Install Spacer Kit 3 ..................................................................
Install Microwave Oven 3 ........................................................
Complete Installation 4 ...........................................................
SÉCURITÉ DU FOUR À MICRO-ONDES ENCASTRÉ 5 ...........
EXIGENCES D’INSTALLATION 6 ..............................................
Outillage et pièces 6 ................................................................
Exigences d’emplacement 6 ...................................................
INSTRUCTIONS D’INSTALLATION 7 ........................................
Assemblage de la trousse d’entretoise 7 ................................
Installation de la trousse d’entretoise 7 ...................................
Installation du four à micro-ondes........................................ 7
Achever l’installation 8 ............................................................
BUILT‑IN MICROWAVE OVEN SAFETY
You can be killed or seriously injured if you don't immediately
You
can be killed or seriously injured if you don't
follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
2
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools
listed here.
Tools needed
■Phillips screwdriver
■¼" (6.3 mm) hex
opening screwdriver
■Measuring tape
Parts supplied
A. Spacer bars (2)
B. Bottom vent (1)
C. ³⁄
8
" hex washer head screws (4)
D. ¾" pan head screws (4)
Location Requirements
IMPORTANT: Observe all governing codes and ordinances.
■Cabinet opening dimensions that are shown must be
used. Given dimensions provide minimum clearance
with microwave oven.
■Recessed installation area must provide complete enclosure
around the recessed portion of the microwave oven.
■Microwave oven support surface must be solid, level, and
flush with bottom of cabinet cutout. Floor must be able to
support a weight of 90 lbs (41.0 kg).
IMPORTANT: To avoid damage to your cabinets, check with
your builder or cabinet supplier to make sure that the materials
used will not discolor, delaminate, or sustain other damage.
This oven has been designed in accordance with the
requirements of UL and CSA International and complies
with the maximum allowable wood cabinet temperatures
of 194°F (90°C).
Product Dimensions
27" (68.6 cm) and 30" (76.2 cm) Microwave Oven Spacer Kits
27" (68.6 cm) models
A. 26³⁄
4
" (67.9 cm) overall width
30" (76.2 cm) models
A. 29³⁄
4
" (75.6 cm) overall width
Cabinet Dimensions
27" (68.6 cm) and 30" (76.2 cm) Microwave Oven Spacer Kits
27" (68.6 cm) models
A. 27" (68.6 cm) min. cabinet
width
B. 20
7
⁄
16
" (51.9 cm) bottom of
cutout to bottom of upper
cabinet door
C. 40" (101.2 cm) bottom of
cutout to floor (recommended)
D. 25¹⁄
2
" (64.8 cm) cutout width
E. 1¹⁄
2
" (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 19
7
⁄
16
" (49.4 cm) recommended
cutout height (will fit cutout
height from 19¼" [48.9 cm] to
19¹¹⁄
16
" [50.0 cm])
G. 21
7
⁄
8
" (55.5 cm) min. cutout
depth
30" (76.2 cm) models
A. 30" (76.2 cm) min. cabinet
width
B. 20
7
⁄
16
" (51.9 cm) bottom of
cutout to bottom of upper
cabinet door
C. 40" (101.2 cm) bottom of
cutout to floor (recommended)
D. 28¹⁄
2
" (72.4 cm) cutout width
E. 1¹⁄
2
" (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 19
7
⁄
16
" (49.4 cm) recommended
cutout height (will fit cutout
height from 19¼" [48.9 cm] to
19¹¹⁄
16
" [50.0 cm])
G. 21
7
⁄
8
" (55.5 cm) min. cutout
depth
A
B
C
D
A
A
B
C
D
E
F
G
■Level
■Drill
■¹⁄
8
" (3.2 mm) drill bit
