Reference Series

Owner's Manual

IMPORTANT SAFETY INSTRUCTIONS!

1. READ these instructions.

2. KEEP these instructions.

3. HEED all warnings.

4. FOLLOW all instructions.

5. DO NOT use this apparatus near water.

6. CLEAN ONLY with dry cloth.

7. DO NOT block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other appara-

tus (including ampliﬁers) that produce heat.

9. ONLY USE attachments/accessories speciﬁed by the manufacturer.

10. USE only with a cart, stand, tripod, bracket, or table speciﬁed by the manufacturer,

or sold with the apparatus. When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

11. DO NOT expose this apparatus to dripping or splashing and ensure that no objects ﬁlled with

liquids, such as vases, are placed on the apparatus.

The exclamation point, within an equilateral triangle, is intended to alert the user to

the presence of important operating and maintenance (servicing) instructions in the

literature accompanying the product.

The lightning ﬂash with arrowhead symbol within an equilateral triangle, is intended

to alert the user to the presence of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufﬁcient magnitude to constitute a risk of

electrical shock to persons.

WARNING: To reduce the risk of ﬁre or electrical shock, do not expose this apparatus to rain or moisture.

WARNING: No naked ﬂame sources – such as candles – should be placed on the product.

UNPACKING

All Models

• Open one end of the carton, attach outrigger feet as shown in Figure 2, invert

the speaker and pull the carton off of the loudspeaker. (See Figure 1.)

• Remove all inner packing, including plastic bags, and re-install the grille on

the front of the cabinet.

Inspect the loudspeaker for shipping damage. If damage has occurred, notify your

Klipsch dealer or the responsible transit company. Retain all packaging for future use.

Floorstanding Models

Floorstanding models are supplied with foot spikes to enhance performance on

carpeted ﬂoors.

• Invert the speaker on a carpeted surface and screw the spikes into the

threaded bushings in the bottom of the feet. Use caution when turning the

speaker upright as the spikes are sharp! (See Figure 2.)

• Use an assistant to lift the speaker into position.

• Adjust individual spike length to level the speaker after positioning.

Bookshelf, Center and Surround Models

These models are supplied with self-stick rubber feet to prevent surface damage.

(See Figure 2 for proper application.)

ROOM PLACEMENT

Your Reference loudspeakers will perform well in a variety of locations, but best

results will be achieved using the following guidelines:

Front Left and Right Speakers (See Figures 3 and 4.)

• Place on a common wall 6 to 15 feet apart.

• If used in a home theater system, position the speakers

ﬂanking your video display.

• Position them equidistant from the back wall.

• Position them at the same height above the ﬂoor (for non-ﬂoor standing

models) with the high frequency drivers at seated ear height.

• Angle speakers toward the listener and even with or forward of any adjacent

obstructions.

• Placing them near a corner or wall provides the greatest

amount of bass while moving the speakers away from room boundaries

reduces bass energy.

• Asymmetrical placement of a pair of speakers from adjacent side walls can

smooth room-induced bass unevenness.

• Bookshelf models may be placed on shelves or optional ﬂoor stands.

• Experiment with the above guidelines to suit your taste and to compensate for

your room’s acoustic characteristics.

Center Channel Speakers (See Figures 4 and 6.)

• Place immediately above or below center of your video display.

• These models are supplied with a tilt rod to compensate for placements

above or below seated ear height.

• Use the supplied self-stick rubber pads to cover the threaded bushing holes

(2) if the tilt rod is not used. (See Figure 6.)

Surround Channel Speakers (See Figures 3 and 4.)

• Place approximately 2 feet above the listening position (Typically this will be

about 5-7 feet above the ﬂoor.)

• The surrounds should be placed on the walls directly adjacent to the listening

position. Another option would be on the wall behind the listening position.

• The ﬁnal surround speaker placement depends on your room’s characteristics.

• Use the attached wall bracket to hook to an appropriately sized screw head

screwed into a wall stud or wall anchor with a suitable weight bearing

capacity. (See Figure 4.)

• See your Klipsch dealer for optional, adjustable wall mounts if required. These

mounts utilize the threaded bushings on the rear of the cabinet.

CAUTION! Never use the attached wall bracket for mounting the

speaker to the ceiling!

CONNECTING

CAUTION! Turn your ampliﬁer off before making any

connections.

Your loudspeakers are equipped with positive (Red) and negative (Black) connection

terminals on the rear of the cabinet. These correspond to the positive and negative

terminals on the appropriate channel (left, right, center, rear etc.) of your ampliﬁer.

Standard Connections (See Figure 5.)

• Some Reference speakers come with dual binding posts that are connected

by a metal strip. Do not remove this strip or your speakers will not function

correctly. Keep this strip in place and connect your speaker wire to the top

set of the binding posts. It is possible to “Bi-wire” a speaker that has two sets

of binding posts. Please see your receiver’s manual for further instructions.

• All speakers in your system must be connected in phase with the positive

speaker terminal connected to the positive ampliﬁer terminal. Repeat this

for the negative speaker terminal and ampliﬁer terminals. Most speaker

wire has distinguishing markings on the insulation of one of the conductors

to assist in correct hookup.

C A U T I O N

RISK OF ELECTRIC SHOCK.

DO NOT OPEN.

WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this

equipment are hazardous to life. No user-serviceable parts inside.

Refer all servicing to qualified service personnel.
