REFERENCE

RF-7, RF-5, RC-7, RS-7

SERIES

OWNER’S MANUAL

IMPORTANT SAFETY INSTRUCTIONS

1. READ these instructions.

2. KEEP these instructions.

3. HEED all warnings.

4. FOLLOW all instructions.

5. DO NOT use this apparatus near water.

6. CLEAN ONLY with dry cloth.

7. DO NOT block any ventilation openings. Install in accordance with the manufacturer's instructions.

8. DO NOT install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce heat.

9. DO NOT defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two

blades with one wider than the other. A grounding type plug has two blades and a third grounding

prong. The wider blade or the third prong are provided for your safety. If the provided plug does not fit

into your outlet, consult an electrician for replacement of the obsolete outlet.

10.

PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

11. ONLY USE attachments/accessories specified by the manufacturer.

12. USE only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the

apparatus. When a cart is used, use caution when moving the cart/apparatus combination to

avoid injury from tip-over.

13. UNPLUG this apparatus during lightning storms or when unused for long periods of time.

14. vicing is required when the apparatus hasREFER all servicing to qualified service personnel. Ser

been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does

not operate normally, or has been dropped.

This symbol indicates that there are important operating and maintenance instructions in the literature

accompanying this unit.

This symbol indicates that dangerous voltage constituting a risk of electric shock is present

within this unit.

WARNING: To reduce the risk of fire or electrical shock, do not expose this apparatus

to rain or moisture.

WARNING: Voltages in this equipment are hazardous to life. No user-serviceable parts inside. Refer all

ser

vicing to qualified ser

vice personnel.

CAUTION: Changes or modifica

tions not expressl

y a

pproved b

y the manufacturer could void the users

authority to opera

te this device.

POSITIONING YOUR REFERENCE SERIES SPEAKERS

Before You Start

— Some Klipsch speakers have feet and other accessories that may need to be

installed prior to use. Please refer to Diagrams 1, 2, and 3 for installation.

FOR MAXIMUM STABILITY AND SAFETY THE INCLUDED OUTRIGGER FEET MUST BE INSTALLED.

Left and Right Main Channel Speakers — For optimum performance, place your speakers six to 15 feet

(2 to 4.5m) apart and at least 24 inches (60.8cm) from the back and side walls. They may also be

toed-in slightly for better stereo imaging. The listening position should be about 1 to 1.5 times the dis-

tance separa

ting the speakers.

Refer to Figures 1 and 2 f

or connection and placement.

Center Channel Speakers — Center channel speakers are designed to place dialogue and primar

sounds so tha

t they appear to come from the video screen. The speakers should therefore be placed as

close to the screen as possible, preferably directly on top of or below the screen. Refer to Figures 2 and

3 f

or placement.

Rear Surround Channel Speakers — Klipsch WDST™ surround speakers should be placed on the walls

directly adjacent to or on the wall behind the listening position. They are designed to recreate the sense

of space and ambience that many of today’s surround sound technologies provide. Refer to Diagram 4

and Figures 2 for placement.

CONNECTING YOUR REFERENCE SERIES SPEAKERS TO YOUR AMPLIFIER

Conventional Connection — Using 16-gauge or larger speaker wire, connect the RED "positive" (+) ter-

minal of the LEFT speaker to the RED "positive" (+) terminal of your amplifier’s LEFT channel. Connect

the BLACK "negative" (–) terminal of the LEFT speaker to the BLACK "negative" (–) terminal of your

amplifier’s LEFT channel. Repeat this procedure for connecting all remaining speakers to the appropri-

ate amplifier channels. Refer to Figure 4 and 6. Make sure that no bare wires from any of the connec-

tions touch any other terminals as this could cause a short and damage your equipment. Some

Reference models have two sets of input terminals connected by wire jumpers. For conventional con-

nection, leave these jumpers in place, and use either set of terminals.

Bi-wire Connections — Some Reference models ha

ve the capability to be bi-wired. These speakers

ve two sets of input terminals connected by wire jumpers. Bi-wiring requires using two separate

speaker wires f

or each speaker. The RED "positive" (+) leads of both LEFT channel wires are tied

together and inserted into the same RED "positive" (+) terminals of the amplifier’

s LEFT channel. On the

LEFT speaker, the wire jumpers are removed. One of the two speaker wires is connected to the top set

of terminals (RED to RED and BLACK to BLACK) while the other speaker wire is connected to the lower

set of terminals in the same manner. Refer to Figure 5. Klipsch recommends this method of hook-up for

improved bass response, imaging and detail. For more information on how to bi-wire your speakers, see

your dealer or visit www.klipsch.com.

Amplifier Requirements — Klipsch speakers are highly efficient and will operate easily on a wide variety

of amplifiers. All Klipsch speakers are 8-ohm compatible and can be driven to very high levels with low

distortion. Due to the high output levels Klipsch speakers are capable of reproducing, exercise caution

with the volume control. Excessive volume over long periods can permanently damage your hearing.

Overdriving your amplifier could also damage your speakers. Check with your dealer to make sure your

particular amplifier is best suited to your application. We want you listening for a lifetime.

CARE AND CLEANING OF YOUR REFERENCE SERIES SPEAKERS

Your speakers ha yl or real wood veneer finish thave a durable vin t should only require dry dusting or

cleaning with a damp cloth. Avoid the use of abrasive or solvent-based cleaners and harsh detergents.

The brush attachment of your vacuum or a slightly damp sponge should remove any dust from your

speaker grilles.

WARRANTY—U.S. AND CANADA ONLY

The

Warranty below is valid only for sales to consumers in the United States or Canada.

KLIPSCH, L.L.C. ("KLIPSCH") warrants this product to be free from defects in materials and work-

manship (subject to the terms set f

orth below) for a period of five (5) years from the date of pur-

chase. During the Warranty period, KLIPSCH will repair or replace (at KLIPSCH’s option) this prod-

uct or any defective parts (excluding electronics and amplifiers). For products that have electronics

or amplifiers,

the

arranty on those parts is f

or a

period of two (2) years from the da

te of purchase.

o obtain

arranty ser

vice,

please contact the KLIPSCH authorized dealer from which you pur-

chased this product.

If your dealer is not equipped to perf

orm the repair of your KLIPSCH product,

it can be returned,

freight paid, to

KLIPSCH for repair. Please call KLIPSCH at 1-800-KLIPSCH for instructions. You will need to ship

this product in either its original packaging or packaging affording an equal degree of protection.

Proof of purchase in the form of a bill of sale or receipted invoice, which is evidence that this

product is within the Warranty period, must be presented or included to obtain Warranty service.

This Warranty is invalid if (a) the factory-applied serial number has been altered or removed from

this product or (b) this product was not purchased from a KLIPSCH authorized dealer. You may call

1-800-KLIPSCH to confirm that you have an unaltered serial number and/or you purchased from a

KLIPSCH authorized dealer.

E N G -

RISK

ELECTRIC

SHOCK

DO NOT OPEN
