Kodak Ektar H35N Manual

Kodak Kamera Ektar H35N

Læs gratis den danske manual til Kodak Ektar H35N (2 sider) i kategorien Kamera. Denne vejledning er vurderet som hjælpsom af 23 personer og har en gennemsnitlig bedømmelse på 4.5 stjerner ud af 12 anmeldelser. Har du et spørgsmål om Kodak Ektar H35N, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/2

G E T T I N G S TA RT ED

1. Camera Back

2. Back Lock

3. Film Cassette Chamber

4. Film Rewind Shaft

5. Flash

6. Film Advance Wheel

7. Film Sprocket Wheel

8. Film Take-up Spool

9. Shutter Release Button

10. Film Counter

11. Viewfinder Eyepiece

12. Flash On/Oﬀ Wheel

13. Flash Ready Light

14. Film Rewind Button

15. Film Rewind Crank

16. Battery Compartment Cover

17. Lens

18. Camera Starp Holder

19. Star Filter Switch

20. Bulb Shutter

21. Tripod Hole

Quick Start

Guide

KODAK EKTAR H35N

Half Frame Film Camera

Please read this Guide carefully before using and

keep it with you for future reference.

1. Open the Camera Back (1) by releasing the Back Lock (2).

2. Place the film cassette into the Film Cassette Chamber (3),

ensuring that the hollow end of the film is inserted into the

Film Rewind Shaft (4).

3. When the cassette seats properly in place, draw out and

insert the leader of the film into the Film Take-up Spool (8).

4. Press the Shutter Release Button (9) once and roll the

Film Advance Wheel (6).

5. Make sure the film perforations are engaged with the teeth

of the Film Sprocket Wheel (7).

6. Close the Camera Back (1) after the film is loaded correctly.

7. Press the Shutter Release Button (9) once.

Repeat the steps until the Film Counter (10) displays “1”.

The Film Counter (10) indicates the number of exposures

of the film roll at the moment.

Loading Film

Using Flash

1. When shooting indoor or in a dim/cloudy environment, turn

on the flash by adjusting the Flash On/Oﬀ Wheel (12).

2. Wait until the Flash Ready Light (13) is on.

3. Turn the flash oﬀ while not in use.

IMPORTANT:

When the Flash is switched on and the Flash Ready Light turns red, flash will

be charged once. Flash will be released for the next photo.

If you don’t wish to have flash for the next photo, please switch the Flash

Wheel to the “Oﬀ” position.

1. Push open the Battery Compartment Cover (16).

2. Insert one AAA alkaline battery into the Battery Compartment

Cover (16) according to the + indication.

3. Close the Battery Compartment Cover (16).

Loading Battery

www.retopro.co/kodak

The Kodak and Ektar trademarks, Kodak logo and trade dress

are used under license from Kodak.

BATTERY WARNING:

Improper replacement of battery may present a risk of leakage or explosion,

and may cause personal injuries. Mistreated rechargeable battery may

present a risk of fire or chemical burn. Do not disassemble or expose the

battery to conducting materials, moisture or extreme heat. Do not use or

charge the battery if it appears to be leaking, discoloured, deformed, or in

any abnormalities. Do not leave the battery discharged or unused for an

extended period of time. Avoid extremely high or low temperatures during

use, storage or transportation of batteries. Battery life varies with usage.

Non-operational battery should be disposed according to local laws, or

dispose it in a waste bin for electronics if not governed by applicable laws or

regulations. Keep batteries away from children.

Using Star Filter

Using Bulb Shutter

1. Pushing the Star Filter Switch (19) up to apply the Star Filter.

2. Point the camera towards soft light sources such as light bulbs,

and light reflection on water, mirrors, glass surfaces, etc.

3. Press the Shutter Release Button (9) lightly to take a photograph.

4. After taking a photograph, roll the Film Advance Wheel (6) until it

stops rolling.

5. The Star Filter creates 4-beam flares on light spots when applied.

6. Push the Star Filter Switch (19) down while not in use.

1. Insert a tripod into the Tripod Hole (21) in order to stabilise

the camera during bulb photography.

2. Insert a cable release into the Bulb Shutter (20).

3. Press and hold the button of the cable release for the

duration of the shooting. As long as the button of the cable

release is pressed, the shutter remains open.

4. Roll the Film Advance Wheel (6) until it stops rolling to take

the next photo.

Recommendation: When applying the Star Filter, avoid facing strong light which

will result in big flares on the light spots.

Note: Please note that if the film is not advanced before/after using the

Bulb Shutter (20), double exposure will occur. Tripod and cable release

are excluded in the package.

1. Compose your picture by looking through the Viewfinder

Eyepiece (11).

2. Place the key object of your photo at least 1.5 metres

away from you.

3. Determine whether to turn the flash on.

4. Press the Shutter Release Button (9) lightly to take a

photograph.

5. After taking a photograph, roll the Film Advance Wheel

(6) until it stops rolling.

6. Repeat Step 1 to 5 to take the next photo.

Taking Photo Unloading Film

1. After taking the last photo, the Film Advance Wheel (6) will stop

to roll.

2. Press the Film Rewind Button (14) to release the film for rewinding.

3. Lift the Film Rewind Crank (15) and rotate it clockwise to rewind

the film.

4. Open the Camera Back (1) and take out the film for processing.

Note: 1 shot of KODAK EKTAR H35N yields 2 half frame photos. A 36-exp film

gives 72 half frame photos while a 24-exp film gives 48 half frame photos

Produkt Specifikationer

Mærke:	Kodak
Kategori:	Kamera
Model:	Ektar H35N
