Side 1/26
50-60Hz
VEIL WALL HUNG
We appreciate your commitment to Kohler quality. Please take a few minutes before you begin installation to
review this manual to become familiar with tools, materials and installation methods. If you encounter any
installation or performance problems, please don't hesitate to contact us. Thanks again for choosing Kohler Co.
Please follow instructions closely to avoid costly mistakes caused by improper installation. Cover and protect
the components and fittings at all times during installation. Flush the plumbing lines before initial use.
All information in this manual is based upon the latest product information available at the time of publication.
Kohler Co. reserves the rights to make changes in product characteristics, packaging or availability at any time
without notice.
Before continuing, please ensure there is no existing damage to the toilet and that there is suitable space for
installation with no interference with other bathroom fixtures such as shower door openings. Before proceeding
with installation, ensure there is ample room (approx 600mm) down each side of the pan to allow for servicing.
To prevent serious damage, do not use corrosive solutions (see back page for care and cleaning information).
Any use of non-recommended products could void the Kohler warranty.
This manual includes important care and cleaning information - please save these instructions.
The Kohler Veil Intelligent Toilet - Wall Hung (K-5402A-0) is WaterMark certified according to WMTS-051
Technical Specification for Plumbing and Drainage Products - Toilet Douche Seats.
Installation shall be in accordance with the Plumbing Code of Australia.
Hands-free flushing
Manual dual-flush option
Backflow prevention
Anti-impact, rust-proof, macromolecule water tank reduces the possibility of leakages.
Advanced water tank system is able to adjust 4.5/3 litre water discharge. To maintain the 4-star WELS rating,
switch off the Auto-flush option.
No influence on wall structure, superb sound-proof effectiveness.
Easy and quick installation saves time and labour.
Easy servicing, wall reconstruction is not required.
Sanitary system with no residual waste.
Super thin tank body saves installation space and is applicable for all thin mounting walls.
Kohler Co. O 2022ct 1
Preset water inlet level & flush volume
Suitable for either S-trap or P-trap installations
Adjustable toilet installation height
This product must be installed in accordance with the Plumbing Code of Australia (PCA), which requires
provision of a High-Hazard Backflow Prevention device (not supplied). Please consult with your plumber or
hydraulic consultant prior to installation
Each site must have High Hazard Backflow Prevention installed upstream of the installation. For domestic
installations, consult with a Licensed Practitioner (Plumber) before installation. For commercial applications,
refer to a Hydraulic Consultant before specification or installation.
2
Compared to traditional setups, the in-wall tank provides an easier and faster installation method, which
gives a more artistic and complete finish.
The greatest advantage of the in-wall tank is that the toilet installation is not limited to certain locations. It
can be hung almost anywhere which affords a far greater use of bathroom space.
19mm spanner or adjustable wrench
Blade
File
Hacksaw
Hex key
Impact drill
Level
Screwdriver
Rulers/measuring tape
Electrical tape + thread sealing tape
Electrical insulation conduits
Grease
Plug for bidet water supply
Screws/bolts to affix in-wall tank to wall frame and
bottom plate (not supplied). Recommend to use
M6x40 coach screws with appropriate washers.
1mm - 2.5mm hard cord should be reserved as power input during the wall construction. In the circuit, a 220V,
50Hz, 10A minimum Ground-Fault Circuit Interupter (GFCI) or Earth Leakage Circuit-Breaker (ELCB) is required. For
detailed positioning of the hard cord, see diagram below.
NOTE: S-trap installation shown as default. P-trap configuration is achievable by using a DN80 waste pipe connector.
Bidet water supply pipe
Bidet water supply connector
Pan with faceplate .......... 76395A-NA
Remote assembly ........... 1106433
Hydro-Tower 500 in-wall tank ..... 18647A-NA
Faceplate ..................................... 1229390
Kohler Co. O 2022ct
