Side 1/4

H1S216

UPRIGHT

FREEZER

KTUF88

User Manual

Please Read These Instructions Carefully Before Use!05/2023-v3

WARRANTY

Koolatron Corporation warrants that this product will be free from defects in materials or

workmanship under normal household use for a period of 1 year from the date of retail

purchase. During this time, defective products will be repaired or replaced at the discretion

of the retailer and/or Koolatron Corporation.

This warranty covers normal household usage and does not cover damage which occurs

in shipment or results from accident, misuse or abuse, unauthorized repair or alteration,

improper maintenance, commercial use, or use with a voltage converter or aftermarket

accessories. A Koolatron Master Service Centre must perform all warranty work.

WARRANTY AND SERVICE PROCEDURE

Keep your original, dated, sales receipt with this manual. If this product proves to

be defective within the warranty period, please contact Koolatron Corporation at

1-800-265-8456 (North America) or email service@koolatron.com for assistance.

www.koolatron.com

All specification are subject to change without notice.

Made in China

PARTS

1. Adjustable temperature control

2. Slide-out drawers

3. Leveling legs

4. Recersible door

back of freezer

INSTALLATION

1. Remove all packaging, including the foam between the condenser and cabinet on the outside of the

unit. Two or more people should move the freezer. Failure to do so can result in back orWARNING!

other injuries.

2. Remove all packaging and labels. If there is any glue residue rub a small amount of liquid dish soap

with your fingers then wipe with warm water and dry.

NOTE - Do not use any sharp instruments, rubbing alcohol, flammable fluids or abrasive cleaners to

remove tape or glue.

3. IMPORTANT! Let the freezer stand upright for approximately 2 hours before plugging into the power

source. This will reduce the possibility of a malfunction in the cooling system from handling during

transportation.

4. This freezer is designed to be free standing. It was not designed for recessed or enclosed area

installation.

5. Place your freezer on a floor that is strong enough to support the freezer when it is fully loaded.

6. Locate the freezer away from direct sunlight and sources of heat (stove, heater, radiator, etc). Direct

sunlight may affect the acrylic coating and heat sources may decrease cooling efficiency.

7. Ensure there is a minimum 20 cm (8") clearance on both sides,10 cm (4") at the back wall and 30

cm (12") above the unit for proper air circulation. NOTE: If you are installing your freezer next to a

fixed wall, leave sufficient space on the hinge side to allow for the door to swing open.

8. Level the freezer by adjusting the legs. Turn the leg clockwise to raise that side of the freezer or turn

counterclockwise to lower that side. While adjusting the legs, have someone push against the top

of the freezer to take some weight off the front leveling legs.

NOTE - To help with door closure, position legs with a 1/8" (3 mm) tilt to the back.

9. Do not use in any location not properly insulated or heated, e.g. garage etc. Your freezer was not

designed to operate in temperatures below 12.8°C (55°F). In extreme cold ambient temperatures

the freezer will not perform properly. Avoid locating the freezer in damp or moist areas. Excessive

moisture may cause frost to form quickly on the evaporator. This would require more frequent

defrosting of the freezer.

10. Make sure all shelves and other parts listed in the description of PARTS are in place.

11. Once the freezer has been plugged in (after 2 hours in the upright position), allow the freezer's

interior to cool for 2-3 hours before putting food into the compartments.

SPECIFICATIONS

IMPORTANT SAFEGUARDS

Power Requirements: AC 115V 60Hz 140W

Max. Setting (6): -24°C (-11.2°F) at 25°C (77°F) ambient air temp.

Min. Setting (1): 0°C (32°F) at 25°C (77°F) ambient air temp.

Before the appliance is used, it must be properly positioned and installed as per the instruc-

tion in the Installation section. To reduce the risk of fire, electric shock or injury, follow basic

precautions including the following:

1. Read all instructions before using the appliance.

2. Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an

adapter, and do not use an extension cord.

3. Do not place any other household appliances on top of the unit.

4. It is recommended that a separate circuit, serving only your appliance be provided. Use

receptacles that cannot be turned off by a switch or pull chain.

5. Never clean appliance parts with flammable fluids. Do not store or use gasoline or other

flammable vapors and liquids in the vicinity of this or any other appliance. The fumes can

create a fire hazard or explosion.

6. Failure to unplug the appliance during cleaning could result in electrical shock or personal

injury.

7. Do not connect or disconnect the plug when your hands are wet.

8. Do not operate any appliance with a damaged cord or plug or after the appliance malfunc-

tions or has been damaged in any manner. Return appliance for examination, repair or

replacement of any part of the freezer. See the Warranty section.

9. To ensure proper ventilation for your appliance, follow the instructions in the Installation

section for proper clearances. Choose a well-ventilated area with temperatures above 55°F

(13°C) and below 90°F (32°C).

10. Do not use outdoors.

11. The appliance should not be located next to ovens, grills or other sources of high heat.

12. It is important for the appliance to be leveled to work properly.

13. Never allow children to operate, play with or crawl inside the unit.

14. Do not use this appliance for other than its intended use

GROUNDED PLUG

• To reduce the risk of electric shock this appliance has a grounded plug (2 blades and 1 pin).

If the plug does not fit fully into the electrical outlet contact a qualified electrician. Do not

modify the plug in any way or use an adaptor.

• Use an exclusive wall outlet. Do not connect your freezer to extension cords or together

with any other appliance in the same wall outlet. If the power cord is too short, have a

qualified electrician or service technician install an outlet near the appliance.

DANGER - Risk of child entrapment

Before disposing of your appliance, ensure that the door(s) are removed. Shelves should

also be left in place to help avoid children climbing inside. Never allow a child to operate, play

with or climb inside the appliance.

Produkt Specifikationer

Mærke:	Koolatron
Kategori:	Fryser
Model:	KTUF88
