PAGE 1
302720
DPF-MRK-003 REV B 8/10/18
ROAD THUNDER SOUND BAR PLUS BY MTX, SATIN BLACK 2720
866 277 9598 | INFO@KURYAKYN.COM
454 COUNTY ROAD VV SOMERSET, WI 54025
KURYAKYN.COM
INSTALLATION INSTRUCTIONS
THANK YOU FOR CHOOSING KURYAKYN!
Protect yourself and others from possible injury and property damage or loss. Pay close attention to all instructions, warnings, cautions, and notices regarding the installation, use, and care of this product.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT IN POTENTIAL DEATH OR SERIOUS INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT IN MINOR OR MODERATE POTENTIAL INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN MAY NEGATIVELY AFFECT PRODUCT PERFORMANCE AND FUNCTIONALITY OR
DAMAGE THE PRODUCT ITSELF OR THE PRODUCT TO WHICH IT IS BEING ATTACHED.
YOU WILL ALSO NEED:
Metric Hex, Allen wrenches, pliers
THESE INSTALLATION INSTRUCTIONS CONTAIN IMPORTANT INFORMATION. ENSURE THE END USER RECEIVES THIS COPY AND IS AWARE
OF ITS IMPORTANCE FOR FUTURE USE.
WHEN CONNECTING POWER AND GROUND WIRES ENSURE THAT THE RED POWER WIRE IS FUSED AT THE POINT WHERE IT IS
CONNECTED TO THE VEHICLE’S BATTERY. FAILURE TO DO SO CAN RESULT IN DAMAGE TO THE VEHICLE IF A SHORT CIRCUIT DEVELOPS
BETWEEN THE VEHICLE CONNECTION POINT AND THE PRODUCT.
ENSURE THAT THE FOLLOWING PARTS HAVE BEEN INCLUDED IN THE KIT:
1 Road Thunder Sound Bar Plus with
Wire Harness
1 Hardware Kit, containing:
2 M6-1.0 X 35MM Button Head Hex Screws
2 Sound Bar Mounting Clamps 2 M6-1.0 Lock Nut w/Washers
2 7/8” Clamps 2 M6-1.0 X 11MM Cap Screw Hex Drive
2 1” Clamps 2 M6 Split Washers
2 1-1/8” Clamps 2 M4-0.7 X 10MM Set Screws
2 1-1/4” Clamps 1 2MM Allen Wrench
1 USB Rubber Plug Seal 1 10 Amp Mini Fuse
1 Transparent Film 1 T-Tap Quick Connect Female
4 Cable Ties
1” CLAMP
1-1/8” CLAMP
1-1/4” CLAMP
7/8” CLAMP
2MM ALLEN WRENCH
TRASNPARENT FILM
CABLE TIES
SOUND BAR
MOUNTING CLAMPS
ROAD THUNDER
SOUND BAR PLUS
WIRE HARNESS
10 AMP
FUSE
M6-1 X
35MM BHHS
USB RUBBER
PLUG SEAL
M6-1 X
11MM CSHD
SPLIT
WASHERS
SET
SCREWS
T-TAP QUICK
CONNECTS
M6-1
LOCK NUT
CHANGES OR MODIFICATIONS TO THIS UNIT NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER’S
AUTHORITY TO OPERATE THE EQUIPMENT.
