Side 1/20
LMb
Synthesized UHF Belt-Pack Transmitter
Featuring
Digital Hybrid Wireless®
Technology
US Patent 7,225,135
INSTRUCTION MANUAL
Rio Rancho, NM, USA
www.lectrosonics.com
Fill in for your records:
Serial Number:
Purchase Date:
Quick Start Steps
1) Install good batteries and turn power on (see pages
5 and 6).
2) Set compatibility mode to match the receiver (see
page 9).
3) Connect signal source and adjust input gain for
optimum modulation level (see page 9).
4) Set StepSize and frequency to match receiver (see
page 10). Also see receiver manual for scanning
procedure.
5) Turn on the receiver and verify RF and audio sig-
nals are present (see receiver manual).
LMb
LECTROSONICS, INC.
2
Consumer Alert for US Users - FCC Order DA 10-92
Most users do not need a license to operate this wireless microphone system. Nevertheless, operating this micro-
phone system without a license is subject to certain restrictions: the system may not cause harmful interference; it
must operate at a low power level (not in excess of 50 milliwatts); and it has no protection from interference received
from any other device. Purchasers should also be aware that the FCC is currently evaluating use of wireless mi-
crophone systems, and these rules are subject to change. For more information, call the FCC at 1-888- CALL-FCC
(TTY: 1-888-TELL-FCC) or visit the FCC’s wireless microphone website at www.fcc.gov/cgb/wirelessmicrophones.
To operate wireless microphone systems at power greater than 50mW, you must qualify as a Part 74 user and be
licensed. If you qualify and wish to apply for a license go to: http://www.fcc.gov/Forms/Form601/601.html
Table of Contents
Introduction 3 ............................................................................
About Digital Hybrid Wireless 3 ..............................................
Frequency Agility.................................................................. 3
Wide-Band Deviation 3 ...........................................................
Servo Bias Input and Wiring 3 ................................................
LMb Block Diagram 4 ..............................................................
DSP-controlled Input Limiter 4 ................................................
No Pre-Emphasis/De-Emphasis 4 ..........................................
Pilot Tone Squelch ............................................................... 4
Battery Installation 5 ................................................................
Belt Clips 5 ................................................................................
Operating Instructions 6 ..........................................................
Battery Status LED Indicators 6 ..............................................
Powering On in Operating Mode 6 ..........................................
Powering On in Standby Mode 7 ............................................
Powering Off 7 ........................................................................
Navigating Menus 7 ................................................................
Locking/Unlocking Changes to Settings............................... 7
Power Menu 7 .........................................................................
Selecting Programmable Switch Functions.......................... 8
Main Window Indicators ....................................................... 8
Selecting the Compatibility (Compat) Mode 9 .........................
Connecting the Signal Source 9 .............................................
Adjusting the Input Gain 9 .......................................................
Selecting Step Size 10 ............................................................
Selecting Frequency 10 ..........................................................
Selecting Frequency Using Two Buttons 10 ............................
Helpful Features on Receivers 10 ...........................................
About Overlapping Frequency Blocks 11 ................................
Selecting Audio Polarity (Phase) 11 ........................................
Adjusting LCD Backlight 11 ....................................................
RF ON/OFF on the Menu 11 ...................................................
Selecting Battery Type ....................................................... 11
Restoring Default Settings 11 .................................................
IR (infrared) Sync 11 ...............................................................
5-Pin Input Jack Wiring 12 .......................................................
Microphone Cable Termination
for Non-Lectrosonics Microphones 13 ............................
Input Jack Wiring for Different Sources 14 ............................
Compatible Wiring for Both Servo Bias Inputs
and Earlier Transmitters: .................................................... 14
Simple Wiring for Servo Bias Inputs ONLY: ........................ 14
Microphone RF Bypassing 15 .................................................
Line Level Signals 15 ..............................................................
Wiring Diagram for MI39A Instrument Cable 15 .....................
Accessories 16 .........................................................................
Troubleshooting 17 ...................................................................
Specifications and Features 18 ...............................................
Service and Repair 19 ..............................................................
Returning Units for Repair 19 .................................................
