Side 1/39

DWG.

No.

TRIG.

DR COMPLETED

도면 DR 완료

완료일 :

LG 전자 (주)

LG Electronics Inc.

UNIT SCALE N S

REVIEWED DESIGNED

RELATED DWG.

CHECKED APPROVED

안 은 주

14.07.15 14.07.15 14.07.16

곽 병 희

14.07.15

이 성 민 장 한 용

MODELING I

APPROVED

승인자

PREPARED

시방자

DATE

년/월/일

REF. NO.

시방 번호

REV. NO.

기호

REVISION DESCRIPTION

변경 사항

RELEASING THIS DRAWING

WITHOUT PERMISSION LG

Electronics SHOULD BE

ACCUSED ACCORDING TO THE

LAWS AND COMPANY RULES.

이 도면은 LG전자의 자산으로 불법

유출시 관계법과 회사규정에 의해 처벌됨.

PDF

ILLUSTRATOR

MFL67737699

MANUAL,OWNER’S

DRUM-EXPORT 1/1

MFL67737699

<< 주기 >>

1. 재질, 인쇄방법, 인쇄도수, 외곽치수등은 작업표에 준한다.

2. 인쇄내용, 문자크기 및 형상, 선의 굵기 등은 설계에서 제시된 FILM에 준함.

3. 외곽치수는 절단후 치수임.

4. 양산전에 설계 한도를 득할 것.

<< NOTES >>

1. Material, printing and exterier size are refer to work tables.

2. Printing, text size and line are based on LG design film.

3. Exterier size on the drawing is cutting line.

4. Before product controlled by criteria sample.

가

P/NO. 다

나

WORK

가

BRAND

WM5000H*A FH3C8CDYK*

나

MODEL

다

P/NO.

MATERIAL AND PRINTING DESCRIPTION

PRINTING DEGREE

LG MODEL 명

A**EEUS

SUFFIX

ENG/SPA

LANGUAGE

PAGE

TT-PJT 27”, EUS

수정 업체 : 지디피

양산처 : 남성기획

REMARK

SEC.

5. 본 부품에 금지물질이 포함되지 않도록 하고, 상세내용은 LG(63)-A-5501-34를 만족할 것

5. The part should not contain prohibited substances(Pb,Cd,Hg,Cr+6,PBB,PBDE)and details

should comply with LG standard of LG(63)-A-5501-34

SNOW WHITE 80g OFFSET 인쇄

MFL67737699

2 1 0

150 150

장 한 용안 은 주15.07.17EAGF700695인쇄내용 개선에 따른 인쇄내용 변경

장 한 용안 은 주15.07.21EAGF700823 인쇄내용 개선에 따른 변경

장 한 용안 은 주15.07.22EAGF700925인쇄내용 개선에 따른 변경 (호스그림 추가)

장 한 용안 은 주15.07.29EAGF701176제품무게 오기에 따른 수정

김 현 석안 은 주15.09.01EAGF900003인쇄내용 오기에 따른 인쇄내용 변경

김 현 석안 은 주15.10.07EAGFA00259인쇄내용 오기에 따른 인쇄내용 변경

김현석안은주2015.11.07EAGFB00312 Smart ThinQ에 TM추가

김현석안은주2015.12.28EAGFC00789DOE 내용 추가 및 odor issue 내용 추가

김현석안은주2016.02.24EAGG200983odor issue 내용 시카고랩 재감수

김현석이다정2016.09.27EAGG900843 Detergent Pod 관련 문구 추가, 스마트앱 명칭 변경

김 현 석이 다 정2016.10.27EAGGA00845 권장용량 문구 추가/ Tub Clean 문구 개선

김 현 석이 다 정2016.12.06EAGGC00208 모델명 추가/ FCC 문구 개정

김 현 석이 다 정2017.03.16EAGH300133 인쇄내용 수정

6IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USE

WARNING

For your safety, the information in this manual must be followed to minimize the risk of fire or explosion,

electric shock, or to prevent property damage, injury to persons, or death.

SAFETY INSTRUCTIONS FOR USE, CARE, CLEANING, AND DISPOSAL

WARNING

To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic

precautions, including the following.

SAVE THESE INSTRUCTIONS

• Unplug the washer before cleaning to avoid the risk

of electric shock.

• Never use harsh chemicals, abrasive cleaners, or

solvents to clean the washer. They will damage the

finish.

• Do not put oily or greasy rags or clothing on top of the

washer. These substances give off vapors that could

ignite the materials.

• Do not wash items that are soiled with vegetable or

cooking oil. These items may contain some oil after

laundering. Due to the remaining oil, the fabric may

smoke or catch fire by itself.

• Disconnect this appliance from the power supply

before attempting any user maintenance. Turning the

controls to the OFF position does not disconnect this

appliance from the power supply. Failure to follow

this warning can cause serious injury, fire, electric

shock, or death.

• Do not combine laundry products for use in one load

unless specified on the label.

• Do not mix chlorine bleach with ammonia or acids

such as vinegar. Follow package directions when

using laundry products. Incorrect usage can produce

poisonous gas, resulting in serious injury or death.

• Do not reach into the washer while parts are moving.

Before loading, unloading, or adding items, press the

START/PAUSE button and allow the drum to coast to a

complete stop before reaching inside. Failure to fol-

low this warning can cause serious injury, fire,

electric shock, or death.

• Do not allow children to play on or in the washer.

Close supervision of children is necessary when the

washer is used near children. As children grow, teach

them the proper, safe use of all appliances. Failure to

comply with these warnings could result in serious

injury to persons or death.

• Destroy the carton, plastic bag, and other packing

materials after the washer is unpacked. Children

might use them for play. Cartons covered with rugs,

bedspreads, or plastic sheets can become airtight

chambers. Failure to comply with these warnings

could result in serious injury to persons or death.

• Keep laundry products out of children’s reach. To

prevent injury to persons, observe all warnings on

product labels. Failure to comply with these warn-

ings could result in serious injury to persons or

death..

• Remove the door to the washing compartment to

avoid the danger of children or small animals getting

trapped inside before your washer is removed from

service or discarded. Failure to do so can result in

serious injury to persons or death.

• Make sure the dispenser lid is closed at all times

when not being filled with laundry products. Failure to

keep the lid closed can result in personal injury or

flooding.

Produkt Specifikationer

Mærke:	LG
Kategori:	Vaskemaskine
Model:	WM5005HKA
Vekselstrømsindgangsspænding:	120 V
Bredde:	686 mm
Dybde:	833 mm
Højde:	986 mm
Vægt:	95256 g
Produktfarve:	Sort
Kontroltype:	Buttons, Rotary, Touch
Motortype:	Bæltefri
Indbygget skærm:	Ja
Skærmtype:	LED
Strøm:	10 A
Pakkevægt:	105233 g
Pakkedybde:	844 mm
Pakkebredde:	742 mm
Pakkehøjde:	1076 mm
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Inverter-teknologi:	Ja
Ilægningstype:	Front-læsning
Tromlekapacitet:	- kg
Maksimal centrifugeringshastighed:	1300 rpm
Antal vaskeprogrammer:	14
Støjniveau (centrifugering):	- dB
Støjniveau (vask):	- dB
Forsinket start-timer:	Ja
Vaskeprogrammer:	Hygiene/anti-allergy, Cold, Cotton, Quick, Sport, Steam, Delicate/silk
Børnesikring:	Ja
Justerbare fødder:	Ja
Energiforbrug ved vask:	- kWh
Understøttede scanningstilstande:	1397 mm
Tromlemateriale:	Rustfrit stål
Tromle volumen:	127.5 L
Dør farve:	Sort
Certificering:	UL
Balance system:	Ingen
Wi-Fi kontrolleret:	Ja
Dispenser skuffetype:	4-vejs
Rense plus funktion:	Ja
Justerbar temperatur:	Ja
Justerbar centrifugeringshastighed:	Ja
Tromle indvendigt lys:	Ja
Tilføj tøj (pause) -funktion:	Ja
Lydalarm:	Ja
Døråbning diameter:	1029 mm
TurboWash:	Ja
LG-teknologier (tøjpleje):	Inverter Direct Drive Motor
