Liebherr FRTSrg 7531 Manual

Liebherr Ikke kategoriseret FRTSrg 7531

Læs gratis den danske manual til Liebherr FRTSrg 7531 (4 sider) i kategorien Ikke kategoriseret. Denne vejledning er vurderet som hjælpsom af 18 personer og har en gennemsnitlig bedømmelse på 4.3 stjerner ud af 9.5 anmeldelser. Har du et spørgsmål om Liebherr FRTSrg 7531, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/4
Installation Guide
Quality, Design and Innovation
home.liebherr.com/fridge-manuals
Contents
1 Assembly information........................................... 2
1.1 Connecting the appliance to an external unit or
to a central cooling system........................................ 2
1.2 Components.................................................................. 2
1.3 Minimum/power requirement for connecting a
single appliance........................................................... 2
1.4 Assembly procedure.................................................... 2
1.5 Electrical connection................................................... 3
1.6 Tests and checks.......................................................... 3
1 Assembly information
1.1 Connecting the appliance to an
external unit or to a central cooling
system
Note
You can only connect specially prepared version appli‐"r"
ances, such as FRTSrg, FFTRrg, to an external unit.
CAUTION
Health hazard due to escaping refrigerant/nitrogen!
Respiratory problems.
uMake sure that only trained refrigeration engineers
connect the appliance to an external unit or a central
cooling system.
CAUTION
Health hazard due to live parts!
Electric shock.
uBefore starting assembly work: Disconnect the power
plug.
1.2 Components
The following thermostatic expansion valves are installed:
-Cooler: Danfoss Thermostatic Expansion Valve TN2
068Z3384.
-Freezer: Danfoss Thermostatic Expansion Valve TN2
068Z3384.
1.3 Minimum/power requirement for
connecting a single appliance
Model Voltage Current
consumption
Power consump‐
tion
Cooler 220-240 V ~
50/60 Hz
4.02 A 840 W
Freezer 220-240 V ~
50/60 Hz
4.4 A 970 W
Model Cooling
capacity
Data
Cooler
Width:
1160 mm
519 W R452a refrigerant,
-10 °C evaporating tempera‐
ture,
Condensation temperature
+55 °C
Model Cooling
capacity
Data
Cooler
Width:
1640 mm
668 W R452a refrigerant,
-10 °C evaporating tempera‐
ture,
Condensation temperature
+55 °C
Cooler
Width:
2120 mm
668 W R452a refrigerant,
-10 °C evaporating tempera‐
ture,
Condensation temperature
+55 °C
Freezer
Width:
1160 mm
540 W R452a refrigerant,
-30 °C evaporating tempera‐
ture,
Condensation temperature
+55 °C
Freezer
Width:
1640 mm
540 W R452a refrigerant,
-30 °C evaporating tempera‐
ture,
Condensation temperature
+55 °C
Freezer
Width:
2120 mm
656 W R452a refrigerant,
-30 °C evaporating tempera‐
ture,
Condensation temperature
+55 °C
1.4 Assembly procedure
CAUTION
Health hazard due to escaping refrigerant/nitrogen!
Respiratory problems.
uOpen the refrigerant line carefully.
CAUTION
Damage to the appliance due to condensate!
Corrosion of components.
uDo not shorten the refrigerant line in the insulation.
uInstall the extended refrigerant line in an insulating tube.
Note
Reduction in cooling capacity.
uIf you extend the refrigerant line: do not reduce the inner
diameter of the pipe.
uInstall the refrigerant lines that are supplied on the rear
side of the appliance toward the cooling unit or the
building refrigerant lines according to the structural
conditions.
- ø Intake line 10 x 0.7 mm
- ø Pressure line 6 x 0.7 mm
The appliances are equipped with a refrigerant valve (stop
valve) that is already connected with the electronics. The
temperature is regulated by opening and closing the valve.
The thermostatic expansion valve is located in the motor
compartment.
uSet overheating on the valve if required. The works
setting is 4K. 1 clockwise revolution corresponds to 2K
higher overheating.
Assembly information
2 * Depending on model and options
