Side 1/12

Operating instructions

Combined fridge-freezer for integrated use

140217 7086522 - 00

ICU/ ICUN/ ICUS/ ICUNS ... LC

Contents

1 Appliance at a glance............................................ 2

1.1 Description of appliance and equipment.................. 2

1.2 Appliance range of use............................................. 2

1.3 Conformity................................................................ 3

1.4 Saving energy.......................................................... 3

2 General safety information................................... 3

3 Controls and displays........................................... 4

3.1 Operating and control elements............................... 4

3.2 Temperature display................................................. 4

4 Putting into operation............................................ 5

4.1 Switching on the appliance....................................... 5

5 Control.................................................................... 5

5.1 Child proofing........................................................... 5

5.2 Door alarm................................................................ 5

5.3 Temperature alarm................................................... 5

5.4 Refrigerator compartment........................................ 5

5.5 Freezer compartment............................................... 7

6 Maintenance........................................................... 8

6.1 Manual defrosting..................................................... 8

6.2 Defrosting with NoFrost............................................ 9

6.3 Cleaning the appliance............................................. 9

6.4 Customer service..................................................... 9

7 Malfunctions........................................................... 10

8 Decommissioning.................................................. 11

8.1 Switching off the appliance....................................... 11

8.2 Taking the appliance out of service........................... 11

9 Disposing of the appliance................................... 11

The manufacturer works constantly on the further development

of all the types and models. Therefore please understand that

we have to reserve the right to make design, equipment and

technical modifications.

To get to know all the benefits of your new appliance, please

read the information contained in these instructions carefully.

The instructions apply to several models. Differences may

occur. Text relating only to specific appliances is marked with

an asterisk (*).

Instructions for action are marked with a , the results of

action are marked with a .

1 Appliance at a glance

1.1 Description of appliance and equip-

ment

Fig. 1

(1) Operating and control

elements

(7) Vegetable bin

(2) Shelf, sectioned Can rack(8)

(3) (9)Shelf Bottle rack

(4) (10)LED interior light Bottle holder

(5) (11)Drain hole Freezer compartment

drawer

(6) (12)Coldest zone Type plate

Note

u Place food inside the appliance as shown in the diagram.

This allows the appliance to save energy during operation.

u Shelves, drawers and baskets are arranged for optimum

energy efficiency on delivery.

1.2 Appliance range of use

Intended use

The appliance is only suitable for cooling food

products in a domestic or household-like envi-

ronment. This includes, for example, use:

-in staff kitchens, bed and breakfast establish-

ments,

- by guests in country houses, hotels, motels

and other accommodation,

-for catering and similar services in the whole-

sale trade.

All other types of use are not permitted.

Foreseeable misuse

The following applications are expressly

forbidden:

Appliance at a glance

2 * Depending on model and options

Produkt Specifikationer

Mærke:	Liebherr
Kategori:	Køleskab
Model:	ICU 3324
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	- mm
Dybde:	- mm
Højde:	- mm
Vægt:	61500 g
Produktfarve:	Hvid
Kontroltype:	Knapper
Lampe type:	LED
Indbygget skærm:	Ja
Skærmtype:	LCD
Strøm:	1.4 A
Pakkevægt:	65300 g
Pakkedybde:	622 mm
Pakkebredde:	572 mm
Pakkehøjde:	1829 mm
Energieffektivitetsklasse (gammel):	A++
Årligt energiforbrug:	235 kWh
Placering af apparat:	Indbygget
Dørhængsel:	Højre
Installationsrum bredde:	560 mm
Installationsrum dybde:	550 mm
Installationsrum højde:	1772 mm
Tilsluttet belastning:	- W
Støjniveau:	37 dB
Strømkilde:	Elektrisk
Børnesikring:	Ja
Justerbare fødder:	Ja
Døråbningsvinkel:	115 °
Vendbare døre:	Ja
Fryser, netto rumindhold:	80 L
Fryser, brutto rumindhold:	83 L
Frysekapacitet:	6 kg/24t
Opbevaringstid under strømafbrydelse:	24 t
Klimaklasse:	SN-T
Brugerdefineret panel klar:	Ja
Køleskab antal hylder/kurve:	5
Antal grøntsagsskuffer:	1
Æggebakke:	Ja
Køleskabsdøre:	3
Dørpanel inkluderet:	Ingen
Køleskab, netto rumindhold:	194 L
Total netto kapacitet:	274 L
Understøtter VPN:	284 L
No Frost (køleskab):	Ingen
Køleskab indvendigt lys:	Ja
Stjernebedømmelse:	4*
Fryser position:	Bottom-placeret
Hylder, materiale:	Hærdet glas
Køleskab, brutto rumindhold:	201 L
Flaskeholder:	Ja
No Frost (fryser):	Ingen
Hurtig frys funktion:	Ja
Fryser antal hylder/kurve:	3
Frisk zone, aflukke:	Ingen
Energiforbrug:	0.642 kWh/24t
Automatisk afrimning (køleskab):	Ja
Temperaturalarm:	Ja
Kølesystem:	Dynamisk (blæserassisteret)
