Installation Guide

Quality, Design and Innovation

home.liebherr.com/fridge-manuals

Contents

1 General safety instructions................................... 2

2 Installation conditions........................................... 2

2.1 Location.................................................................... 2

2.2 Building the appliance into kitchen units................... 3

2.3 Installing multiple appliances.................................... 3

2.4 Mains connection..................................................... 4

3 Installation dimensions......................................... 4

4 Ventilation requirements....................................... 4

5 Transporting the device......................................... 4

6 Unpacking the appliance...................................... 4

7 Mounting wall spacers.......................................... 4

8 Setting up the appliance....................................... 4

9 Setting up the appliance so that it is level.......... 5

10 After setting up...................................................... 5

11 Disposing of packaging........................................ 5

12 What the symbols mean........................................ 5

13 Door hinge change................................................ 6

13.1 Removing the door................................................... 6

13.2 Moving the upper bearing parts to the other side...... 8

13.3 Moving the lower bearing parts to the other side...... 8

13.4 Moving the door bearing parts to the other side....... 9

13.5 Fitting the door......................................................... 9

13.6 Aligning the door...................................................... 10

13.7 Fitting the covers...................................................... 10

14 Connecting device................................................. 10

The manufacturer is continually working on the further develop-

ment of all types and models. Please be aware that we reserve

the right to make changes to the shape, equipment and tech-

nology.

Symbol Explanation

Read instructions

Please read the information in these instructions

carefully to understand all of the benefits of your

new appliance.

Full instructions on the internet

The detailed instructions are available via

the QR code on the front of these instruc-

tions, at home.liebherr.com/fridge-manuals

or by entering the service number at

home.liebherr.com/fridge-manuals.

The service number can be found on the serial

tag

Fig. ()

Fig.

Example illustration

Check appliance

Check all parts for transport damage. If you have

any complaints, please contact your agent or

customer service.

Symbol Explanation

Differences

These instructions apply to a range of models, so

differences are possible. Sections that apply to

certain models only are marked with an asterisk

(*).

Instructions and results

Instructions are marked with a .

Results are marked with a .

Installation videos

You can find videos on installing appliances on

the Liebherr-Hausgeräte YouTube channel.

1 General safety instructions

The socket must be easily accessible so that

the appliance can be quickly disconnected

from the supply in an emergency. It must be

outside the area of the rear of the appliance.

DANGER identifies a situation involving direct

danger which, if not obviated, may

result in death or severe bodily

injury.

WARNING identifies a dangerous situation

which, if not obviated, may result in

death or severe bodily injury.

CAUTION identifies a dangerous situation

which, if not obviated, may result in

minor or medium bodily injury.

NOTICE identifies a dangerous situation

which, if not obviated, may result in

damage to property.

Note identifies useful information and tips.

2 Installation conditions

WARNING

Fire hazard due to dampness!

If live parts or the mains lead become damp this may cause

short circuits.

The appliance is designed for use in enclosed areas. Do

not operate the appliance outdoors or in areas where it is

exposed to splash water or damp conditions.

Intended use

Install and use the appliance in indoor spaces only.

2.1 Location

WARNING

Leaking coolant and oil!

Fire. The coolant contained in the appliance is eco-friendly,

but also flammable. The oil contained in the appliance is flam-

mable. Escaping coolant and oil can ignite if the concentration

is high enough and in contact with an external heat source.

Do not damage the pipelines of the coolant circuit and the

compressor.

General safety instructions

2 * Depending on model and options
