Lindy 36296 Manual

Lindy Kabler til pc'er og periferiudstyr 36296

Læs gratis den danske manual til Lindy 36296 (8 sider) i kategorien Kabler til pc'er og periferiudstyr. Denne vejledning er vurderet som hjælpsom af 32 personer og har en gennemsnitlig bedømmelse på 4.7 stjerner ud af 16.5 anmeldelser. Har du et spørgsmål om Lindy 36296, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/8

TECHNICAL DATA SHEET

Part No

36296

DESCRIPTION RELATED PRODUCTS

DP Male to Male

No compromise, ultimate performance DisplayPort cable for demanding environments and mission critical systems

Supports UHD resolutions up to 4096x2160@60Hz 4:4:4 8bit

Full metal 24K gold plated housing, 24K gold plated connectors and contacts

Low attenuation triple shielded cable, corrosion resistant, high performance OFC 24AWG conductors

DisplayPort 1.2 compliant: 3D, 4K, 21.6Gbps, DisplayPort Certified; 25 year warranty

From the Lines cable connectivity concept developed by Lindy, Gold Line DisplayPort cables are the no compromise, high

performance connection solution for use in the most demanding professional environments.

Gold Line DisplayPort cables feature triple shielded construction with 24AWG OFC conductors for premium performance and

corrosion resistance. High quality 24K gold plated contacts and connectors maintain optimal signal integrity and maximum

reliability.

UHD resolutions up to 4K 4096x2160@60Hz 4:4:4 8bit, including stereoscopic 3D and HDCP are supported. DisplayPort 1.2

technology and DisplayPort compliance certification ensures compatibility with all DisplayPort enabled devices.

These superior quality cables utilise a unique low attenuation design that ensures consistent and reliable transmission even over

very long distances.

Gold DisplayPort cables are available in lengths from 0.5m to 20m.

36290 - 0.5m (1.64ft)

36291 - 1m (3.28ft)

36292 - 2m (6.56ft)

36293 - 3m (9.84ft)

36294 - 5m (16.40f)

36295 - 7.5m (24.61ft)

36296 - 10m (32.81ft)

36297 - 15m (49.21ft)

36298 - 20m (65.62ft)

10M DISPLAYPORT CABLE 1.2, GOLD LINE

DP MALE TO MALE

10m DisplayPort Cable 1.2, Gold Line

No.

EAN

Certificated

4002888362962

300kHz-825MHz <5dB

825MHz-2.475GHz <5dB

2.475GHz-4.125GHz <12dB

4.125GHz-5.1GHz <20dB

36296 36290 - 0.5m (1.64ft)

36291 - 1m (3.28ft)

36292 - 2m (6.56ft)

36293 - 3m (9.84ft)

36294 - 5m (16.40f)

36295 - 7.5m (24.61ft)

36296 - 10m (32.81ft)

36297 - 15m (49.21ft)

36298 - 20m (65.62ft)

AVAILABLE IN OTHER LENGTHS

PVC

DisplayPort Male

24K Gold 3µm

OFC Copper

Length 10m (32.81ft)

DisplayPort 1.2

Grey

Round

9mm (0.35in)

Type

Jacket Diameter

Jacket Material

CABLE CONSTRUCTION

CONNECTORS

4096x2160@60Hz 4:4:4 10bit

Conductor Material

Conductor Gauge

Shielding

21.6Gbps

Copper Braid 85%

MISCELLANEOUS

Warranty (Years)

24AWG

Packaging Type

Polybag

CE, UKCA, RoHS,

RE UACH, L

Maximum Resolution

Nominal Attenuation

Supported Bandwidth

Pin Plating

Dimensions (approx.) WxDxH

SPECIFICATONS

PURCHASING INFORMATION

90mm (3.5in)

-20°C - 80°C (-4°F - 176°F)

-25°C - 80°C (-13°F - 176°F)

Minimum Bend Radius

Operating Temperature

Storage Temperature

ATC Approved

10M DISPLAYPORT CABLE 1.2, GOLD LINE

Pin Construction

19.8x42.5x12.5mm

(0.78x1.67x0.49in)

24K Gold 15µm

Phosphor Bronze

Standard

Colour

Connector A

Connector B

Housing Material

Connector Plating

DisplayPort Male

24 Gold Plated Zinc Alloy

Produkt Specifikationer

Mærke:	Lindy
Kategori:	Kabler til pc'er og periferiudstyr
Model:	36296
