Lindy 36300 Manual

Lindy Kabler til pc'er og periferiudstyr 36300

Læs gratis den danske manual til Lindy 36300 (8 sider) i kategorien Kabler til pc'er og periferiudstyr. Denne vejledning er vurderet som hjælpsom af 75 personer og har en gennemsnitlig bedømmelse på 4.9 stjerner ud af 38 anmeldelser. Har du et spørgsmål om Lindy 36300, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/8

TECHNICAL DATA SHEET

Part No

36300

DESCRIPTION RELATED PRODUCTS

0.5M DISPLAYPORT 1.4 CABLE, CROMO LINE

DP MALE

0.5m DisplayPort 1.4 Cable, Cromo Line

Superior performance and design DisplayPort cable

Supports UHD resolutions up to 8K 7680x4320@60Hz 4:2:2 8bit, including 4K 4096x2160@160Hz 4:4:4 8bit

Chrome design ABS housing, 24K gold plated connectors and contacts

Triple shielded cable, corrosion resistant, high performance tinned copper 28AWG conductors

DisplayPort 1.4, 8K, 4K, 3D, 32.4Gbps; 10 year warranty

From the Lines cable connectivity concept developed by Lindy, Cromo Line DisplayPort cables are high performance, designer

connections that combine premium construction materials with striking connector architecture.

Cromo Line DisplayPort Cables feature triple shielded construction with 28AWG conductors for premium performance and

corrosion resistance. High quality 24K gold plated contacts and connectors maintain optimal signal integrity and maximum

reliability.

UHD resolutions up to 8K 7680x4320@60Hz 4:2:2 8bit, including 4K 4096x2160@160Hz 8bit, are supported. Cromo Line

DisplayPort cables are capable of delivering 4:4:4 colour spacing for the most accurate colour representation possible.

Cromo Line cables feature sleek chrome design ABS housing to complement the aesthetics of style focused commercial and home

applications.

Cromo Line DisplayPort cables are available in lengths from 0.5m to 5m.

36300 - 0.5m (1.64ft)

36301 - 1m (3.28ft)

36302 - 2m (6.56ft)

36303 - 3m (9.84ft)

36304 - 5m (16.40ft)

DP Male to Male

No.

EAN

0.5M DISPLAYPORT 1.4 CABLE, CROMO LINE

Pin Construction

19.7x38.9x12mm

(0.77x1.53x0.47in)

24K Gold 15µm

Phosphor Bronze

Standard

Colour

Connector A

Connector B

Housing Material

Connector Plating

DisplayPort Male

Chrome plated ABS

Maximum Resolution

Nominal Attenuation

Supported Bandwidth

Pin Plating

Dimensions (approx.) WxDxH

SPECIFICATONS

PURCHASING INFORMATION

73mm (2.87in)

-20°C - 80°C (-4°F - 176°F)

-25°C - 85°C (-13°F - 185°F)

Minimum Bend Radius

Operating Temperature

Storage Temperature

ATC Approved

CABLE CONSTRUCTIONCONNECTORS

107680x4320@60Hz 4:2:2 8bit

4096x2160@120Hz 4:4:4 8bit

RoHS, REACH, UL

Conductor Material

Conductor Gauge

Shielding

32.4Gbps

Copper Braid 85%

MISCELLANEOUS

Warranty (Years)

28AWG

Packaging Type Polybag

PVC

DisplayPort Male

24K Gold 3µm

Tinned Copper

Length 0.5m (1.64ft)

DisplayPort 1.4

Grey

Round

7.3mm (0.29in)

Type

Jacket Diameter

Jacket Material

Certificated

4002888363006

300kHz-825MHz <5dB

825MHz-2.475GHz <5dB

2.475GHz-4.125GHz <12dB

4.125GHz-5.1GHz <20dB

36300 36300 - 0.5m (1.64ft)

36301 - 1m (3.28ft)

36302 - 2m (6.56ft)

36303 - 3m (9.84ft)

36304 - 5m (16.40ft)

AVAILABLE IN OTHER LENGTHS

Produkt Specifikationer

Mærke:	Lindy
Kategori:	Kabler til pc'er og periferiudstyr
Model:	36300
Produktfarve:	Grå
Opbevaringstemperatur (T-T):	-25 - 85 °C
Driftstemperatur (T-T):	-20 - 80 °C
Maksimal opløsning:	4096 x 2160 pixel
Certificering:	REACH, UL
Kabellængde:	0.5 m
Harmoniseret systemkode (HS):	84733080
Bæredygtighedscertifikater:	RoHS
DisplayPort-version:	1.2
Stik 1:	DisplayPort
Stik 2:	DisplayPort
Stik 1 køn:	Hanstik
Stik 2 køn:	Hanstik
Stikforbindelse kontakter plettering:	Guld
Dataoverførselshastighed:	21.6 Gbit/sek.
Materiale for kapper:	Polyvinylchlorid (PVC)
AWG-ledningsstørrelse:	28
