Part no.:

| DESCRIPTION

38396

4K30 HDMI & USB over IP Extender - Encoder

Extends HDMI, USB, Audio, IR and RS-232 signals over a Gigabit IP Network including multicast and Video Wall functions

Supports resolutions up to 3840x2160@30Hz 4:4:4 8bit

Point-to-point, matrix, KVM and Video Wall over IP applications

Flexible control through Web GUI (Controller n. 38395), TCP, IR, RS-232 and third-party API control

PoE support

2 year warranty

This Encoder can be used in combination with the Decoder n. 38397 and the Controller n. 38395 to manage and distribuite HDMI,

USB, Audio, IR and RS-232 signals trough a 1G Ethernet Switch. It supports resolutions up to 4K30, KVM multicast applications and

video walls providing reliable solutions for creating eyecatching digital signage in retail, immersive displays at events or engaging

setups in larger conference rooms or lectures halls.

It supports HDMI 4K video streaming, point-to-point extension up to 100m and multicast functions such as video walls up to 9x9

and matrix conﬁgurations with many Encoders connected to many Decoders within the same 1G network environment. An

additional HDMI display can be connected to the loop out port on the Encoder to keep connected a monitor for local control.

This extender system provide JPEG2000 main stream and H.264/H265 codec Secondary Stream which supports plenty API

commands to achieve exible conﬂ ﬁgurations also from third party controll Apps.

It needs a layer3 1G managed network Switch supporting IGMP snooping and 8K Jumbo frame, with PoE funcion is also possible to

power on the unit without connecting the enclosed power supply.

•

Speci cationsﬁ

AV Interface: HDMI

Interface Standard: HDMI 2.0

Supported Bandwidth: 18Gbps

Maximum Distance: 100m (328.08ft)

Maximum Resolution: 4K@30Hz 4:4:4

HDCP Support: 2.2

EDID Pass Through: -

Supported Audio: Pass Through

Separate Audio Ports: 3-pin

IR Support: 20 - 60KHz

CEC Support: Pass Through

Serial Interface: RS-232

Transmission Protocol: IP

Transmission Medium: Cat.6

Laser Class (only for Fibre): -

Wavelength (only for Fibre): -

•

| TECHNICAL DATA SHEET



Chipset: -

Special Features: PoE, API support

Transmitter Input: HDMI (Female), USB Type B (Female), 3-pin Audio (Female), 3.5mm IR (Female)

Transmitter Output: HDMI (Female), 3-pin Audio (Female), 3.5mm IR (Female)

Bi-directional Ports: RS-232 3-Pin Terminal Block

Power: 5.5/2.1mm

Physical Properties

Dimensions (approx.) WxDxH: 204x134x21.5mm (8.03x5.28x0.85in)

Housing Material: Metal

Net Weight: 0.78kg (1.72lb)

Operating Temperature: 0°C - 40°C (32°F -104°F)

Storage Temperature: -20°C - 60°C (-4°F - 140°F)

Humidity: 20 - 90% RH (non-condensing)

Power Requirements: 12V 1A

Colour: Black

Miscellaneous

Packaging Type: Carton Box

Packaging Dimensions: 245x185x75mm (9.65x5.28x2.95in)

Gross Weight: 1.02kg (2.25lb)

Warranty (Years): 2

Product Compliance: CE, UKCA, FCC, RoHS, REACH & California Proposition 65

Package Contents

4K30 HDMI & USB over IP Encoder

IR Emitter Cable, 1.5m

IR Receiver Cable, 1.5m

2 x Mounting Ears & 4 x Screws

3 x 3-Pin Terminal Block

Multi-country Power Supply (UK, EU, US & AUS)

Lindy Manual

Purchasing Information

No.: 38396

EAN: 4002888383967

•

| TECHNICAL DATA SHEET



Produkt Specifikationer

Mærke:	Lindy
Kategori:	AV forlænger
Model:	38396
Type:	AV sender
Bredde:	204 mm
Dybde:	134 mm
Højde:	21.5 mm
Vægt:	780 g
Antal pr. pakke:	1 stk
Brugervejledning:	Ja
Produktfarve:	Sort
Pakkevægt:	1020 g
Pakkedybde:	185 mm
Pakkebredde:	245 mm
Pakkehøjde:	75 mm
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	20 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	20 - 90 %
HDCP:	Ja
Ethernet LAN:	Ja
Driftstemperatur (T-T):	0 - 40 °C
Maksimal opløsning:	3840 x 2160 pixel
Kabler inkluderet:	IR
Pakketype:	Kasse
Forbindelsesteknologi:	Ledningsført
DC-in-stik:	Ja
Understøttede netværksprotokoller:	IP
Strømkilde type:	DC
Udgangsstrøm:	1 A
AC-adapter inkluderet:	Ja
Antal USB-porte:	1
Bæredygtighedscertifikater:	CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA
Driftsspænding:	12 V
Maksimal overførselsafstand:	100 m
Maksimal opdateringshastighed:	30 Hz
HDMI-version:	2.0
USB-stik type:	USB Type-B
Strøm over Ethernet (PoE):	Ja
Overholdelse af bæredygtighed:	Ja
Monteringssæt:	Ja
HSMI-indgang:	1
RJ-45 indgangs-porte:	1
Antal HDMI-udgange:	1
Seriel grænsefladetype:	RS-232
Antal serielle porte:	1
HDCP-version:	2.2
Fjernbetjening (IR) indgang:	1
Fjernbetjening (IR) udgang:	1
Understøttede kabeltyper:	Cat6
Båndbredde:	18 Gbit/sek.
3,5 mm ind:	Ja
3,5 mm ud:	Ja
Infrarødt (IR) frekvens rækkevidde:	20 - 60 kHz
Inkluderede strømstik typer:	AU, EU, UK, US
