Side 1/8

TECHNICAL DATA SHEET

Part No.

41498

DESCRIPTION RELATED PRODUCTS

1M HDMI TO DISPLAYPORT CABLE

CONNECT A HDMI SOURCE TO A DISPLAYPORT DISPLAY

1m HDMI to DisplayPort Cable

Connect a HDMI source to a DisplayPort display

• Connect an HDMI equipped device to a DisplayPort display

• Supports high quality resolutions up to 4K@60Hz

• Compliant with HDMI 2.0 and DisplayPort 1.2 specification

• High Dynamic Range support provids deeper blacks, brighter whites and a wider colour spectrum

• 2 year warranty

Lindy’s HDMI to DisplayPort cables combine sleek, modern design with superior performance to provide a high quality conversion of

HDMI signals to output to a DisplayPort display. This range of active cables come with a chipset housed neatly inside the HDMI

connector to ensure a consistently reliable connection between HDMI media players, games consoles and PCs to DisplayPort

monitors.

With support for resolutions up to 4096x2160@60Hz, these cables are great for creating innovative working environments,

engaging educational workstations or immersive gaming experiences, while support for uncompressed multi-channel audio allows

for an impressive three-dimensional surround sound performance to compliment detailed, clear video. The additional USB Type A

connector can optionally be used to amplify the power to ensure a reliable connection in all situations.

41499

41500

TDTDS

S S TM

TMTMP

P P -

- - AV

AVAV //

// //

ACTIVE CABLES HDMI

No.

EAN

1M HDMI TO DISPLAYPORT CABLE

Pin Construction

HDMI: 50x20.9x12.7mm

(1.97x0.82x0.5in)

USB: 35x15.5x7.8mm

(1.38x0.61x0.31in)

DisplayPort: 38.9x19.7x12mm

Gold plated

Standard

Colour

Connector A

Connector B

Housing Material

Connector Plating

DisplayPort A Male

Maximum Resolution

Nominal Attenuation

Supported Bandwidth

Pin Plating

Dimensions (approx.) WxDxH

SPECIFICATONS

PURCHASING INFORMATION

36mm (1,42in)

-20°C - 40°C (-4°F - 104°F)

Minimum Bend Radius

Operating Temperature

Storage Temperature

ATC Approved

CABLE CONSTRUCTIONCONNECTORS

24096x2160@60Hz 4:4:4 8Bit

4096x2160@60Hz 4:2:2 12Bit

with HDR

CE, UKCA, FCC, RoHS, REACH &

California Proposition 65

Conductor Material

Conductor Gauge

Shielding

MISCELLANEOUS

Warranty (Years)

30AWG

Packaging Type Polybag

PVC

HDMI Type A Male, USB Type A M

Nickel Plating

Tinned Copper

Length 1m (3.28ft)

DP 1.2, HDMI 2.0

Black

Round

6mm (0,24in)

Type

Jacket Diameter

Jacket Material

ABS

0,85

41498 - 1m (3.28ft)

41499 - 2m (6.56ft)

41500 - 3m (9.84ft)

Certificated

4002888414982

80-90%

41498

AVAILABLE IN OTHER LENGTHS

-20°C - 40°C (-4°F - 104°F)

Produkt Specifikationer

Mærke:	Lindy
Kategori:	Kabler til pc'er og periferiudstyr
Model:	41498
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Understøttede videotilstande:	2160p
Opbevaringstemperatur (T-T):	-40 - 80 °C
Driftstemperatur (T-T):	-20 - 40 °C
Maksimal opløsning:	4096 x 2160 pixel
Pakketype:	Polybag
Understøttede grafikopløsninger:	4096 x 2160
High Dynamic Range (HDR) understøttet:	Ja
Kabellængde:	1 m
Harmoniseret systemkode (HS):	84733080
Bæredygtighedscertifikater:	CE, REACH, RoHS
HDMI-version:	2.0
DisplayPort-version:	1.2
Stik 1:	HDMI + USB Type-A
Stik 2:	DisplayPort
Stik 1 køn:	Hanstik
Stik 2 køn:	Hanstik
Stikforbindelse kontakter plettering:	Nikkel
Dataoverførselshastighed:	21.6 Gbit/sek.
Kabeltype:	Rundt kabel
Stik 1 formfaktor:	Lige
Stik 2 formfaktor:	Lige
Kabeldiameter:	6 mm
Båndbredde:	60 MHz
Materiale for kapper:	Polyvinylchlorid (PVC)
AWG-ledningsstørrelse:	30
Ledningsmateriale:	Fortinnet kobber
Materiale til stikhus:	Acrylonitrilbutadienstyren
Farveprøvetagning:	4:2:2, 4:4:4
Stik 1 dimensioner (BxDxH):	50 x 20.9 x 12.7 mm
Stik 2 dimensioner (BxDxH):	35 x 15.5 x 7.8 mm
Bøjningsradius (min):	36 mm
Stik 3 dimensioner (BxDxH):	38.9 x 19.7 x 12 mm
