Verricelli Verticali

Vertical Windlasses

MANUALE DI INSTALLAZIONE E D’USO - INSTALLATION AND USER’S MANUAL

MANUEL D’INSTALLATION ED D’UTILISATION - MANUAL DE INSTALACIÓN Y USO

INSTALLATION UND BEDIENUNG

CONSERVARE QUESTO MANUALE A BORDO

STORE THIS MANUAL ON BOARD

CONSERVER CE MANUEL À BORD

DIESES HANDBUCH AN BORD AUFBEWAHREN

GUARDAR ESTE MANUAL A BORDO

X1 - X1 ALU - X1 Dark Version

Via Philips, 5 - 20052 Monza (MB) (Italy)

www.Lofrans’.com - e-mail: contact@Lofrans’.com

Years Limited

Warranty

Lofrans'

X1 - X1 ALU

Dear Customer,

Thank you for choosing a Lofrans’’ product. Lofrans’’ is a leader company in the production and worldwide distribution of nautical

systems manufactured according to the most modern technologies, in compliance with international regulation requirements and the

most important certifying bodies. All our products are manufactured with excellent materials suited for operations in marine environments

and are subject to continuous checks to improve the qualitative levels and make them without any manufacturing defects. Together with

such requirements, Lofrans’ anchor windlasses are a synthesis of reliability and efciency, by guaranteeing the maximum performances

during each phase of mooring, even in the most difcult. With a Lofrans’ product, years of reliable operations are guaranteed.

Lofrans’ declines any liability for possible inaccuracies due to print errors in this manual and reserves the right to introduce any changes

deemed appropriate. For this reason, Lofrans’ does not guarantee the accuracy of the manual after the date of issue and declines all

liability for possible errors and omissions.

1 INTRODUCTION 3

1.1 Purpose of the manual 3

1.2 Assistance 3

1.3 Receipt and storage 3

2 SAFETY INFORMATION 3

3 INSTALLATION 4

3.1 Contents of the package 4

3.2 Equipment necessary for installation 4

3.3 Recommended accessories 4

3.4 General requirements for installation 4

3.5 Prevention from electrolysis 5

3.6 Deck thickness 5

3.7 Deck installation 5

3.8 Under deck installation 5

3.9 Chain insertion 6

4 ELECTRICAL SYSTEM 6

4.1 Electrical cable section 6

4.2 Solenoid valves (Control Box) 6

4.3 Circuit breakers 6

4.4 Remote control electric panel board 6

4.5 Wiring diagram 7

5 USE OF THE WINDLASS 8

5.1 Lowering the anchor 8

5.1.1 Lowering the anchor electrically 8

5.1.2 Lowering the anchor by gravity 9

PRODUCT COMPLIANT WITH EC REGULATIONS

TABLE OF CONTENTS

5.2 Weighing the anchor 9

5.3 of the warping drum 10

5.4 Notes for use 10

6 MAINTENANCE 10

6.1 Maintenance programme 11

6.2 Gipsy maintenance/replacement 11

7 TROUBLESHOOTING 11

8 TECHNICAL DATA 13

9 SPARE PARTS 14

10 OVERALL DIMENSIONS 18

11 DRILLING TEMPLATE 19

12 WARRANTY CONDITIONS 20

12.1 Conditions and limits 20

12.2 Exceptions 20

12.3 Liability 20

12.4 Procedure 20

12.5 Clause of Termination 20

12.6 Compliance 20
