Product Specification
Product Name: TWS31
Bluetooth
V
ersion: 5.3
Battery Input: DC 5V
Earphone Battery: 30mAh
Charge Case Battery: 190mAh
Working Time: About 3-4 hours
Sensitive: 116+/-3dB
Frequency: 20Hz-20KHz
Impendance: 32Ω
Profile support: HFP/HSP/A2DP/AVRCP
When charging: Flash white light
Full power: Solid bright white light
When charging the earbuds: Solid bright blue light
Charging time: about 90 minutes
1. Remove the earbuds from the charging case, the earbuds will automatically turn on
and pai;
2. Turn on the Bluetooth of your mobile phone and put the earbuds close to the mobile
phone. Select “Logic TWS31” from the bluetooth device list to connect.
Touch 1 time | Play/Pause Receive a call / End the call
Long touch 2 seconds | Transparency Mode/ANC ON /ANC OFF
Long touch 2 seconds | Call rejection
Touch 4 times | Wake up voice assistant
Long touch 3 seconds | Power on
Touch 2 times | Previous song
Touch 2 times | Next song
Touch 3 times | Vol-
Touch 3 times | Vol+
Long touch 5 seconds | Power off
Binaural Function:
Charging Case
Using Both Earbuds/Binaural Use:
1. Put the earbuds in to the charging case, the earbuds will turn off automatically.
The charging case will automatically charges the earbuds.
2. When the earbuds is turned on, long touch for 5 seconds to turn it off;
3. If the earbuds is not connected for 5 minutes, it will power off automatically
Power OFF:
Prepare the USB charger and connect the
charging cable to the charger and connect
charging case. When charging, the white light
flash after full charging, solid bright white light.
Charge:
Check if the earbuds has power (after the charging case is connected with USB,
and the earbuds is put in to the charging case for charging continuously for more than
1 hour).
1. Make sure that both earbuds are powered on and can be turned on normally;
2. Check if one earbud can connect to the other Bluetooth device;
3. Clear all the corresponding Bluetooth device name on the mobile phone, put both
earbuds in to the charging case, find an open area, reconnect the two earbuds.
1. The earbuds is low on power;
2. Check if the device is within a reasonable distance, preferably within 10 meter;
3. Check if there is a large area of signal barrier between mobile phone and earbuds,
such as wall or iron door;
4. There are interfering devices attached, such as routers or Bluetooth devices.
A. When the earbuds can't turned on automatically
B. When the earbuds have only one side sound or the mobile phone can not
find the Bluetooth device
C. When the earbuds is stuck or disconnected while talking or playing music
Warning
When charging: Solid bright white light
Full power: Light off
Charging time: about 60 minutes
Earbuds
FAQ
When you are plugging your cable in to wall charger, we recommend using a
UL/ETL 5V/1A approved charger. Don't use the fast charger over 5V/1A to avoid damage
to the charging case. To ensure the battery life of the earbuds, the earbuds and
charging case should be charged once a month.
Operation Instructions
Product Diagram Product Operation
LOGIC
TWS31
QUICK GUIDE | GUÍA RÁPIDA
TRUE WIRELESS HEADSET
logicmobility.com
Copyright Swagtek, Inc. 2024
Made in China
Warranty Certificate
Terms and Conditions
LOGIC warrants that their Products will be free from defects in material and workmanship. The warranty period
is one (1) year for the products and three (3) months for the accessories which are part of the original package
including the battery. The warranty period begins the date of purchase by the End-User who shall present an
invoice or a purchase receipt when requiring warranty service otherwise the warranty period will begin from the
date of manufacture of the product. LOGIC will repair a product without cost to the customer if it presents a
manufacturing defect or defect in workmanship during the warranty period and if the defect occurred under
normal conditions of use in accordance with the instructions and specifications stated in the user’s manual.
For additional information about the terms and conditions of LOGIC‘s Limited Warranty or to obtain warranty
service information, please visit the support section at: logicmobility.com
Certificado do Garantía
Términos y Condiciones
LOGIC garantiza que sus productos estarán libres de defectos de materia prima y ensamblaje. El período de
garantía es de un (1) año para los productos y de tres (3) meses para Ios accesorios que forman parte del
paquete original incluyendo la batería. El usuario final deberá presentar una factura o un recibo de compra
cuando exija el servicio de garantía, de lo contrario el período de garantía comenzará a partir de la fecha de
fabricación del producto. LOGIC reparará un producto, sin costo para el cliente si presenta un defecto de
fabricación o un defecto de ensamblaje durante el período de garantía y si el defecto se produjo en condiciones
normales de uso de acuerdo con las instrucciones y especificaciones indicadas en el manual del usuario.
Para más detalles de la Garantía Limitada de LOGIC y para obtener información del servicio de garantía, por
favor visite la sección de soporte en nuestro sitio web: logicmobilitycom.
