Motion Sensor

AM41TK Series

Quick Start Guide

lorex.com

PIR Sensor

Bracket

(optional)

Mounting Adhesive

Pin*

Package Contents

AM41TK_QSG_EN_R1

LED Behavior

See the table below for denitions of the

sensor’s LED behaviors:

Lorex products come with a standard 1-year

warranty. For more information about Lorex’s

warranty policy, visit .lorex.com/warranty

WAR NING:

CHOKING HAZARD

KEEP OUT OF REACH OF CHILDREN

Behavior Meaning

(solid for 2 seconds)

Powered on.

(ashing rapidly)

Ready to pair.

(solid for 2 seconds)

Pairing successful.

(ashing 3 times)

Pairing failed. Try

repeating the setup.

(ashing rapidly)

Alarm has been

triggered.

(ashing)

Firmware upgrade in

progress.

Battery slot

LED indicator

Pin insert

PIR sensor

Overview

• Environment: Indoor

• Maximum detection distance: 26 feet

• Maximum detection angle: 110°

• Operating temperature: 14°F~113°F

• Operating humidity: 0-95%RH

• Battery: CR2450

• Protocol: Bluetooth 5.0

Specifications

*May include one or more, depending on the package purchased.

To purchase additional sensors, visit and/or authorized resellers.lorex.com

STEP 2: Installing the Motion Sensor

Location tips:

• The motion sensor can be installed

indoors on a wall, ceiling or table, with or

without the included bracket.

• The motion sensor works best when it’s

placed 6 to 8 feet high, to keep safe from

being bumped and out of reach from

children and pets.

• If you want to detect smaller objects, use

one of the angled sides of the bracket.

Keep in mind the range and width of the

sensor.

Option A Option B - Bracket

AM41TK_QSG_EN_R1

NOTE: The bracket offers 2 separate angles for

the sensor to face.

NOTE: The sensor can be mounted on any at surface using the

adhesive. If you prefer to have the sensor on a table or placed in a

45° angle, see Option B for the bracket.

110°

Changing the BatterySTEP 1: Pairing to Your Device

To connect the sensor to your

device:

1. Tap the Lorex Home icon to

launch the app.

2. In the tab, press Devices

+ Add sensor to set up the

sensor.

Tap the icon on the top right +

of the screen to add more

sensors.

NOTE: the screen to the left is

taken from the Sensor Hub.

To change the sensor’s battery:

1. Make sure your system is disarmed.

2. Use the wide part of the pin to open the

sensor from the battery slot.

3. Slide the old battery out and replace it with

the new one.

NOTE: This sensor uses a CR2450 battery.

4. Snap the sensor closed with the battery

slot meeting the Lorex logo at the top.

1. Pick a at surface area to stick the sensor.

2. Test the sensor’s connectivity.

1. Pick a at surface area to stick the sensor.

2. Test the sensor’s connectivity.

3. Peel the circular adhesive and stick to the

back of the sensor. Then stick the other

26 feet

side to the bracket.

4. Peel the other adhesive and stick to the desired bracket angle.

Then stick the other side to the chosen at surface area.

3. Peel the circular mounting

adhesive and stick to the back of

the sensor. Then stick the other

side to the desired area.

3. Follow the on screen prompts

to complete the rest of the

setup. The Lorex Home app will

walk you through the process,

step by step.
