Side 1/2
Contents
• Weatherproof IR dome camera
• Mounting screws x 4
• 60ft. BNC / power extension cable
• BNC female / RCA male adapter
• Power adapter
Features
• Advanced Sony Super HAD™ II image sensor
• Video image processor produces sharp and clear video at
• Night vision up to 50ft. (15m) away in total darkness*
• ClearNight imaging technology ensures clear night vision and
improves recording efficiency up to 30%
• 3.6mm wide angle lens for wide area coverage (80° FOV)**
• IP66 rated aluminum housing for indoor / outdoor
installations***
Disclaimers:
* Infrared illumination range under ideal conditions. Actual range and clarity may vary depending on
scene / object reflection and camera application.
** Field of View, diagonal.
*** Not intended for submersion in water. Installation in a sheltered location recommended.
Warning/Caution
• Read this guide carefully and keep it for future reference
• Follow all instructions for safe use of the product
• Use the camera within given temperature, humidity, and
voltage levels noted in Camera Specifications
• Do not disassemble the camera
• Do not point the camera directly towards the sun or a source of
intense light
• Use only the supplied regulated power supply. Use of a non-
regulated, non-conforming power supply can damage this
product and voids the warranty
• The supplied extension cable is rated for surface mounting only
• Cables for in-wall / floor-to-floor installations are sold
separately
Installation Tips
• Point the camera where there is the least amount of obstructions
(i.e. tree branches)
• Install the camera in a location that is difficult for vandals to
reach
• Secure cabling so that it is not exposed or easily cut
• Camera rated for outdoor use. Installation in a sheltered
location recommended
WARNING: A REGULATED UL / CSA APPROVED power supply is
REQUIRED for use with this camera. Use of a non-regulated, non-
conforming power supply can damage this product and voids the
warranty.
Camera Specifications
* IR Illumination Range under ideal conditions. Objects at or beyond this range may be partially or
completely obscured, depending on the camera application.
** Not intended for submersion in water. Installation in a sheltered location recommended.
Dimensions
Copyright © 2011 Lorex Technologies Inc.
As our products are subject to continuous improvement, Lorex reserves the right to modify product design,
specifications and prices, without notice and without incurring any obligation. E&OE
Image Sensor 1/3” Sony Super HAD™ II
Video Format NTSC
Effective Pixels H: 768 V: 494
Resolution 600 TV Lines
Scan System 2:1 Interlace
Sync System Internal
S / N Ratio 50dB (AGC Off)
Iris AES
AES Shutter Speed 1/60 ~ 1/100,000 sec.
Min. Illumination 0.2 Lux without IR LED
0 Lux with IR LED
Video Output Composite 1.0Vpp @ 75ohm
Lens / Lens Type 3.6mm F2.0 / Fixed
FOV (Diagonal) 80°
Termination BNC Type
IR LED Qty / Type 14 pieces / 850nm
Night Vision Range* 50ft. / 15m
Power Requirement 12V DC ±10%
Power Consumption Max. 250mA (w / IR)
Operating Temp. Range 14° ~ 122°F / –10° ~ 50°C
Operating Humidity Range < 90% RH
Environmental Rating** IP66
Weight (including stand) 0.8lbs. / 0.4kg
95mm / 3.8"
88mm / 3.5”
Product Information
User Manuals
Quick Start Guides
Specification Sheets
Software Upgrades
Firmware Upgrades
LDC6051
SUPER RESOLUTION WEATHERPROOF
NIGHT VISION DOME CAMERA
FOR SUPPORT AND INFORMATION,
VISIT WWW.LOREXTECHNOLOGY.COM
QUICK START GUIDE
English Version 1.0
