Side 1/2

4K Ultra HD Motorized Varifocal

Bullet IP Camera

LNB9272_QSG_EN_R1

Quick Start Guide

English Version 1.0

As our products are subject to continuous improvement, Lorex reserves the right

to modify product design, speciﬁcations and prices, without notice and without

• For a full list of compatible recorders, visit lorex.com/compatibility.

• Not intended for submersion in water. Installation in a sheltered location

recommended.

• This camera includes an Auto Mechanical IR Cut Filter. When the camera changes

between Day/Night viewing modes, an audible clicking noise may be heard from

the camera. This clicking is normal, and indicates that the camera ﬁlter is working.

• For optimal remote viewing from your recorder, an upload speed of 256kbps per

camera is required (default setting). For example, your Internet service package

must support 2Mbps or greater upload speed for 8 cameras, 4Mbps or greater

for 16 cameras, and 8Mbps or greater for 32 cameras (your Internet service

provider can conﬁrm your upload speed). You may lower the resolution and

bitrate of camera video streams to further boost performance for slower Internet

connections. See your NVR's user manual at lorex.com for full instructions (see

"Conﬁguring Recording Quality" section).

Disclaimers

Dimensions

10.5” / 266mm3.7” / 95mm

LNB9272 SERIES

Resources

Need Help?

Visit us online for

up-to-date software and

complete instruction manuals

Click on the Downloads tab

Visit lorex.com

Search for the model number

of your product

Click on your product in the

search results

• 4K Ultra HD Motorized Varifocal Bullet IP Camera

• Mounting Kit*

• Mounting Template*

• Ethernet Extension Cable with Pre-attached RJ45 Cable Gland*

• Allen Key*

* Per camera in multi-camera packs.

Package Contents

ATTENTION:

It is recommended to connect the camera to the NVR or an external PoE

switch. If using a DC power adapter (not included) with the camera, a

REGULATED power supply is REQUIRED for use with this camera. Use of

a non-regulated, non-conforming power supply can damage this product

and voids the warranty.

• Use the camera only with compatible Lorex NVRs.

• Read this guide carefully and keep it for future reference.

• Follow all instructions for safe use of the product and handle with care.

• Use the camera within given temperature, humidity and voltage levels

noted in the camera’s speciﬁcations.

• Do not disassemble the camera.

• Do not point the camera directly towards the sun or a source of

intense light.

• Use only a regulated power supply with the product (optional). Use of a

non-regulated, non-conforming power supply can damage the product

and void the warranty.

• Periodic cleaning may be required. Use a damp cloth only. Do not use

any harsh, chemical-based cleaners.

• The supplied cable is rated for surface mounting only. Cables for in-wall

and ﬂoor-to-ﬂoor installations are sold separately (CMR type). These

and other cables are available at lorex.com.

Safety Precautions

www.lorex.com

• You can use a RJ45 coupler or switch (not included) to connect male

ends of Ethernet cable together.

• To extend the cable run beyond 300ft (92m), a switch will be required

(sold separately).

Extend the Ethernet cable run for your camera up to 300ft (92m).

See table below. It is recommended to use UL CMR approved cables

available at lorex.com.

Cable Extension Options

Cable Type

Max Cable Run

Distance

Max # of

Extensions

CAT5e (or higher) Ethernet cable 300ft (92m) 3

• Point the camera where there is the least amount of obstructions (i.e., tree

branches).

• Install the camera where vandals cannot easily reach.

• Secure cabling so that it is not exposed or easily cut.

• The camera is rated for outdoor use. Installation in a sheltered location is

recommended.

Installation Tips

Ethernet

Extension

Cable

RJ45 Cable Gland

Using the RJ45 Cable Gland (Optional)

The RJ45 cable gland is pre-attached to the

included Ethernet extension cable.

The RJ45 cable gland covers the camera’s Ethernet connector and the RJ45 plug to

provide weather-resistance and protection from dust, dirt and other environmental

contaminants.

To use the RJ45 cable gland:

RJ45 Cable

Gland Barrel

Camera Ethernet

Connector

NOTE: The RJ45 cable gland is weather-resistant. Seal the cap with silicone and/or

electrical tape for additional sealing if it will be exposed to precipitation regularly.

Twist the RJ45 cable gland barrel securely onto the camera Ethernet connector.
