HD Wire-Free Add-On Camera

LWB5800_LWB6800_QSG_EN_R1

Quick Start Guide

English Version 1.0

As our products are subject to continuous improvement, Lorex reserves the right

to modify product design, speciﬁcations and prices, without notice and without

LWB5800 / LWB6800 SERIES

• HD Wire-Free Security Cameras

• Camera Mounting Kit*

• Rechargeable Power Pack*

• Camera Antenna*

• Allen Key

• Power Pack Adapter

* Per camera in multi-camera packs

Package Contents

• Read this guide carefully and keep it for future reference.

• Follow all instructions for safe use of the product and handle with care.

• Use the camera within given temperature, humidity and voltage levels

noted in the camera’s speciﬁcations.

• Do not disassemble the camera.

• Do not point the camera directly towards the sun or a source of

intense light.

• Use only the supplied regulated power supply provided with the

product or compatible accessories. Use of a non-regulated, non-

conforming power supply can damage the product and void the

warranty.

• Periodic cleaning may be required. Use a damp cloth only. Do not use

any harsh, chemical-based cleaners.

Safety Precautions

lorex.com

Optimizing Motion Detection

Customize motion detection settings to ensure motion events are being

recorded and reduce false alarms.

To optimize motion detection:

1. Launch the Lorex Cirrus

app.

2. Tap a channel in Live View to

select it.

3. Tap

, then tap Motion.

4. Conﬁgure the following as

needed:

a. Sensitivity: The amount of motion needed to trigger recording (e.g., higher

sensitivity requires less motion to trigger recording).

b. Area Selection: Not supported.

c. Distance Setting: Conﬁgure distance setting for motion detection. While

watching the camera’s video on your mobile device, recreate a motion event

in front of your camera. The icon will change from

to when motion is

detected by the camera. Change the distance setting if motion detection is

being triggered by unwanted events.

NOTE: Distance will be affected by temperature.

d. Buzzer: Set the recorder to sound an alarm when motion is detected.

5. Tap Save. Repeat for other cameras on the system.

Installation Tips

• See images to the right for ideal setup. It is

recommended to place your camera at least

7ft (2.1m) above the ground and angle it slightly

downward toward the monitoring area, excluding

any busy areas (e.g., sidewalks or roadways).

• Ensure the camera image is free of obstructions

(i.e., tree branches).

• Position the camera no more than 20ft (6.1m)

away from the area you wish to monitor.

• See the “Optimizing Motion Detection” section to

customize motion settings for each camera on

your system.

• For best performance, position the camera so

that objects of interest will move from side-

to-side across the camera image, rather than

Follow the tips below for more accurate motion detection and to optimize

battery life:

moving towards or away from the camera.

• Install the camera within range of the recorder (noted in the camera’s

speciﬁcations).

• This camera is weather resistant for outdoor use (IP66 rated). Installation in a

sheltered location is recommended.

• Battery life will vary based on temperature, settings and number of events.

• For a full list of compatible recorders, visit lorex.com/compatibility.

• Not intended for submersion in water. Installation in a sheltered location

recommended.

Disclaimers

The following accessories are available for purchase. Visit lorex.com and

search for the model numbers below for details:

COLOR

Extra Power

Pack Power

Adapters

2-cell

Accessory

Power Pack

3-cell

Accessory

Power Pack

PLUS

Solar

Panel

WHITE

ACPWF1

ACBATT2

ACBATTR2

ACBATT3

ACBATTR3

ACSOL1B*

BLACK

ACPWFBK1

Available Accessories

* Compatible with select Wire-Free cameras only. Visit

lorex.com/compatibility for details.

STEP 1: Initial Setup

To prepare the cameras:

Before you begin, you will need to prepare the wire-free cameras and Power Packs.

2. Peel off the PLEASE REMOVE label

covering the contacts on each Power

Pack. Insert the charged Power Packs

into each camera base. Push up until

the Power Pack ‘clicks’ into place.

NOTE: Power Packs come fully charged with no need for initial charging.

1. Attach an antenna to

each camera.

STEP 2: Pairing with Lorex Cirrus

To pair the camera with Lorex Cirrus:

Pair your add-on camera to your recorder using the free Lorex Cirrus app for

smartphones and tablets (iOS and Android).

1. From Live view, tap any free

channel you would like to

pair a camera to (marked

with a

icon).

2. Tap PAIR. A timer for 30

seconds appears.

3. Press and hold the pair

button on the back of the

camera for 3 seconds.

NOTE: A “pairing successful” message should appear on screen. If you do not see this message,

repeat the steps above.

NOTE: Make sure the camera is within 3ft (1m) of the recorder.

To install your cameras:

1. Set the mounting bracket in

the desired mounting position.

Mark holes through the

mounting bracket (shown as

orange X’s on the right).

2. Drill holes where marked for

the mounting screws using

the included drill bit (item C

provided in the toolkit with your

wire-free system).

3. Secure the bracket to the mounting

surface with the included mounting

screws (×4). Make sure all screws

are fastened tightly using the

included screwdriver (item A+B

provided in the toolkit with your

wire-free system).

NOTES:

• Insert the included drywall anchors if you are mounting

the camera onto drywall.

• The hole at the top of the mounting bracket will be used in

step 5, once the camera is attached to the mounting plate.

STEP 3: Installing the Cameras

Follow the instructions below to mount the cameras. It is recommended that you refer to the “Installation Tips” section

to help you select good mounting locations.

4. Lower the camera base

onto the mounting bracket

so the 2 tabs in the

mounting bracket lock into

the 2 slots in the camera

base.

6. OPTIONAL: Tighten the pre-installed locking screw on the base of the Power Pack using

the included screwdriver (item A+B provided in the toolkit with your wire-free system).

7. Adjust the angle of the camera.

Use the included Allen Key

to loosen the adjustment

screws labelled below. Tighten

all adjustment screws when

ﬁnished.

8. OPTIONAL: Use the included cable clips to complete the installation. Remove the protective

strip to uncover the adhesive on the cable clip to attach to the mounting surface.

NOTE: You will need to loosen the locking screw to remove the Power Pack in the future.

Camera

levelling

Arm

rotation

Arm

angling

Power

cable

Mounting

surface

5. Insert the security screw

through the fasteners on the

top of the camera base and

mounting bracket to secure

the camera to the mounting

bracket. Tighten using

the included screwdriver

(item A+B provided in the

toolkit with your wire-free

system).

NOTE: The camera will 'beep' when the

Power Pack is properly inserted. If you

do hear this alert, remove the Power

Pack by pushing on the release tabs then

re-insert.

NOTE: If you are

angling the camera

down and to the right,

position the antenna

as shown to the right.

LWB5800_LWB6800_QSG_EN_R1
