Side 1/2

Package Contents

NR900XCL_QSG_EN_R1

USB MouseEthernet CablePower Adapter HDMI Cable

4K Network Video Surveillance Recorder

Remote Control

Dimensions

Connect your IP cameras (not included) using one of the following methods:

a. Connect cameras directly to the recorder (recommended).

NR900XCL Series

Quick Setup Guide

Physical setup of recorder and essential system settings

b. Connect cameras to a PoE switch or router on your network (not included). See “Adding

Cameras from the LAN” on reverse for more details.

1 / 2

Setting Up Your Recorder

Follow the steps below to complete physical setup of your recorder.

To set up your recorder:

STEP 1:

Connect IP cameras*

STEP 2:

Connect router*

STEP 3:

Connect monitor*

STEP 4:

Connect mouse

STEP 5:

Connect power

STEP 1:

Connect IP cameras*

STEP 2:

Connect router*

STEP 3:

Connect monitor*

STEP 4:

Connect mouse

STEP 5:

Connect power

Connect the recorder to your router using the included Ethernet cable.

Connect the recorder to a monitor using the included HDMI cable or a VGA cable

(not included). The HDMI port supports up to 4K resolution, and VGA supports up to

1080p.

Connect the included mouse to a USB port on the recorder.

Use the included power adapter to connect the recorder to a nearby outlet. Turn the

recorder on using the power switch on the back panel.

14.7” / 375mm

12.9” / 327mm

2.1”

53mm

* Not included / sold separately.

NOTES:

• This guide covers connecting IP cameras to your security recorder only. For full instructions

on installing your cameras, please refer to your camera’s documentation at lorex.com.

• Connecting cameras to a router, or a network switch without PoE, requires a power adapter

for each camera. Refer to your camera’s documentation at for the correct power lorex.com

adapter model number.

NOTES:

• If you are using a PoE switch, ensure the switch is connected to the same network as your

recorder.

• To receive automatic ﬁrmware updates and enable remote viewing with computer and mobile

apps, a high speed Internet connection is required (minimum upload speed of 5Mbps required for

4K viewing; 3.5Mbps for lower resolutions).). All other system features can be used without an

Internet connection.

NOTE: To optimize picture quality, set the recorder’s video output to match the resolution of

your monitor.

8-channel conﬁguration shown. 16/32 channel will have the respective number of video inputs.

For camera compatibility information, visit lorex.com/compatibility.

Overview of extra ports:

NOTE: For full instructions on using the extra ports, please refer to your security recorder’s

instruction manual at lorex.com.

Alarm Block

Connect alarm devices*

Audio I/O

Connect microphone / speaker*

RS232

Connect access control systems*

Back panels shown below are for illustration only. Your recorder’s back panel

may appear different, with all the same ports in different locations.

As our products are subject to continuous improvement, Lorex reserves the right to modify product design,

Need Help?

Visit us online for up-to-date software

and complete instruction manuals

Click on the Downloads tab

Visit lorex.com

Search for the model

number of your product

Click on your product

in the search results

NR900XCL_QSG_EN_R1

STEP 1: Creating a New Password

When using your system for the ﬁrst time, you will be prompted to create a new 6-32

character password.

To create a new password:

1. Connect your system according to the instructions on the front of this guide.

2. When the recorder turns on, create and conﬁrm your new, secure password. This

password will be used to connect to your system from now on.

Once you have completed the physical setup of your recorder,

follow the steps below to conﬁgure essential system settings.

Record your password below and store in a secure place:

STEP 2: Firmware Update

This system features automatic ﬁrmware upgrades for enhanced functionality. It is

required to upgrade your system to the latest ﬁrmware version.

To upgrade ﬁrmware:

1. After startup, a notiﬁcation will appear asking you to upgrade the ﬁrmware if a

newer version is available. Click to upgrade. OK

2. The system will download and install the ﬁrmware upgrade. Wait for the ﬁrmware

update to complete. The system may restart during the ﬁrmware upgrade process.

IMPORTANT: Do not power off the recorder or disconnect the power cable during

ﬁrmware installation.

STEP 3: Setting Date and Time

It is important to set the correct time to ensure accurate time stamps on recordings.

To set date and time:

1. In live view, right-click and click .Main Menu

2. Log in using the system user name (default: ) and your new, secure password.admin

3. Click

and select .Setting

4. Click General and select the Date & Time tab.

5. Click to save changes. Apply

a. Enter the current time and

select your time zone, and

click . OK

b. Check to enable auto DST

Daylight Savings Time

updates.

c. (Optional) Check NTP to

sync your system with an

Internet time server. Click

Manual Update to instantly

update the time.

NOTE: A constant Internet

connection is required to

use NTP.

1. LEFT-CLICK:

• During split-screen display mode: Click an individual channel

to view it in full-screen. Click again to return to the split-screen

display mode.

• While navigating menus: Click to open a menu option.

2. RIGHT-CLICK:

• Right-click anywhere on the screen to open During live view:

the Quick Menu.

• Right-click to exit menus.While navigating menus:

3. SCROLL WHEEL:

• During live view: Use the scroll wheel to zoom in / out.

NOTE: In live view, hover the mouse cursor over the top of the

screen to open the Navigation Bar. Move the mouse cursor away

from the top of the screen to close the Navigation Bar.

To quickly open a window that displays vital system information such as device ID,

model number, ﬁrmware version, and IP address:

• Press the button on the front panel. ENTER

• Right-click to open the Quick Menu and click . If prompted, enter the system user Info

name (default: ) and your new, secure password.admin

STEP 4: Adding Cameras from the LAN

Follow the steps below to add cameras that are not directly connected to the Power

over Ethernet (PoE) ports on the back of the recorder.

NOTE: lorex.com/compatibility Please visit for a list of compatible Lorex IP cameras.

To add cameras from the LAN:

1. Connect the camera to a router or switch on the same network as the recorder.

2. Right-click and select Device Search. Log in using the system user name (default:

admin) and your new, secure password.

3. The Remote Device menu appears. Perform the following:

a. Click . Device Search

b. Check the camera(s) you

would like to add.

c. Click Add. The status

indicator turns green

to show the camera is

successfully connected.

d. Click to save changes.OK

Reference: Using the Quick Menu

Right-click anywhere on the live viewing screen to open the Quick Menu.

a. Select camera/live display view.

b. Control PTZ cameras (not included).

c. Control Fish Eye cameras (not included).

d. Control auto focus cameras (not included).

e. Adjust camera color and image settings.

f. View system information.

g. Start/stop sequence mode.

h. Disable current audible warning.

i. Search and playback recordings.

j. Open manual recording controls.

k. Add IP cameras over the LAN.

l. Open Main Menu.

Reference: Using the Mouse

Reference: Quick Access to System Information

Search through and play video recordings from the hard drive.

To search for and play back recordings:

1. From live view, right-click and then click . Playback

2. Log in using the system user name (default: ) and your new, secure password.admin

3. Conﬁgure the following:

Reference: Playback and Search

a. Use the calendar on the

right to select the date to

playback.

b. Check channels you want

to play back. Click the

gray icon beside each

selected channel to

select Mainstream (M) or

Substream (S) video quality.

c. Click inside the video bar to

select the playback time.

Playback starts immediately

at the selected time.

Now that you have set up your recorder, see the following

reference sections to learn more about using your system.

Back up recordings from the hard drive to a USB ﬂash drive (not included).

To back up recordings:

1. Insert a USB ﬂash drive (not included) into a free USB port on the recorder.

2. From live view, right-click and then click . Main Menu

3. Log in using the system user name (default: ) and your new, secure password.admin

4. Click

, then click .BACKUP

5. Conﬁgure the following:

Reference: Backup

a. Select the type and quality of

recordings to search for.

b. Select the channel(s) to search

by.

c. Select a start and end time for

your search.

d. Choose a ﬁle format for your

backed up ﬁles.

e. Click Add to see recordings

that match your search.

f. Check boxes next to recordings

you want to back up, then

click . You may also click Start

Onekey Backup to back up all

ﬁles that match your search.

1 2
