Side 1/2

Dimensions

Camera Overview

Package Contents

Power AccessoriesMounting StandsHD Wi-Fi Camera Mounting Kit

×12

×8

×1

• Read this guide carefully and keep it for future reference.

• Follow all instructions for safe use and handling of the product.

• Use the camera within given temperature, humidity and voltage levels noted in the camera’s specications.

• Do not disassemble the camera.

• Do not point the camera directly at the sun or a source of intense light.

• Periodic cleaning may be required. Use a damp cloth only. Do not use any harsh, chemical-based cleaners.

Safety Precautions

aPlug in the camera:

DO NOT DOWNLOAD

Lorex Home

Congratulations! You can now view live video from your camera on your

mobile device.

Verify your camera image by temporarily plugging it in indoors. You will complete nal installation and

mounting later in the process.

• Connect the included power

adapter to the camera cable.

No need to use the included

extension cable at this time.

bDownload and sign up with Lorex Home:

• Download and launch the app from the App Lorex Home

Store or Google Play Store.

• Tap , then follow the on screen prompts to create an Sign up

account. Record your account details below:

Email:

Account Password:

cAdd your camera:

• Wait until the startup

chime is heard and the

status LED on the camera

is ashing green.

• From the tab, tap . Devices

NOTE: + If this is not your rst device, tap

in the top-right corner.

• Scan the QR

code on the

bottom of

the camera:

NOTE: If your mobile device cannot scan the

QR code, tap .Manually enter Device ID

dCreate password

• Create a secure password for the

camera.

eConnect to Wi-Fi

• Select your Wi-Fi network from the list.

• Enter your Wi-Fi password, then tap .Connect

Camera Password:

fFinishing touches

• Wait until the status LED on

the camera is solid green,

then tap .Next

• The camera is added to your Lorex Home account.

• Set the camera name and timezone, then tap .Complete

STEP 1: Getting Started

Status LED Behavior

See table below for denitions of camera’s LED behaviors:

Behavior Meaning

(steady) Operating correctly.

(ashing) Ready for connection.

(ashing rapidly) Mobile device is attempting to connect to the camera.

(steady) Device malfunction. Try resetting the camera (see ‘Camera Overview’ for details) and

repeating the setup.

(ashing) Network connection failed. Try resetting the camera (see ‘Camera Overview’ for details)

and repeating the setup.

(ashing rapidly) microSD error. Try removing and re-inserting the included microSD card, or try a different

card.

(alternating) Firmware upgrade in progress.

W282CA_QSG_EN_R1

W282CA Series

Quick Setup Guide

5.3” / 134mm 3.1” / 78mm

3.4”

85mm

As our products are subject to continuous improvement, Lorex reserves the right to modify product design,

Need Help?

Visit us online for up-to-date software

and complete instruction manuals.

Click on the tabDownloads

Visit lorex.com

Search for the model

number of your product

Click on your product

in the search results

Camera with wall mount

Camera with ceiling mount

5.1” / 129mm

3.1” / 78mm

4.6”

118mm

AMicrophone

DWarning Light

BImage Sensor

Status LED

IR LED

Power Cable

H IG Mounting Point Speaker microSD Slot

JReset Button: Press and hold for 10 seconds until you hear the audible chime.

Live Viewing Controls

Additional Installation Tips:

Connectivity Guidelines:

STEP 3A: STEP 3B: Wall Mounting Ceiling / Tabletop Mounting

Lorex Home Overview

Ensuring Accurate Person & Vehicle Detection:

Optimal accuracy for objects between 5-50ft (1.5-

15m) and in the bottom ⅔ of the image.

Lower accuracy for objects further away than 50ft

(~15m) and/or in the top ⅓ of the image.

• Angle the camera between 30~60° down from the level position.

• Install the camera between 8-16ft (2.5-5m) off of the ground.

Level position (i.e., ceiling)

Optimal

angle

range

NOTE: Accuracy of person and vehicle detection will be inuenced

by multiple factors, such as the object’s distance from the camera,

the size of the object, and the height and angle of the camera. Night

vision will also impact the accuracy of detection.

• Angle the camera so that objects of interest appear in the bottom ⅔ of the camera image.

• Choose a location where objects of interest will be between 5-50ft (1.5-15m) from the camera.

STEP 2: Important Installation Notes

• Other electronic devices such as microwaves, TVs, cordless phones, and baby monitors can cause signal interference.

It is recommended to install the camera as far away from these devices as possible.

• Place the camera as close to your Wi-Fi router or access point as possible.

• Reduce the number of obstructive materials between the camera and the router or access point. Concrete, brick,

metal and wood are the most common materials in your house that can cause poor signal strength.

• Point the camera where there is the least amount of obstructions (e.g., tree branches).

• Install the camera where vandals cannot easily reach.

• Secure cabling so that it is not exposed or easily cut.

• This camera is rated for outdoor use. Installation in a sheltered location is recommended.

1. Unplug the camera.

2. Use the included mounting template

to mark holes for the mounting screws

(×2) and cable (see ).Figure 1

3. Drill holes where marked. If required,

insert the included drywall anchors

(×2).

4. Set the mounting plate over the screw

holes with the indicator pointing TOP

up. Secure the mounting plate in place

using the included screws (see Figure

2).

5. Twist the camera clockwise onto the

wall mount (see ).Figure 3

6. Feed the camera cable through the

cable notch in the wall mount, as well

as the mounting surface (see Figure

4).

7. Use a athead screwdriver (not

included) to unlock the wall mount to

move the adjustment arm. Adjust the

camera angle as needed, then lock the

adjustment arm (see ).Figure 5

8. Position the wall mount over the wall

mounting plate so the cable notch lines

up with the unlocked position marked

on the wall mount base (see Figure

6).

9. Twist the wall mount cover clockwise

to lock the camera in place.

10. Reconnect the camera to the included

power adapter using the optional

weatherproof USB extension cable if

desired (see ).Figure 7

1. Unplug the camera.

2. Use the included mounting template to mark holes for

the mounting screws (×4) and cable (see ).Figure 8

3. Drill holes where marked. If required, insert the included

drywall anchors (×4).

4. Remove the pre-inserted silicon plugs (4×) from the

mounting stand (see ).Figure 9

5. Twist the camera clockwise onto the mounting stand

(see )Figure 10

6. Set the mounting stand over the screw holes. Secure

the mounting stand in place using the included screws

(see ).Figure 11

7. Feed the camera cable through the hole in the mounting

stand base, as well as the mounting surface (see Figure

12).

8. Twist the adjustment ring on the mounting stand

counterclockwise to adjust the camera angle as needed.

Tighten the adjustment ring when nished (see Figure

13).

9. Reconnect the camera to the included power adapter

using the optional weatherproof USB extension cable if

desired (see ).Figure 14

Figure 2Figure 1 Figure 9Figure 8

Figure 7 Figure 14

Figure 4Figure 3

Figure 6Figure 5

Figure 11Figure 10

Figure 13Figure 12

C D E F G

I J K

Settings: Congure settings for selected device.

Snapshot: Tap to save a still image of the current live view.

Two-Way Audio: Tap to speak into the microphone on your mobile

device. Sound will be transmitted through the camera’s speaker.

Tap again to disable.

Return to Main Menu

Pause/Restart Video

Viewing Mode: Switch between single and quad-channel views*.

Timeline: Tap to search for and play back recorded videos.

Video Quality: Tap to switch to HD** video quality. Tap again for

reduced video quality that is optimized for streaming.

Audio: Tap to mute / unmute.

Fullscreen: Tap to view in landscape mode.

Warning Light: Tap to enable the warning light.

Siren: Tap to enable the camera's siren.

Manual Recording: Tap to begin manual recording of the current

live view. Tap again to stop recording and save the video clip to

your mobile device storage.

* Quad-channel view allows you to view up to 3 other cameras, or channels from a security system. Tap the sign on an empty +

channel to select additional devices.

** HD resolution will be limited to the maximum screen resolution of your mobile device. This will not impact the recording

resolution of the camera.

• A regulated UL / CSA approved power supply is required for use with this camera (included). Use of a non-regulated, non-conforming power supply can damage this product and voids the warranty.

• Not intended for submersion in water. Installation in a sheltered location recommended.

• Audio recording without consent is illegal in certain jurisdictions. Lorex Corporation assumes no liability for use of its products that does not conform with local laws.

• This camera includes an Auto Mechanical IR Cut Filter. When the camera changes between Day/Night viewing modes, an audible clicking noise may be heard from the camera. This clicking is normal, and

indicates that the camera lter is working.

• Some channels on the 5GHz Wi-Fi band are restricted in Canada. This means certain Wi-Fi networks may not be available to connect to during setup.

Disclaimers

Adjustment arm

Mounting plate

Wall mount

Cable notch

Adjustment arm

Mounting

stand

Silicon plugs

Smart Motion Detection

Person Detection: Tap to enable/disable person detection. Motion notications

will state when a person is detected.

Motion Detection: Tap to enable/disable motion detection.

Vehicle Detection: Tap to enable/disable vehicle detection. Motion notications

will state when a vehicle has been detected.

Motion Sensitivity: Set a sensitivity level for motion detection (1 is the lowest).

Warning LED Light: Tap to enable/disable automatic warning light triggering when

motion, person, or vehicle is detected.

To access smart motion detection settings:

From the tab (default screen when launching Lorex Home), tap Devices next to

your Wi-Fi camera to access the device settings. Tap .Detection Settings

For tabletop installation:

Please refer to the following installation notes for outdoor mounting locations:

• Ensure objects of

interest will be further

than 5ft (1.5m) from

the camera.

• Place the camera so

that it has a clear view

of the scene, and is not

blocked by the surface

it is installed on.

For ceiling installation:

Refer to “Ensuring Accurate Person & Vehicle Detection”

above.

NOTE: For complete app instructions, see the Lorex Home manual on your

product page at .lorex.com

W282CA_QSG_EN_R1

Once you have completed initial setup using the Lorex Home app detailed on the front page, and reviewed all installation notices above,

select one of the installation methods below:

Congratulations! Your camera is fully installed and ready to go.

Now let’s start exploring what your camera can do. See the section below for an overview of features using Lorex Home.

5ft / 1.5m

Produkt Specifikationer

Mærke:	Lorex
Kategori:	Overvågningskamera
Model:	W282CA

Har du brug for hjælp?

Hvis du har brug for hjælp til Lorex W282CA stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Overvågningskamera Lorex Manualer

Lorex W261AS Manual

19 Juli 2025

Lorex F861AS-AA Manual

4 Juli 2025

Lorex W281AA Manual

3 Juli 2025

Lorex LND45DVW Manual

3 Juli 2025

Lorex E863SD Manual

2 Juli 2025

Lorex E863SB Manual

2 Juli 2025

Lorex LNB95MBW Manual

2 Juli 2025

Lorex LNW16XF Manual

26 Juni 2025

Lorex LNE95MDB Manual

20 Juni 2025

Lorex LNZ45P25 Manual

20 Juni 2025

Overvågningskamera Manualer

Nyeste Overvågningskamera Manualer

FLIR ioi HD CB-5222 Manual

30 Juli 2025

Eufy Cam S3 Pro Manual

30 Juli 2025

Telycam Vision+ 4KN 30X Manual

30 Juli 2025

Marshall Electronics CV630-BI Manual

30 Juli 2025

Telycam Vision+ SE Manual

30 Juli 2025

FLIR Ariel CC-3405 Manual

29 Juli 2025

FLIR Ariel CM-3505 Manual

29 Juli 2025

Axis Q6355-LE Manual

29 Juli 2025

Sony SNC-EMX52R Manual

29 Juli 2025

Hikvision DS-2CD3086G2H-LIU Manual

29 Juli 2025
