F EAT U R ES A N D S P EC I F I C AT I O N

1. This watch is a combination quartz watch with

analogue and digital displays, 3 hands analogue

movement.

2. Accuracy at normal temperature: 30 seconds ±

a month

3. Time keeping mode: hours, minutes, seconds,

month, date, day of week, “PM”(only available

in 12-hour format)

Press S1 button to show the month and date

indication.

4. Alarm Mode: Daily alarm.

5. Timer Mode:

Measuring unit: 1 second

Input range: from 1 second to 23:59’59”.

6. Stop watch Mode:

Measuring unit 1/100 of second :

Measuring capacity: 23:59’59”.

7. Normal operating temperature range: between

-20°C and 70°C.

8. Battery type: CR2016, SR626SW

S E T T I N G T H E T I M E ( A N A L O G U E)

(MODE)

AFTERNOON

HO UR HA ND

S 4

DAY O F W E EK

C H I M E

S IG N A L

CHRONOGRAPH

S IG N A L

DA T E

S 2

( S E T / R E S E T )

M IN U T E S

S E C O ND S

C R O W N

( L I G HT )

A L A R M

S IG N A L

S 3

S 1

( S T A R T / S T O P)

C R O W N

MINU T E HA ND

S E C O ND HA ND

DAY O F W E EK

C H IME S I G NA L

A L A R M S I G NA L

S E C O ND S

T I M E R

S IG N A L

CHRONOGRAPH

S IG N A L

AFTERNOON

D I G I TA L D I S P L AY A

M IN U T E S

HO U R S

S 4

( L I G HT )

(MODE)

S 3 S 2

( S E T / R E S E T )

S 1

( S T A R T / S T O P)

DA T E

T I M E R

S IG N A L

HO U R S

C R O W N

1. Pull the crown out one step, the second hand

will stop.

2. Set the hands to the correct time by turning the

crown.

3. Push the crown back to the original position. The

watch will start running again.

The analogue indication and digital display of the

time setting can be adjusted separately.

H O W T O C H A N G E D I SP L AY M O D E

H O W T O S E T N O R M A L T I M E /

C A L E N D A R

1. While in the normal time mode, press S2 button

once. The second digits start to flash.

2. While the second digits are selected (flashing),

press S1 button to reset the seconds to 00. If you

press S1 button while the second count is in the

range between 30 and 59, the seconds are reset

to 00 and 1 is added to minutes. If the second

count is in the range between 00 and 29, the

seconds are reset to 00 but the minute count is

unchanged.

3. Press S3 button to move on to the next setting.

SECO NDS

DATEDAY

12 / 2 4 - H O U R

FO R M AT

MONTH

MINUTESHOURS

Press S3 button to change the display mode. Each

time the button is pressed, the mode changes in

the following order.

T I M E R

NO R MA L T IM E C H R O NO G R A P H

A L A R M

S E C O N D T IME Z O NE

S 3

S 3 S 3

S 3

S 3S 3

S 3

NORMAL TIME

12/24 FORMAT SETTING

BY PRESSING S1

DAY OF WEEK SETTING

BY PRESSING S1

DATE SETTING BY

PRESSING S1

MONTH SETTING BY

PRESSING S1

MINUTE SETTING BY

PRESSING S1

HOUR SETTING BY

PRESSING S1

SECOND SETTING BY

PRESSING S1

H O W T O U S E S T O P WAT C H

From the normal time mode, press S3 button once,

you are now in the chronograph mode.

First Usage:

1. Press S1 button alternately to start and stop the

chronograph.

2. Press S2 button to reset the chronograph to zero.

3. Pre ss S3 but t on to ret urn to nor mal time

mode. (This can be done at any time with the

chronograph still running.)

Second Usage:

1. Press S1 button to start counting.

2. Press S2 button to show the first split time T1 (0

to T1). The digits stop flashing, but chronograph

is still counting.

3. Press S2 button again to continue counting.

4. Further press S2 button to show the second split

time T2 (0 TO T2). This operation can be repeated

and the split times can be read: 0 to T3, 0 to T4

etc.

5. Press S1 button to stop the measurement of the

chronograph.

6. Press S2 button to show the last split time Tn (0

to Tn).

7. Press S2 button again, the chronograph is reset

to zero.

8. Press S3 button to return to the normal time mode.

S 3

S 2

NORMAL TIME

START

STOPWATCH

LAP

STOP

S 3

S 2

S 3

S 2

NREZ022 4-2014

CAL. Z022 (R23 SERIES)

4. Press S1 button to adjust the value. Holding S1

button down can fasten the process.

5. When the 12-hour format is selected, the indicator

“PM” indicates “p.m.” times. There is no indicator

for “a.m.” times.

6. Press S2 button to confirm the settings.

D I G I TA L D I S P L AY B

S 3

1. From the normal time mode, press S3 button 4

times to enter the second time zone mode.

2. Press S2 button to start the setting procedure.

The hour digits start flashing.

3. To adjust the value, press S1 button (+1 hour).

4. Press S3 button once to move on to the minute

setting.

5. To adjust the value, press S1 button (+30 minutes

or -30 minutes).

6. Press S2 button to confirm the setting.

7. Press S3 button to return to the normal time mode.

MINUTE SETTING BY PRESSING S1

(+30 MINUTES)

H O U R S E T T I N G B Y

PRESSING S1 (+1 HOUR)

SECOND TIME ZONE

NORMAL TIME

PRESS S3

4 TIMES

NORMAL TIME

PRESS S3

2 TIMES

ALARM MODE

HOUR SETTING BY

PRESSING S1

MINUTE SETTNG BY

PRESSING S1

TIME ZONE SETTING

BY PRESSING S1

S 3

S 2

S 3

H O W T O S ET A L A R M T I ME

1. You can set alarm with hours and minutes. When

the alarm is on, the alarm (BI-BI) sounds for 20

seconds at the preset time. Press S1, S2 or S3

button to stop the alarm after it starts sound.

Alarm is available in one time zone only (T1 or

T2).

2. From the normal time mode, press S3 button 2

times to enter the alarm mode.

3. To change the alarm setting, press S2 button. The

hour digits start flashing. To adjust the value, press

S1 button.

4. To move on to the minute setting, press S3 button.

To adjust the value, press S1 button.

5. To set the time zone, press S3 button. “AL. T1” or

“AL. T2” will flash. Select the time zone by pressing

S1 button.

H O W T O S ET S EC O N D Z ON E T I M E

S 2

S 3

S 2

S 3

S 2

H O W T O U S E T I ME R

indicated hourly chime is on

indicated alarm is on

TO SET THE COUNTDOWN TIMER

1. From the normal time mode, press S3 button 3

times to enter the timer mode.

2. While in the timer mode, press S2 button. The hour

digit starts to flash.

3. Press S3 button to change the selection of setting.

3. Press S1 button to adjust the value. Holding S1

button down can fasten the process.

4. After you set the countdown time, press S2 button

to return to the timer mode.

A L A R M & C H I ME O N / OF F

PRES S S3

2 TIMES

NORMAL TIME ALARM

From the normal time mode, press S3 button 2

times to enter the alarm mode.

Press S1 button to turn on or off the ALARM and

HOURLY CHIME signals.

H O W T O U S E EL B A C K L I GH T

In any mode press S4 button to illuminate the

display for about 3 seconds.

Note:

1. The backlight of the watch employs an electro-

luminescent (EL) light, which tends to lose

illuminating power after very long use.

2. The illumination provided by backlight may be

hard to see when viewed under direct sunlight.

S 3

NORMAL TIME TIMER

PRESS S3

3 TIMES

HOU R S ET T ING BY

PRESSING S1

MIN U T E SET T ING BY

PRESSING S1

S 3

TO USE THE COUNTDOWN TIMER

1. Press S1 button while in the timer mode to start

the countdown timer.

2. Press S1 button again to stop the countdown

timer.

3. While in the timer mode, press S2 button to reset

the countdown time to its starting value and to

start to countdown automatically or while in the

timer mode, press S2 button and then press S1

button to reset the countdown time.

4. From 3 minutes prior to the expiry time, the alarm

(BI BI) beeps each time when the second digits

reach “0” or “30”.

5. Within 10 seconds to the expiry time, the alarm

(BI) beeps per second.

6. When the timer expires, the alarm (BI-BI-BI) beeps

for 10 seconds. It may be silenced by pressing S1,

S2 or S3 button.

SECOND SET T ING BY

PRESSING S1

S 3

SETTING IS COMPLETED

TIMER HAS EXPIRED

BEGIN COUNT DOWN

RELOAD

TIMER AND

SET

S 2

S 3

S 2

The batteries CR2016 and SR626SW which power

your wat ch should last approximately 2 years.

Ho we v e r, b e ca use t h ey a r e ins e r t e d a t t h e

factor y, the actual life of the batteries once in

your possession may be less than 2 years.

Be sure to replace the batteries to prevent any

possible malfunction as soon as they run down. To

replace the batteries, we recommend taking the

watch to a local watch repair shop.

Note: If t h e a l a r m is u se d fo r m o r e t h an 20

seconds a day, the hourly time signal more

than 24 times a day, the stopwatch more

than once a day and/or the illuminating

light for more than 1 second a day, the

battery life may be less than the specified

period.

B AT T ER Y C H A N G E

Pr int ed in C hina

CAUTION

S1 to stop

T h i s w a t c h c o n t a i n s p r e c i s e e l e c t r o n i c

components. Never attempt to open the case or

remove the back cover.

• BATTERY

Do not exp o se t he old ba t ter y t o f ir e o r

recharge it. Keep it at a place beyond the

reach of chil dren. If a child swallows it, consult

a doctor immediately.

• WATERRESISTANT

Con d i t i o n

of u s e Ac c i d e n t a l

con t a c t

wi t h wa t er,

s u c h a s

s p l a s h e s

a n d ra i n

Sw i m m i n g

a n d ta kin g

a s h o wer

Sk i n

d i v i n g

Sc u ba

d i v i n g

Indication

on the dial/

case back

I nd ic a t i on

* If your watch is 200 M/20 BAR, 100 M/10 BAR or

50 M/5 BAR water resistant, it is so indicated on

the dial/case back.

• Donotoperatethebuttonswhenthewatchiswet.

• If thewatchis exposedto saltwater, rinse itin

fresh water and then wipe it thoroughly dry.

• Shouldyoufindanywaterorcondensationinside

the watch, immediately have it checked. Water

can corrode electric parts inside the case.

NO NO NO

YE S YE S NO NO

YE S YE S NO

NO NO NO

YE S

WA T E R

R E SI S T A N T

WA T E R

R E SI S T A N T

( 5 0 M / 5  B A R

)

WA T E R

R E SI S T A N T

1 0 0M / 1 0 B A R 

or ab ove

(

Caution:

Leather st raps are not water resistant except

so indicated, even if the watch head is water

resistant.

• ALLERGICREACTION

Be cause t he c a se a n d b a nd t o uch t he s k in

directly, it is important to clean them regularly. If

not, shirt sleeves may be stained and those with

delicate skin may develop a rash. Please wear

the watch with some play to avoid any possible

allergic reaction. If you develop a rash on your

wrist, stop wearing and consult a physician.

• MAGNETISM

Your watch will be adversely affected by strong

magnetism. Keep it away from close contact with

magnetic objects.

• SHOCKSANDVIBRATIONS

Yo ur wa t c h ma y b e wo r n fo r n o r m a l s po r t s

activities, but be careful not to drop it or hit it on

hard surfaces.

• TEMPERATURE

Your wa t ch i s p re ad just e d so t h at co n st ant

accuracy may be insured at normal tem pera ture.

• CLEANING

U s e o n l y a so f t cl o t h an d c l e a n w a t e r fo r

cleaning your watch. Never use chemicals, as the

waterproof gasket will corrode.

YE S

■ C A R E O F Y O UR L O R U S WAT C H

■ S E R V I CE

W he n yo u r L O RU S wa t ch r e qu i r e s r e p a i r o r

ser vicing, please see the enclosed WARRANTY/

GUARANTEE.

(

Produkt Specifikationer

Mærke:	Lorus
Kategori:	Ur
Model:	Sports R2321MX8

Har du brug for hjælp?

Hvis du har brug for hjælp til Lorus Sports R2321MX8 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Ur Lorus Manualer

Lorus R23 SERIES - CAL Z013 Manual

23 August 2024

22 August 2024

20 August 2024

19 August 2024

19 August 2024

Lorus Dress RT333GX9 Manual

18 August 2024

Lorus Kids R2345MX9 Manual

18 August 2024

Lorus Z015 Manual

18 August 2024

Lorus Dress RM307DX9 Manual

17 August 2024

Lorus Sports RM367EX9 Manual

17 August 2024

Ur Manualer

Nyeste Ur Manualer

Citizen Marvel Deadpool CA0688-04W Manual

28 Juli 2025

Citizen Disney Aurora Diamond EM0594-53W Manual

28 Juli 2025

Casio G-Shock GA-700UC-3A Manual

28 Juli 2025

Casio Baby-G BSA-B100 Manual

27 Juli 2025

Casio G-Shock GM-110 Manual

27 Juli 2025

Casio G-Shock GM-S5600 Manual

27 Juli 2025

Casio Edifice EF-527D-1A Manual

27 Juli 2025

Casio Edifice EFR-571 Manual

27 Juli 2025

Citizen Axiom EM0633-53A Manual

27 Juli 2025

Casio G-Shock GST-S110 Manual

27 Juli 2025
