Page 1 of 8 P/N 11857.00 Rev A

INSTALLATION INSTRUCTIONS

HOOD MODELS LOH36, LOH48 & LOH60–

IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ ENTIRE INSTRUCTION BEFORE PROCEEDING.

INSTALLATIONS MUST COMPLY WITH ALL LOCAL CODES.

IMPORTANT: Save these Instructions for the Local Electrical Inspector's use.

INSTALLER: Please leave these Installation Instructions with this unit for owner.

OWNER: Please retain these Instructions for future reference

WARNING - TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO PERSONS, HOODS

SHOULD BE INSTALLED WITH VENTILATORS APPROVED FOR USE WITH THE HOOD. SEE TABLE 1 ON –

THIS PAGE FOR APPROVED VENTILATORS.

WARNING - TO REDUCE THE RISK

OF FIRE, ELECTRIC SHOCK, OR

INJURY TO PERSONS, OBSERVE

THE FOLLOWING:

A. Installation work and Electrical Wiring

Must Be Done By Qualiﬁed Person(s) In

Accordance With All Applicable Codes

& Standards. Including Fire-Rated

Construction. “WARNING” To Reduce

The Risk Of Fire, Use Only Metal Duct

Work.

B. Suﬀicient air is needed for proper

combustion and exhausting of gases

through the ﬂue (chimney) of fuel

burning equipment to prevent

backdrafting. Follow the heating

equipment manufactures guideline and

safety standard such as those published

by the National Fire Protection

Association (NFPA) and the American

Society for Heating, Refrigeration and

Air Conditioning Engineers (ASHRAE),

and the local code authorities.

C. When cutting or drilling into wall or

ceiling, do not damage electrical wiring

and other hidden utilities.

D. Ducted fans must always be vented to the

outdoors.

E. Before Servicing or Cleaning Unit,

Switch Power oﬀ At Service Panel And

Lock Service Disconnecting Means to

Prevent Power From Being Switched On

Accidentally. When The Service

Disconnecting Means Cannot be Locked,

securely Fasten A Prominent Warning

Device, Such As A Tag, To The Service

Panel

CAUTION - TO REDUCE THE RISK OF FIRE AND TO PROPERLY EXHAUST AIR, BE SURE TO DUCT AIR

OUTSIDE FOR DUCTED FANS DO NOT VENT EXHAUST AIR INTO SPACE WITHIN WALLS OR CEILING –

OR INTO ATTICS, CRAWL SPACES OR GARAGES.

Read this instruction completely before starting installation. Planning the complete installation before starting any work is

highly recommended. This includes all aspects of the installation including hood location, ducting, electrical requirements, and

adequacy of mounting surfaces.

TABLE - 1

Model LOHI = Internal ventilator

Model LOHE = Remote ventilator

This hood series has been designed to be used with the ventilators shown in Table 1. Before –

cutting into cabinets, it is necessary to conﬁrm that the correct ventilator is being used. Your

dealer should have reviewed your needs prior to your purchase. Be sure you have the correct

ventilation system.

CAUTION: To Reduce The Risk Of Fire And Electrical Shock, Install This

Rangehood Only With Blowers Manufactured By Lynx Professional Grills.

DUCTING: Use a minimum 10" round duct for LOHI and LOHE installations. See Page – 3. A standard starting transition

(33895) is included with the Hood.

SAFTY WARNING:

Turn oﬀ power circuit at the service entrance and lockout panel before wiring the range hood.

NOTE: Unit be vented must

to the outside of the building.

Page 2 of 8 P/N 11857.00 Rev A

BEFORE STARTING INSTALLATION, YOU MUST IDENTIFY THE VENTILATOR MODEL BEING USED AND

IF A TOP OR REAR EXHAUST IS TO BE USED.

Prepare cabinet and/or wall for mounting either top (Fig - 1)

or rear (Fig 6 & 7) exhaust. Use furring strips to level cabinet

mounting surface with any cabinet trims.

For knock out removal see Fig- B

Remove

See

Ventilator Model Knock out # Transition # Fig

LOHI Top Exhaust 1 33895 1,2,3

LOHE Top Exhaust 1 33895 1,2,3

LOHI Rear Exhaust 2 33895 4,5,6,7

LOHE Rear Exhaust 2 33895 5,6,7

Break the metal webs by placing a screwdriver at one corner

of the plate and hitting screwdriver sharply with a hammer.

After breaking a second web the plate can be flexed to break

other webs.

Wear eye protection when using tools.

Caution: When knock outs are removed the edges will be

sharp! Sharp Edges should be Filed or Covered with

Metal Tape.

Attach and secure the transition to the hood with #6x3/8 sheet

metal screws and tape all joints prior to installing the hood.

Attach hood to cabinet using #10 wood screws. Holes are

located in the back panel and top panel of the hood for

mounting. Use a minimum of four #10x3/4 wood screws to

mount the hood. Longer screws are required if wall board or

other nonstructural surfaces are used between the hood and

main mounting surface which should be a minimum of 3/4”

thick. When using rear holes for additional mounting use

appropriate anchors if not engaging the wood structure.

HINT: If you find vibration noise is present because of

cabinet structure use additional screws, in holes available, to

make the mounting more ridged.

Connect 120 volt, 60 Hz power through the conduit hole in

top of hood, connecting to pigtail in hood junction box, white

to white, black to black and connect green ground wire to the

power supply ground wire per local codes. See Fig A. –

NOTE: Recommended height over BBQ Grills = 36

inches.

Hood is recommended for use over domestic gas or electric

appliances. Not recommended for use over solid fuel ﬁred

appliances.

After installing the hood, install the internal blower (Top

Exhaust See Fig 2; Rear Exhaust See Fig - 4) unit by

positioning the blower onto bracket-A, notched blower

bracket will center blower. Rotate into position against hood

and secure Bracket B to Hood with #8 sheet metal screws. –

If the remote ventilator is used see related instructions. The

LOHE ventilator will require revision of some wiring in the

hood receptacle box - See LOHE instructions.

NOTE: LOHE requires a dedicated 20 AMP Power

Supply. All other ventilators require a dedicated

15 AMP Power Supply

CAUTION: The hood is of sufﬁcient weight that two

installers are recommended to prevent injury or damage to the

hood in handling.

Turn the power on at the service entrance and check the

operation of the controls.

NOTE: be sure that all dampers are operating properly and

are free to open.

Hood Top

Hood Wiring Access

Mounting Screw

Cover

Knock Outs

Remove Appropriate Knock Outs and Connect Wiring

According to Hood and Blower Installation Instructions.

CAUTION: Always Install Receptacle Box Cover.

RECEPTACLE BOX COVER

Fig A –

Fig - B
