INSTRUCTION MANUAL

Slide Compound Miter Saw

LS1219

LS1219L

ENGLISH: Original instructions

DOUBLE INSULATION

Read before use.

2 ENGLISH

SPECIFICATIONS

Model: LS1219 LS1219L

Blade diameter 305 mm

Hole diameter European countries 30 mm

Countries other than Europe 25.4 mm

Max. kerf thickness of the saw blade 3.2 mm

Max. miter angle Right 60°, Left 60°

Max. bevel angle Right 48°, Left 48°

No load speed (RPM) 3,200 min-1

Laser type Red Laser 650 nm, Maximum -

output

1.6mW ( Laser Class 2M )

Dimensions (L x W x H) 898 mm x 664 mm x 725 mm

Net weight 29.3 kg 29.5 kg

Safety class /II

Cutting capacities (H x W)

Miter angle Bevel angle

45° (left) 45° (right)0°

0° - 61 mm x 382 mm

71 mm x 363mm

92 mm x 382 mm

107 mm x 363 mm

44 mm x 382 mm

54 mm x 363 mm

Thickness of wood

facing on guide

fence for increased

height of cut

20 mm 78 mm × 325 mm 115 mm × 325mm 61 mm × 325 mm

38 mm 80 mm × 292 mm 120 mm × 292 mm -

45° (right and left) 61 mm x 268 mm-

71 mm x 255 mm

92 mm x 268 mm

107 mm x 255 mm

44 mm x 268 mm

54 mm x 255 mm

Thickness of wood

facing on guide

fence for increased

height of cut

15 mm 115 mm × 227 mm- -

25 mm 120 mm × 212 mm

60° (right and left) 92 mm x 185 mm- -

107 mm x 178 mm

Thickness of wood

facing on guide

fence for increased

height of cut

15 mm 115 mm × 155 mm

25 mm 120 mm × 140 mm

Cutting capacities for special cuttings

Type of cutting Cutting capacity

Crown molding 45° type

(with crown molding stopper used)

203 mm

Base board

(with horizontal vise used)

171 mm

• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange

without notice.

• Specicationsmaydifferfromcountrytocountry.

• WeightaccordingtoEPTA-Procedure01/2014

Symbols

The following show the symbols used for the equip-

ment. Be sure that you understand their meaning before

use.

Read instruction manual.

DOUBLE INSULATION

Toavoidinjuryfromyingdebris,keep

holding the saw head down, after making

cuts, until the blade has come to a com-

plete stop.

Whenperformingslidecut,rstpullcar-

riage fully and press down handle, then

push carriage toward the guide fence.

Produkt Specifikationer

Mærke:	Makita
Kategori:	Sav
Model:	LS1219L
Bredde:	644 mm
Dybde:	898 mm
Højde:	725 mm
Vægt:	29500 g
Produkttype:	Glidende sammensat geringssav
Pakketype:	Kasse
Indgangseffekt:	1800 W
Strømkilde:	Vekselstrøm
Vibrationsniveau:	2.5 m/s²
Tomgang (maks.):	3200 rpm
Kabellængde:	2.5 m
Bærehåndtag:	Ja
Lydeffektniveau:	100 dB
Lydtryksniveau:	91 dB
Usikkerhed i lydniveauet:	3 dB
Blad, diameter:	305 mm
Klinge boring:	30 mm
Savblade inkluderet:	Ja
Langsom start:	Ja
Klippe-kapacitet 0°:	382 mm
Støvudsugning:	Ja
Gering, indstilling (venstre):	60 °
Gering, indstilling (højre):	60 °
Konisk indstilling (venstre):	48 °
Konisk indstilling (højre):	48 °
Glideskinner:	Ja
Laserstyr:	Ja
Usikkerhed om vibrationsniveau:	1.5 m/s²
Facettype:	Enkelt facet
Vinkelskåret kapacitet (0° x 45°):	54 x 363 mm
