2
ENGLISH (Original instructions)
SPECIFICATIONS
Model TM3010C
Oscillation per minute 6,000 - 20,000 (min
-1)
Oscillation angle, left/right 1.6 ﾟ (3.2 ﾟ total)
Overall length 283 mm
without dust extraction attachment
1.6 kg
Net weight
with dust extraction attachment
1.7 kg
Safety class /II
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
END201-7
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･ Read instruction manual.
･ DOUBLE INSULATION
･ Only for EU countries
Do not dispose of electric equipment
together with household waste
material!
In observance of the European
Directive, on Waste Electric and
Electronic Equipment and its
implementation in accordance with
national law, electric equipment that
have reached the end of their life must
be collected separately and returned to
an environmentally compatible
recycling facility.
ENE080-1
Intended use
The tool is intended for sawing and cutting wood, plastic,
gypsum, non-ferrous metals, and fastening elements (e.
g. unhardened nails and staples). It is also intended for
working soft wall tiles, as well as dry sanding and
scraping of small surfaces. It is especially for working
close to edge and flush cutting.
ENG905-1
Noise
The typical A-weighted noise level determined
according to EN60745:
Work mode: Sanding
Sound pressure level (L
pA) : 80 dB (A)
Uncertainty (K) : 3 dB (A)
The noise level under working may exceed 80 dB (A).
Work mode: Cutting with plunge cut saw blade
Sound pressure level (L
pA) : 80 dB (A)
Uncertainty (K) : 3 dB (A)
The noise level under working may exceed 80 dB (A).
Work mode: Cutting with segment saw blade
Sound pressure level (L
pA) : 79 dB (A)
Uncertainty (K) : 3 dB (A)
The noise level under working may exceed 80 dB (A).
Work mode: Scraping
Sound pressure level (L
pA) : 82 dB (A)
Uncertainty (K) : 3 dB (A)
The noise level under working may exceed 80 dB (A).
Wear ear protection
ENG900-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745:
Work mode : sanding
Vibration emission (ah) : 2.5 m/s2 or less
Uncertainty (K) : 1.5 m/s2
Work mode : cutting with plunge cut saw blade
Vibration emission (ah) : 6.5 m/s2
Uncertainty (K) : 1.5 m/s2
Work mode : cutting with segment saw blade
Vibration emission (ah) : 2.5 m/s2
Uncertainty (K) : 1.5 m/s2
Work mode : scraping
Vibration emission (ah) : 5.0 m/s2
Uncertainty (K) : 1.5 m/s2
