ENGLISH (Original instructions)
SPECIFICATIONS
Model VC2201M
With φ28 mm X 3.5 m hose 2.0 m
3/min
Volume flow (air) With φ38 mm X 2.5 m hose 3.5 m
3/min
Vacuum 22 kPa
Type of protection IP X 4 (splash-proof)
Dust 22 L
Recoverable capacity Water 17 L
Dimensions (L x W x H) 552 mm x 398 mm x 569 mm
Net weight 16.0 kg
Safety class /II
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
END293-1
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･ Read instruction manual.
･ DOUBLE INSULATION
･ Take particular care and attention.
･ Warning! The cleaner may contain
hazardous dust.
･ Never stand on the cleaner.
･ Dust class M (medium). The cleaners
are capable of picking up dust class L
and M. Follow your county's regulations
relating to dusts and to occupational
health and safety.
･ Only for EU countries
Do not dispose of electric equipment
together with household waste
material!
In observance of the European
Directive, on Waste Electric and
Electronic Equipment and its
implementation in accordance with
national law, electric equipment that
have reached the end of their life must
be collected separately and returned to
an environmentally compatible
recycling facility.
ENE084-1
Intended use
The tool is intended for collecting both wet and dry dust.
The tool is suitable for commercial use, for example in
hotels, schools, hospitals, factories, shops, offices and
rental businesses.
ENF002-2
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated and can, therefore, also be used
from sockets without earth wire.
ENG905-1
Noise
The typical A-weighted noise level determined
according to EN/IEC60704:
Sound pressure level (L
pA) : 72.5 dB (A)
Uncertainty (K) : 2.5 dB (A)
The noise level under working may exceed 80 dB (A).
Wear ear protection
ENG900-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN/IEC60335:
The vibration emission value is below 2.5 m/s
2.
ENH038-3
For European countries only
EC Declaration of Conformity
Makita declares that the following Machine(s):
Designation of Machine:
Vacuum Cleaner
Model No./ Type: VC2201M
