Side 1/3

marvelrefrigeration.com | 800.223.3900

Performance

• The quietest ice machine you can buy

• New energy-saving options conserve water and energy

• Engineered to consistently produce pure, clear ice with unrivaled

clarity, immediate cooling and slower melt

• Its uniform size and compact density prove to be the optimal shape

to provide faster cooling, while taking up less space in your glass

• Produces up to 39 pounds of clear ice daily, the equivalent of nearly

eight convenience-store bags of ice

• Streamlined componentry and single-connection water ﬁ tting

for simple installation

Storage Capabilities

• Large-capacity bin stores 35 pounds of clear ice, while preserving

quality and assuring fresh ice production

• Easy-to-clean, hygienic interior surface

Touchpad Controls

• Marvel Intuit™ Integrated Controls feature all-new settings for

ultimate programmability

• Eco Ice™ mode moderates ice production to conservative usage,

saving 25% water (91 gallons monthly) and 25% energy ($45

annually)**

• Delay Start/Vacation option automatically postpones operation by

1/4/6/8 (hour or day) intervals, preventing wasteful water use

• Audible alerts and programmed cleaning reminders

Aesthetics

• New Illuminice™ feature projects arctic white LED light through clear

ice for a dazzling illumination effect

• First-ever glass door model with white interior adds drama to

entertaining at home

• Easy-to-install panel-ready option includes soft-close

integrated hinge

• Finish options: stainless steel, black or overlay panel

Additional Convenience

• Close Door Assist System™ prevents energy loss by automatically

drawing door to a gentle close

• Black toe kick adjustable to 4” with leveling legs

• 1-year parts and labor warranty, 5-year sealed system parts warranty

(see owner’s guide for details)

15” Marvel Clear Ice Machine

with Arctic White Illuminice™

Lighting

Model # ML15CL & ML15CP

Ordering Options

Gravity Drain Applications

Solid Stainless Steel Door, Right Hinge ML15CLS1RS

Solid Stainless Steel Door, Left Hinge ML15CLS1LS

Stainless Frame, Glass Door, Right Hinge ML15CLG1RS

Stainless Frame, Glass Door, Left Hinge ML15CLG1LS

Solid Smooth Black Door, Right Hinge ML15CLS1RB

Solid Smooth Black Door, Left Hinge ML15CLS1LB

Panel-Ready Solid Overlay Door,

Integrated Right Hinge* ML15CLP2RP

Panel-Ready Solid Overlay Door,

Integrated Left Hinge* ML15CLP2LP

Factory Installed Pump

Solid Stainless Door, Right Hinge ML15CPS1RS

Solid Stainless Door, Left Hinge ML15CPS1LS

Stainless Frame, Glass Door, Right Hinge ML15CPG1RS

Stainless Frame, Glass Door, Left Hinge ML15CPG1LS

Solid Smooth Black Door, Right Hinge ML15CPS1RB

Solid Smooth Black Door, Left Hinge ML15CPS1LB

Panel-Ready Solid Overlay Door,

Integrated Right Hinge* ML15CPP2RP

Panel-Ready Solid Overlay Door,

Integrated Left Hinge* ML15CPP2LP

*Easy installation! No panel kit required. Consult your cabinet maker for overlay

panel and handle options.

Solid Overlay

(Panel Ready)*

BlackSolid Stainless

Steel

Stainless Steel

Frame

Finish Options

14 7/8" W

33 3/4" H

25 9/16’ D

including

handle

marvelrefrigeration.com | 800.223.3900

15⁄ "32

(2.9 cm)

15⁄ "32

(2.9 cm)

Clearance

for hinge

2 places

143⁄ "4

(37.5 cm)

Clearance for

screw head,

4 places

Figure 14

Left Hand Hinged Door

15" (38.1 cm) wide appliance

Hinge side of door

Clearance

for hinge

2 places

143⁄ "4

(37.5 cm) 1⁄ " (6 mm) 4

Deep

1" (25.4 mm) diameter

counter bore 1⁄ " (6.4mm) 4

deep 4 places.

13⁄ "4

(4.4 cm)

7⁄

(12.4 cm)

27⁄ "32

(9.7 cm)

11⁄ "16

(4.3 cm)

(12.7 cm)

⁄ "8

(7.9 cm)

Minimum

(5.1 cm)

41⁄ "8

(10.5 cm)

Minimum

3011⁄ "32

(77.1 cm)

13⁄ "16

(3 cm)

⁄ "8

(7.9 cm)

⁄ "2

(3.8 cm)

typical

11 ⁄ "16

(9.4 cm)

31⁄ "8

(7.9 cm)

Minimum

This side

facing interior This side

facing interior

⁄ " (6 mm)4

radius is

permissible

Hinge side of door

Top of door

Clearance for

screw head,

4 places

Figure 16

Right Hand Hinged Door

15" (38.1 cm) wide appliance

327⁄ "32

(9.7 cm)

1⁄ " (6 mm) 4

Deep

(12.7 cm)

1" (25.4 mm) diameter

counter bore 1⁄ " (6 mm) 4

deep 6 places.

1⁄ " (6 mm)4

radius is

permissible

3011

⁄ "32

(77.1 cm)

7⁄

(12.4 cm)

31⁄

(7.9 cm)

11⁄ "2

(3.8 cm)

typical

3⁄ "4

(4.4 cm)

31⁄ "8

(7.9 cm)

Minimum

(5.1 cm) 311

⁄ "16

(9.4 cm)

41⁄ "8

(10.5 cm)

Minimum

111 ⁄16"

(4.3 cm)

31⁄ "8

(7.9 cm)

Minimum

3⁄ "16

(3 cm)

Panel Overlay Dimensions (Frame Door)

Rough-In Dimensions

A. Rough-In Width 15”

B. Rough-In Height 34” to 35”

C. Rough-In Depth 24”

Product Dimensions

D. Width 14 7/8”

E. Height 33 3/4” to 34 3/4”

G. Depth to Front of Door

Solid Door 23 5/8”

Overlay Door 22 15/16”

H. Depth to Handle 25 9/16’ (Stainless Steel)

I. Depth with door at 90˚

Solid Door 37 13/32”

Overlay Door 38 5/8”

Product Features

Interior Cabinet Finish White

Capacity 35 lbs of Ice Storage

Shelving System NA

Shelf Fronts NA

Other Storage Ice Bin

Interior Lighting Illuminice™ White LED

Toe Grill Finish Black

Hinge Classic Hinge

Handle

Slim Designer Handle

(Panel Overlay Does

Not Include Handle)

Control Type Intuit™

Temperature Range NA

Lock No

Electrical Requirements 120V / 60Hz / 15A

Length of Power Cord 6’

Shipping Weight 127 lbs

Finishes Stainless Steel, Overlay, Black

Vacation Mode Yes

Agency Approvals CSA

"A"

"B"

"C"

"D"

"E"

"I""G"

"H"

Product Dimensions

For comprehensive installation instructions, please visit

www.marvelrefrigeration.com to access the owner’s guide.
