Additional Guide for 15.5" Pedestal Installation assistance
1
Follow instructions below to assist in attaching all four (4) fasteners to install 15.5" Pedestal to Washer or Dryer.
Tools needed:
nDrill Machine with 3/16" drill bit.
n1/4" hex-head ratchet or 5/16" open ended wrench.
Rework Procedure:
1. Empty the Pedestal Drawer.
2. Remove the Pedestal Drawer as per Installation Instruction document (Refer Below Image).
4. Tilt the Wash Unit with Pedestal assembly gently on one side and lay it down as shown in the below images.
A
B
DO NOT LAY DOWN WASHER AS
SHOWN IN THE ABOVE IMAGE
LAY DOWN WASHER AS SHOWN
IN THE ABOVE IMAGE
A. Drawer slide
B. Hex-head screw
W11687988A
Pedestal Installation:
Remove pedestal drawer
A
B
2
5. Check if the Front or Rear Screw used to mount the Pedestal to Wash Unit Model Base are missing.
6. Check if Pedestal is xed to Wash Unit Model Base with 2 screw #12-3/4 as instructed in the Installation Instruction.
7. Make sure the Pedestal is moved towards the front of the Washer and aligned to Washer Front.
A
B
A. Screw on Rear side
B. Screw on Front side
A
B
