Side 1/4

Installation Manual

 Type：

：

：： Medical Switching Power Supply

(1) Enclosed (Families: MSP)

(2) Modular (Families: MP, NMP)

(3) PCB (Families: MPS, MPD, MPT, MQ, RPS, RPD, RPT, RPTG, NEM, PM)

(4) Adaptor (Families: GSM, MES)

 Installation

(1) Enclosed Type

(a) Before any installation or maintenance work, please disconnect your system from the utility.

Ensure that it cannot be re-connected inadvertently!

(b) Mounting orientations other than standard orientation or operate under high ambient

temperature may increase the internal component temperature and will require a de-rating in

output current. Please refer to the specification sheets to receive the optimum mounting

position and information about the de-rating curve.

must be kept when the adjacent device is a heat source.

(d) Keep enough insulation distance between mounting screws and internal components of

Enclosed units. Please refer to case drawing on specifications to receive the maximum length of

mounting screw.

(e) Recommended wires of Enclosed units are shown as below.

AWG 18 16 14 12 10 8

Rated Current of

Equipment (Amp) 6A 6-10A 10-16A 16-25A 25-32A 32-40A

Cross-section of

Lead(mm2 ) 0.75 1.00 1.5 2.5 4 6

Note: The suggested maximum current above only suit for 1-4 strips, 5 or more

strips should not exceed 80% of current rating.

Make sure that all strands of each stranded wire enter the terminal connection and the screw

terminals are securely fixed to prevent poor contact.

(f) For other information about the products, please refer to www.meanwell.com for details.

(2) Modular Type

(a) Before any installation or maintenance work, please disconnect your system from the utility.

Ensure that it cannot be re-connected inadvertently!

(b) Mounting orientations other than standard orientation or operate under high ambient

temperature may increase the internal component temperature and will require a de-rating in

output current. Please refer to the specification sheets to receive the optimum mounting

position and information about the de-rating curve.

must be kept when the adjacent device is a heat source.

(d) Keep enough insulation distance between mounting screws and internal components of

Modular units. Please refer to case drawing on specifications to receive the maximum length of

mounting screw.

(e) Recommended wires of Modular units are shown as below.

AWG 18 16 14 12 10 8

Rated Current of

Equipment (Amp) 6A 6-10A 10-16A 16-25A 25-32A 32-40A

Cross-section of

Lead(mm2 ) 0.75 1.00 1.5 2.5 4 6

Note: The suggested maximum current above only suit for 1-4 strips, 5 or more

strips should not exceed 80% of current rating.

Make sure that all strands of each stranded wire enter the terminal connection and the screw

terminals are securely fixed to prevent poor contact.

(f) For other information about the products, please refer to www.meanwell.com for details.

Installation Manual

(3) PCB Type

(a) Before any installation or maintenance work, please disconnect your system from the utility.

Ensure that it cannot be re-connected inadvertently!

(b) Mounting orientations other than standard orientation or operate under high ambient

temperature may increase the internal component temperature and will require a de-rating in

output current. Please refer to the specification sheets to receive the optimum mounting

position and information about the de-rating curve.

must be kept when the adjacent device is a heat source.

(d) Recommended wires of PCB units are shown as below.

AWG 18 16 14 12 10 8

Rated Current of

Equipment (Amp) 6A 6-10A 10-16A 16-25A 25-32A 32-40A

Cross-section of

Lead(mm2 ) 0.75 1.00 1.5 2.5 4 6

Note: The suggested maximum current above only suit for 1-4 strips, 5 or more

strips should not exceed 80% of current rating.

Make sure that all strands of each stranded wire enter the terminal connection and the screw

terminals are securely fixed to prevent poor contact.

(e) At least 5mm insulation distance on the bottom of PCB units should be kept and a Mylar film

should be added between the units and the system. In addition, keep enough insulation

distance of 15mm around the PCB units.

(f) PCB units greater than 120W may require a forced air/fan for cooling. Please refer to

specifications to receive a minimum air intensity and air-flow direction.

(g) For other information about the products, please refer to www.meanwell.com for details.

(4) Adapter Type

(a) Before any installation or maintenance work, please disconnect your system from the utility.

Ensure that it cannot be re-connected inadvertently!

(b) Mounting orientations other than standard orientation or operate under high ambient

temperature may increase the internal component temperature and will require a de-rating in

output current. Please refer to the specification sheets to receive the optimum mounting

position and information about the de-rating curve.

must be kept when the adjacent device is a heat source.

(d) Before attaching the DC plug of an adaptor to equipment, please unplug the adaptor from the

AC power and verify the unit is within the voltage and current rating on the equipment.

(e) Keep the linkage between the adaptor and its power cord tightly as well as connecting the DC

plug to equipment properly.

(f) Protect the power cord of adaptors from being trodden on or being squashed.

(g) An approved power cord of an adaptor should greater or equal to SVT, 3G×18AWG or H03VV-F,

3G×0.75mm2.

(h) If the final equipment is not used for long period of time, disconnect the equipment from

adaptors to avoid being damaged by voltage peaks or lightning strike.

(i) For other information about the products, please refer to www.meanwell.com for details.

 User Manual

NMP series:

http://www.meanwell.com/webapp/product/search.aspx?prod=NMP1K2&pdf=Tk1QLUUucGRm&a=4

Produkt Specifikationer

Mærke:	Mean Well
Kategori:	Ikke kategoriseret
Model:	RPD-65C
Bredde:	76 mm
Dybde:	127 mm
Højde:	29 mm
Vægt:	220 g
Antal pr. pakke:	63 stk
Udgangseffekt:	65 W
Udgangsspænding:	5 V
Bæredygtighedscertifikater:	RoHS
Indgangsspænding:	90 - 264 V
