Side 1/16

WATCHER LT

Instructions Manual

PC Camera for Teleconferencing & Video Surveillance

MT4023

Parameters and features

■ 300Kpix Digital Camera CMOS Sensor

■ Interface: USB2.0 port (compatible with USB1.1)

■ Transmission rate: (640*480ppi) 30fps

■ 2560x1920 ppi – maximum still picture size

■ Image focus: 5cm to inﬁ nity

■ Non-compression image processor

■ AWB (Automatic White Balance)

■ 2 glass lens

■ Microphone built in

■ Automatic Face Tracking and Zoom (software oper-

ated available in low resolution mode only)

System requirements

■ IBM PC or compatible PC or laptop with USB port

■ Pentium 1GHz or higher CPU

■ Over 500MB free hard-disc space

■ CD-ROM drive

■ 256MB memory

■ Support DirectX 9.0 VGA card

■ Windows XP/ Windows Vista

Installation

Hardware installation

Please plug camera into free USB 2.0 port

Thanks for choosing our new generation of high reso-

lution Web Camera. It is a driverless product for real-

time data transmission thru PC Via USB port. This cam-

era creates a new standards in digital imaging.

Software installation

This camera is driverless device, what means no any

driver is necessary to use it with operation system.

Camera is ready to work with any application using

Windows Twain type driver (for example Skype).

To use ZOOM and Face tracking function, please install

software AMCAP from CD-ROM discs included in the set.

Operate

1. Start your Web Cam by selecting the AMCap appli-

cation from Start menu as shown below.

The preview of webcam picture will appear.

2. Click the Video Capture Pin in Option menu to ad-

just the resolution of preview picture.

Note.

Higher resolution will decrease picture speed (fps).

Advanced Settings

Click the Video Capture Filter to get access to advanced

settings of picture.

Precautions

■ This PC Camera is not waterproof. Don’t use it out-

door and places with high humidity.

■ Don’t disassemble his device.

■ For clearing use only dry, clean clothes. Don’t use

alcohol and solvents.

You can make 5 Mpix snapshot (interpolation) by

choosing maximum resolution in snapshot menu (the

camera picture must be set ﬁ rstly to maximum 300Kpix

resolution).

Enabling “Face tracking” function will focus camera

picture automatically on user face (only in VGA mode)

The Advanced settings can also be accessed by right

click on the Camera Icon in Taskbar.

Eﬀ ect page oﬀ ers 18 special eﬀ ects and 10 photo

frames for actual view.

Mark it in low-light condition

Adjust the parameter to favorite settings

Set frequency to local power frequency conditions

(50Hz in Europe, 60Hz in America and part of Asia)

Special eﬀ ects setting ﬁ elds

Photo frame setting ﬁ elds

With this function, user can edit the photo frame

Access to digital zoom mode is possible only in VGA mode by

marking “Enable Zoom” checkbox.
