Playing your iPod

To see the iPod options

press h followed by Aux, i80.

Connecting the iPod

The i80 iPod Dock allows you to play the

sound from your iPod through the F80.

This section explains how you control the

iPod from the F80, using the front panel

controls or remote control.

Select the i80 source by pressing h

followed by Aux, i80.

After a delay of up to five seconds the

iPod displays a message showing that it

is connected.

•

Playing and pausing

To play a track

Press ±.

While a track is playing the display shows

the elapsed time, the title of the track,

and its position in the album or playlist

(for example, 1 of 9).

While a track is playing the ± label

changes to =.

To pause the disc

Press =.

While a track is paused a = symbol is

displayed at top right of the display and

the = label changes to ±:

Baby be Mine

]

[

)

1 of 9

iPod 2:45

(

To resume play

Press ±.

•

Stepping between tracks

You can step between tracks while the

iPod is playing or paused.

To step to the start of the next track

Press ].

To restart the current track

Press [.

To select a track

Press [ or ] until the display

shows the track you want to play.

Shuffle and repeat

Press ( to display the keys for shuffle

and repeat.

To shuffle the tracks in the current

album/playlist

Press Shuffle.

To repeat the current track/playlist

Press Repeat.

•

Scanning through a track

Press ) to display the keys for

scanning.

To scan at faster than normal speed

Press { for reverse scan or }

for forward scan.

While scanning a scan symbol is shown

at top right of the display:

Billie Jean

}

{

iPod 4:35

Press ± to revert to normal play.

Play resumes from the point you

reached.

•

Browsing your iPod

Browsing your music

To browse for music

Press Menu from the playing screen.

The first time you press Menu you will

see the main MUSIC screen with the first

menu, Playlists, shown:

Playlists

Enter

^¬

iPod MUSIC

Press ` or ^ to step between

the main menus: Playlists,

Albums, Artists, Songs, Genres,

Composers, Podcasts, and

Audiobooks.

If you subsequently press Menu while

music is playing you will return to the last

menu item you were looking at.

•

Navigating the menus

To step between items on the

current menu

Press ` or ^.

The name of the current menu or

category is shown at the top of the

display; for example ALBUMS.

Thriller

Enter

^¬

iPod ALBUMS

•

Selecting an item

To show the contents of an item

Select a playlist, album, artist, genre,

composer, podcast, or audiobook.

Press Enter.

To play a track

Select a song.

Press Enter.

•

Returning to the previous

To return to the previous menu

Press Menu.

Pressing Menu from the MUSIC screen

returns to the playing screen.

Returning to the playing

screen

Press ¬, or press and hold Menu on

the remote control.

Alternatively if you do not press anything

the display reverts to the playing screen

after 20 seconds.

•

Lady in my Life

Enter

^¬

iPod Thriller

Baby be Mine

]

[

)

1 of 9

iPod 2:34

(

Connecting the i80 dock

To connect the iPod

Connect one end of the i80 Dock

cable to the connector on the back of

the i80 Dock.

Connect the other end of the cable to

the i80 Dock connector on the F80.

Insert the plastic cover supplied with

your iPod onto the i80 Dock.

Mount your iPod on the i80 Dock.

While connected the iPod battery is

recharged from the product.

•

USB Connector

The USB connector optionally allows you

to charge your iPod from an external

USB power supply or computer. The i80

light changes from green to red when

charging.

Setting iPod control

The instructions on this leaflet explain

how to control the iPod from the F80

using the front panel controls or remote

control.

If you prefer to disable iPod control, for

example to view video on the iPod while

playing the sound through the product,

proceed as follows:

To enable/disable iPod control

Press h, Adjust, Setup to display

the SETUP menus.

Press ) to display the i80 Ctrl

option.

You can choose between Enabled,

which allows you to control the iPod from

the product, or Disabled, which allows

you to play the iPod without controlling it.

•

USB i80

dock cable

i80 iPod dock for F80

Designed and Engineered by

Meridian Audio Limited

Cambridgeshire England

Safety instructions

This product is only intended for use with

an iPod in conjunction with a Meridian

F80. Please refer to the F80 User Guide

for additional safety information.

i80 compatibility

The i80 is fully compatible with the iPod

Mini, iPod Nano, iPod Classic, and

iTouch.

It may also be usable with the iPhone;

when connecting select Airplane Mode

to avoid incoming calls and messages

interrupting the audio.

Acknowledgements

Meridian is a registered trade mark of

Meridian Audio Ltd.

iPhone and iPod are trade marks or

registered trade marks of Apple Inc.

Audio Ltd.

Part number: P86017

This guide was produced by:

Human-Computer Interface Ltd,

http://www.interface.co.uk/

Sales and service in the UK

Meridian Audio Ltd

Latham Road

Huntingdon

Cambridgeshire

PE29 6YE, England

Tel +44 (0)1480 445678

Fax +44 (0)1480 445686

Sales and service in the USA

Meridian America Inc

8055 Troon Circle

Suite C

Austell

GA30168-7849, USA

Tel +1 (404) 344 7111

Fax +1 (404) 346 7111

Visit us on the Web:

http://www.meridian-audio.com/

Designed and manufactured in the UK

by Meridian Audio Ltd. Meridian Audio

reserves the right to make changes and

improvements to any of the products

described in this document without prior

notice.
