METRA. THE WORLD’S BEST KITS.™

APPLICATIONS

KIT FEATURES

KIT COMPONENTS

TOOLS REQUIRED

1-800-221-0932

metraonline.com

INSTALLATION INSTRUCTIONS FOR PART 99-3010S

2010-UP CHEVY CAMARO

99-3010S

• AXXESS Interface included

• DIN Head Unit Provision w/ Pocket

• ISO DIN Head Unit Provision w/ Pocket

• DDIN Head Unit Provision

• ISO Stacked Head Unit Provision

• Painted Silver to Match Factory Dash

•A) Radio Trim Panel •B) Radio Housing •C) ISO Brackets •D) ISO Trim Plate

•E) DDIN Brackets •F) DDIN Trim Plate •G) Pocket •H) Interface •I) 20 Pin GM Harness

•J) 4 Pin Harness w/ Stripped Leads •K) 22 Pin to 44 Pin Camaro Harness

•L) 18 Pin to 10 Pin HVAC Harness

•M) Female 3.5mm Connector w/ Brown and Brown/White Wires •N) (2) Panel Clips

• Phillips Screwdriver • Panel Removal Tool • Small Flat Blade Screwdriver

• Socket Wrench • Tape • Crimping Tool •Connectors (i.e. Butt Connectors)

4 pin

18 pin

10 pin

A B

E F

IGNITION

TERMINALS

WIRE

CUTTER

M3.5

M2.6

ISO

2.5

1.5

ANTENNA CONNECTIONS (sold separately)

•40-EU55 European Antenna Adapter 2006-UP

REV. 2/9/11

TABLE OF CONTENTS

DASH DISASSEMBLY

• CHEVY CAMARO 2010-UP . . . . . . . . . . . . . . . . . . 1-3

KIT PREPARATION

• CHEVY CAMARO 2010-UP . . . . . . . . . . . . . . . . . . . . 4

KIT ASSEMBLY

CHEVY CAMARO 2010-UP

• DIN HEAD UNIT PROVISION . . . . . . . . . . . . . . . . . . . 5

• ISO DIN HEAD UNIT PROVISION . . . . . . . . . . . . . . . . 6

• DDIN/STACKED ISO DIN HEAD UNIT PROVISION . . . . . . 7

IINTERFACE WIRING

• CHEVY CAMARO 2010-UP . . . . . . . . . . . . . . . . . . 8-18

*NOTE: Refer Also to the instructions included with the aftermarket radio.

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certified technicians

99-3010S
