Side 1/5

Metra. The World’s Best Kits.

INSTALLATION INSTRUCTIONS

99-8911HG

Attention! Let the vehicle sit with the key

out of the ignition for a few minutes before

removing the factory radio. When testing the

aftermarket equipment, ensure that all factory

equipment is connected before cycling the

key to ignition.

KIT FEATURES

• ISO DIN radio provision with pocket

• Painted gloss black

KIT COMPONENTS

• A) Radio trim panel • B) Radio brackets • C) Pocket • D) #8 x 3/8” Phillips screws (4) • E) Panel clips (4)

TOOLS REQUIRED

• Panel removal tool • Phillips screwdriver

• 10mm socket wrench

TABLE OF CONTENTS

Dash Disassembly ..................................................2

Kit Preparation .......................................................2

Kit Assembly ..........................................................3

WIRING & ANTENNA CONNECTIONS

(sold separately)

Wiring Harness: 70-1761

Antenna adapter: 40-LX11

Steering wheel control interface: ASWC-1

A B C D E

Subaru Ascent 2019-up

Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle

speciﬁc applications

1.800.221.0932

MetraOnline.com

(Figure A) (Figure A)

(Figure B) (Figure B)

(Figure C) (Figure C)

DASH DISASSEMBLY KIT PREPARATION

1. Unclip and remove the a/c vent panels

to the left and right of the radio.

(Figure A)

2. Unclip the hazard switch panel, then set

it on top the dash. (Figure B)

3. Remove (4) 10mm screws securing the

radio. Slide the radio out, then unplug

and remove the radio. (Figure C)

Continue to Kit Preparation

From the factory radio brackets:

1. Loosen (8) Phillips screws securing the

radio. (Figure A)

2. Remove (4) Phillips screws securing the

lower electronic module then remove.

(Figure A)

3. Remove (3) screws securing the upper

electronic module then remove.

(Figure A)

4. Relocate the lower electronic module

in the radio cavity, down low. It should

ﬁt snugly, but if not, secure with zip

ties. Connect the wiring harness in the

vehicle back to the module.

5. Secure the upper electronic module

to the radio brackets using the factory

screws. (Figure B)

6. Attach (4) panel clips to the radio trim

panel. (Figure C)

Continue to Kit Assembly

Step 1

Left side shown

Step 2

Step 3
