Side 1/4

Installation instructions for AX-ADBOX1

REV. 9/14/2015 INSTAX-ADBOX1

CAUTION!

Metra recommends disconnecting the negative bat

tery terminal before beginning any installation, unless the vehicle

manufacturer recommends against so. Please check with your local

Dealership for more information. All accessories, switches, climate

controls panels, and especially air bag indicator lights must be con

nected before reconnecting the battery or cycling the ignition. Also,

do not remove the factory radio with the key in the on position, or the

vehicle running. It would be best to remove the key from the ignition

and then wait a few seconds before removing the factory radio.

axxessinterfaces.com

•

metraonline.com

Axxess Integrate

Note: This is a general list for the AX-ADBOX1 lineup. Please see the individual

harnesses for exact features available.

• Provides accessory (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Used in amplified, non-amplified systems

• Retains chimes (GM)

• Turn signal click (GM)

• Provides NAV outputs (parking brake, reverse, mute, and V.S.S.)

• Pre-wired ASWC-1 harness included (ASWC-1 sold separately)

• Retains OnStar/OE Bluetooth

• Adjustable gain control for overall volume (on amplified systems)

• Adjustable gain control for chimes and OnStar (GM)

• Retains SYNC in Ford (if equipped)

• Adjustable gain control for SYNC (Ford)

• Retains Blind spot detection system in Chrysler/Dodge/Jeep (if equipped)

• High level speaker input

• Micro “B” USB updatable

• Retains balance and fade

• Retains digital fade (excluding Ford and VW vehicles)

-,(;<9,:

• Cutting tool • Crimping tool • Tape • Connectors

(example: butt-connectors, bell caps, etc.)

;663:9,8<09,+

AX-ADBOX1

AX-ADBOX Series main interface control box

• AX-ADBOX1 interface

• 16-pin harness with stripped leads

05;,9-(*,*64765,5;:

(7730*(;065:

See application list inside

AX-ADBOX1

Applications

Interface must be used in conjunction of one of the

following harnesses:

Note: Applications are notated with characters to indicate which

harnesses needs to be used.

(a) AX-ADCH01

(b) AX-ADCH02

(d) AX-ADFD02

(e) AX-ADGM01

(f) AX-ADGM02

(g) AX-ADGM03

(h) AX-ADGM04

(i) AX-ADTY01

(with amplifier only)

(x) AX-ADVW01

* Indicates vehicle has a digital amplifier option.

** Indicates SONY/THX sound systems are digitally amplified.

*** These vehicles have a digital amp option. Please look at

the “Service Parts Identification” sticker in the glove box

for the RPO code listed in parenthesis.

† Indicates vehicle is standard for a digital amplifier.

6 In 2012-up, if the vehicle is equipped with OE navigation,

you must use the GMOS-LAN-08 if non-amped;

GMOS-LAN-07 if amped.

BUICK

Allure (g) 2005-2009

Century (g) 2004-2005

Enclave (e) 2008-up

LaCrosse (g) 2005-2009

Lucerne (e) 2006-2011

Rainier***(UQA) (g) 2004-2007

Rendezvous (g) 2002-2007

Terraza (g) 2005-2008

CADILLAC

DTS †(e) 2006-2011

Escalade/

ESV/EXT †(g) 2003-2006

Escalade †(e) 2007-2011

SRX †(e) 2007-2009

CHEVROLET

Avalanche***

(Y91) (g) 2003-2006

Avalanche***

(STZ or Y91) 6(e) 2007-2013

Cavalier (g) 2000-2005

Cobalt (f) 2007-2010

Corvette (g) 2005-2013

Equinox (e) 2007-2009

Express (g) 2003-2007

Express

(without NAV) (e) 2008-up

HHR (f) 2006-2011

Impala (g) 2000-2005

Impala (e) 2006-2013

Kodiak (g) 2003-2009

Malibu (g) 2001-2003

Malibu

(classic) (g) 2004-2005

Malibu (f) 2008-2012

Malibu (h) 2013-up

Monte Carlo (g) 2000-2005

Monte Carlo (e) 2006-2007

Silverado***

(Y91) (g) 2003-2006

Silverado

(classic)***

(Y91) (g) 2007

Silverado

(new body)***

(Y91) 6(e) 2007-2013

Silverado 2500/3500***

(Y91) 6(e) 2014

SSR***(UQA) (g) 2003-2006

Suburban***(Y91) (g) 2003-2006

Suburban***

(STZ or Y91) 6(e) 2007-2013

Tahoe***(Y91) (g) 2003-2006

Tahoe***

(STZ or Y91) 6(e) 2007-2013

Trailblazer***(UQA) (g)

2002-2006

Trailblazer (g) 2007-2009

Traverse (e) 2009-up

Uplander (g) 2005-2008

CHRYSLER

200*(b) 2011-2014

300*(a) 2005-2007

300*(b) 2008-2010

Aspen*(a) 2007

Aspen*(b) 2008-2009

Sebring*(b) 2007-2010

Town & Country*(b) 2008-up

DODGE

Avenger*(b) 2008-2014

Caliber*(a) 2007-2008

Caliber*(b) 2009-2010

Challenger*(b) 2008-up

Charger*(a) 2005-2007

Charger*(b) 2008-2010

Dakota*(a) 2005-2007

Dakota*(b) 2008-2011

Durango*(a) 2004-2007

Durango*(b) 2008-2013

Grand Caravan*(b) 2008-up

Journey*(b) 2009-2010

Magnum*(a) 2005-2007

Magnum*(b) 2008-2009

Nitro*(b) 2007-2011

Ram 1500*(a) 2006-2008

Ram 1500*(b) 2009-2011

Ram 2500/3500*(a) 2006-2009

Ram 2500/3500*(b) 2010-2011

Ram Chassis

Cab*(a) 2006-2010

Ram Chassis

Cab*(b) 2011

FORD

Edge (d) 2011-2014

(Continued on the next page)
